TechnischeꢀInformationꢀ/ꢀTechnicalꢀInformation
IGBT-Module
IGBT-modules
FZ1500R33HL3
IGBT,Wechselrichterꢀ/ꢀIGBT,Inverter
HöchstzulässigeꢀWerteꢀ/ꢀMaximumꢀRatedꢀValues
Kollektor-Emitter-Sperrspannung
Collector-emitterꢀvoltage
Tvj = -40°C
Tvj = 150°C
3300
3300
VCES
IC nom
ICRM
Ptot
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
V
A
A
Kollektor-Dauergleichstrom
ContinuousꢀDCꢀcollectorꢀcurrent
TC = 95°C, Tvj max = 150°C
1500
3000
17,0
PeriodischerꢀKollektor-Spitzenstrom
Repetitiveꢀpeakꢀcollectorꢀcurrent
tP = 1 ms
Gesamt-Verlustleistung
Totalꢀpowerꢀdissipation
TC = 25°C, Tvj max = 150°C
ꢀ kW
Gate-Emitter-Spitzenspannung
Gate-emitterꢀpeakꢀvoltage
ꢀ
VGES
+/-20
ꢀ
V
CharakteristischeꢀWerteꢀ/ꢀCharacteristicꢀValues
min. typ. max.
Kollektor-Emitter-Sättigungsspannung
Collector-emitterꢀsaturationꢀvoltage
IC = 1500 A, VGE = 15 V
IC = 1500 A, VGE = 15 V
IC = 1500 A, VGE = 15 V
Tvj = 25°C
Tvj = 125°C
Tvj = 150°C
2,40 2,85
2,95 3,50
3,10
V
V
V
VCE sat
Gate-Schwellenspannung
Gateꢀthresholdꢀvoltage
IC = 72,0 mA, VCE = VGE, Tvj = 25°C
VGE = -15 V ... +15 V, VCE = 1800V
Tvj = 25°C
VGEth
QG
5,2
5,8
42,0
0,42
280
6,00
ꢀ
6,4
V
µC
Ω
Gateladung
Gateꢀcharge
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
InternerꢀGatewiderstand
Internalꢀgateꢀresistor
RGint
Cies
Cres
ICES
IGES
td on
Eingangskapazität
Inputꢀcapacitance
f = 1 MHz, Tvj = 25°C, VCE = 25 V, VGE = 0 V
f = 1 MHz, Tvj = 25°C, VCE = 25 V, VGE = 0 V
VCE = 3300 V, VGE = 0 V, Tvj = 25°C
VCE = 0 V, VGE = 20 V, Tvj = 25°C
nF
nF
Rückwirkungskapazität
Reverseꢀtransferꢀcapacitance
Kollektor-Emitter-Reststrom
Collector-emitterꢀcut-offꢀcurrent
5,0 mA
Gate-Emitter-Reststrom
Gate-emitterꢀleakageꢀcurrent
ꢀ
400 nA
µs
Einschaltverzögerungszeit,ꢀinduktiveꢀLast
Turn-onꢀdelayꢀtime,ꢀinductiveꢀload
IC = 1500 A, VCE = 1800 V
VGE = ±15 V
RGon = 0,91 Ω, CGE = 330 nF
Tvj = 25°C
Tvj = 125°C
Tvj = 150°C
0,50
0,50
0,50
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
µs
µs
Anstiegszeit,ꢀinduktiveꢀLast
Riseꢀtime,ꢀinductiveꢀload
IC = 1500 A, VCE = 1800 V
VGE = ±15 V
RGon = 0,91 Ω, CGE = 330 nF
Tvj = 25°C
Tvj = 125°C
Tvj = 150°C
0,55
0,55
0,55
µs
µs
µs
tr
td off
tf
Abschaltverzögerungszeit,ꢀinduktiveꢀLast
Turn-offꢀdelayꢀtime,ꢀinductiveꢀload
IC = 1500 A, VCE = 1800 V
VGE = ±15 V
RGoff = 2,7 Ω, CGE = 330 nF
Tvj = 25°C
Tvj = 125°C
Tvj = 150°C
4,10
4,30
4,30
µs
µs
µs
Fallzeit,ꢀinduktiveꢀLast
Fallꢀtime,ꢀinductiveꢀload
IC = 1500 A, VCE = 1800 V
VGE = ±15 V
RGoff = 2,7 Ω, CGE = 330 nF
Tvj = 25°C
Tvj = 125°C
Tvj = 150°C
0,40
0,40
0,40
µs
µs
µs
EinschaltverlustenergieꢀproꢀPuls
Turn-onꢀenergyꢀlossꢀperꢀpulse
IC = 1500 A, VCE = 1800 V, LS = 85 nH
VGE = ±15 V, di/dt = 4300 A/µs (Tvj = 150°C) Tvj = 125°C
RGon = 0,51 Ω, CGE = 330 nF
Tvj = 25°C
2300
3200
3600
mJ
mJ
mJ
Eon
Eoff
Tvj = 150°C
AbschaltverlustenergieꢀproꢀPuls
Turn-offꢀenergyꢀlossꢀperꢀpulse
IC = 1500 A, VCE = 1800 V, LS = 85 nH
VGE = ±15 V, du/dt = 1550 V/µs (Tvj = 150°C)Tvj = 125°C
RGoff = 2,7 Ω, CGE = 330 nF
Tvj = 25°C
2400
2950
3100
mJ
mJ
mJ
ꢀ
ꢀ
Tvj = 150°C
Kurzschlußverhalten
SCꢀdata
VGE ≤ 15 V, VCC = 2500 V
VCEmax = VCES -LsCE ·di/dt
ISC
ꢀ
tP ≤ 10 µs, Tvj = 150°C
6400
A
Wärmewiderstand,ꢀChipꢀbisꢀGehäuse
Thermalꢀresistance,ꢀjunctionꢀtoꢀcase
proꢀIGBTꢀ/ꢀperꢀIGBT
RthJC
RthCH
Tvj op
ꢀ
ꢀ
ꢀ
7,35 K/kW
K/kW
Wärmewiderstand,ꢀGehäuseꢀbisꢀKühlkörper proꢀIGBTꢀ/ꢀperꢀIGBT
Thermalꢀresistance,ꢀcaseꢀtoꢀheatsink
10,0
λ
Pasteꢀ=ꢀ1ꢀW/(m·K)ꢀꢀꢀ/ꢀꢀꢀꢀλgreaseꢀ=ꢀ1ꢀW/(m·K)
TemperaturꢀimꢀSchaltbetrieb
Temperatureꢀunderꢀswitchingꢀconditions
ꢀ
-40
ꢀ
150
°C
