Product specification
PZT2907A
SOT-223
Unit: mm
■Features
+0.2
+0.2
3.50-0.2
6.50-0.2
●Power Collector dissipation: PC=1W
● Continuous Collector Current: IC=-600mA
+0.2
0.90-0.2
+0.1
3.00-0.1
+0.3
7.00-0.3
4
1 Base
2 Collector
1
2
3
+0.1
3 Emitter
0.70-0.1
2.9
4.6
4 Collector
■Absolute Maximum Ratings Ta = 25℃
Parameter
Collector-base voltage
Symbol
VCBO
VCEO
VEBO
IC
Rating
Unit
V
-60
Collector-emitter voltage
-60
V
Emitter-base voltage
-5
-600
V
Continuous Collector Current
Peak collector current
mA
mA
W
ICM
-800
Power Collector dissipation
Operating and storage temperature range
PC
1
Tj,Tstg
-55 to +150
℃
■Electrical Characteristics Ta = 25℃
Parameter
Symbol
Test conditons
Min
-60
-60
-5
Typ Max
Unit
V
Collector-base breakdown voltage
Collector-emitter breakdown voltage *
Emitter-base breakdown voltage
Collector cutoff current
V(BR)CBO IC=-10μA
V(BR)CEO IC=-10mA
V(BR)EBO IE=-10μA
V
V
ICBO
IEBO
VCB=-50V, IE=0
VEB=-5V, IC=0
-10
-50
nA
nA
V
Emitter cut-off current
Collector-emitter saturation voltage *
Base-emitter saturation voltage *
Base-emitter voltage *
VCE(sat) IC=-500mA,IB=-50mA
VBE(sat) IC=-500mA,IB=-50mA
VBE(ON) IC=-1A,VCE=-5V
IC=-1mA, VCE=-5V*
-1.6
-2.6
-1.0
V
V
300
300
250
160
200
IC=-100mA,VCE=-5V
hFE
800
DC current gain
IC=-500mA, VCE=-5V*
IC=-1A, VCE=-5V*
Transition frequecy
Output capacitance
fT
IC=-50mA,VCE=-20V,f=100MHz
VCB=-10V,IE = 0,f=1MHz
MHz
pF
Cob
8
* Pulse test: tp ≤300 μs; d ≤0.02.
■ Marking
Marking
2907A
