IXYF30N450
ISOPLUS i4-PakTM (HV) Outline
Symbol Test Conditions
(TJ = 25°C Unless Otherwise Specified)
Characteristic Values
Min.
Typ.
Max.
gfS
IC = 30A, VCE = 10V, Note 1
VCE = 25V, VGE = 0V, f = 1MHz
11
18
S
Cies
Coes
Cres
1840
83
pF
pF
pF
35
Qg
88
11
40
nC
nC
nC
Qge
Qgc
IC = 30A, VGE = 15V, VCE = 1000V
td(on)
tr
td(off)
tf
td(on)
tr
td(off)
tf
38
318
ns
ns
ns
ns
Resistive Switching Times, TJ = 25°C
Pin 1 = Gate
IC = 30A, VGE = 15V
Pin2 = Emitter
Pin 3 = Collector
Tab 4 = Isolated
168
VCE = 960V, RG = 15
1220
42
590
ns
ns
ns
ns
Resistive Switching Times, TJ = 125°C
IC = 30A, VGE = 15V
180
VCE = 960V, RG = 15
1365
RthJC
RthCS
0.54 °C/W
°C/W
0.15
Notes:
1. Pulse test, t < 300s, duty cycle, d < 2%.
2. Device must be heatsunk for high-temperature leakage current
measurements to avoid thermal runaway.
ADVANCE TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from a subjective evaluation of the design, based upon prior knowledge and experience, and constitute
a "considered reflection" of the anticipated result. IXYS reserves the right to change limits, test
conditions, and dimensions without notice.
IXYS Reserves the Right to Change Limits, Test Conditions and Dimensions.
