PZT559A
PNP Silicon
Silicon Planar Medium Power Transistor
Elektronische Bauelemente
RoHS Compliant Product
A suffix of “-C” specifies halogen & lead-free
DESCRIPTION
SOT-223
The PZT559A is designed for general purpose switching
and amplifier applications.
FEATURES
ꢀ
ꢀ
ꢀ
4 Amps continuous current, up to 10 Amps peak current.
Excellent gain characteristic specified up to 3 Amps
Very low saturation voltages
MARKING
559A
ꢁꢁꢁꢁ
Date code
Millimeter
Millimeter
REF.
REF.
Min.
6.30
6.70
3.30
1.42
Max.
6.70
7.30
3.70
1.90
Min.
Max.
0.10
2.00
0.35
1.05
A
B
C
D
E
F
I
G
H
J
K
L
0.02
1.50
0.25
0.85
PACKAGE INFORMATION
Package
MPQ
Leader Size
4.60 REF.
2.30 REF.
0.60
0.02
0.80
0.10
M
N
2.90
3.10
SOT-223
2.5K
13’ inch
13 TYP.
O
0°
10°
Collector
2
4
1
Base
3
Emitter
ABSOLUTE MAXIMUM RATINGS (TA = 25°C unless otherwise noted)
Parameter
Collector to Base Voltage
Collector to Emitter Voltage
Emitter to Base Voltage
Collector Current (DC)
Symbol
VCBO
VCEO
VEBO
IC
Ratings
Unit
V
-180
-140
V
-7
V
A
-4
Collector Current (Pulse)
Total Power Dissipation 1
Total Power Dissipation 2
ICM
-10
A
3
1.6
W
W
℃
PD
Junction, Storage Temperature
TJ, TSTG
+150, -55~150
Notes：
1. Surface mounted on 52mm x 52mm x 1.6mm copper pad of FR4 board.
2. Surface mounted on 25mm x 25mm x 1.6mm copper pad of FR4 board.
