8XC251SQ

型号：

8XC251SQ

描述：

高性能CHMOS微控制器[ HIGH-PERFORMANCE CHMOS MICROCONTROLLER ]

品牌：

INTEL[ INTEL ]

页数：

36 页

PDF大小：

409 K

下载PDF手册
PRELIMINARY
8XC251SA/SB/SP/SQ
HIGH-PERFORMANCE
CHMOS MICROCONTROLLER
Commercial/Express
■ Real-time and Programmed Wait State
Bus Operation
■ User-selectable Configurations:
— External Wait States (0-3 wait states)
— Address Range & Memory Mapping
— Page Mode
®
■ Binary-code Compatible with MCS 51
■ Pin Compatible with 44-pin PLCC and 40-
pin PDIP MCS 51 Sockets
■ 32 Programmable I/O Lines
®
■ Register-based MCS 251 Architecture
■ Seven Maskable Interrupt Sources
with Four Programmable Priority
Levels
— 40-byte Register File
— Registers Accessible as Bytes, Words,
or Double Words
■ Three Flexible 16-bit Timer/counters
■ Hardware Watchdog Timer
■ Programmable Counter Array
— High-speed Output
■ Enriched MCS 51 Instruction Set
— 16-bit and 32-bit Arithmetic and Logic
Instructions
— Compare and Conditional Jump
Instructions
— Compare/Capture Operation
— Pulse Width Modulator
— Expanded Set of Move Instructions
— Watchdog Timer
■ Linear Addressing
■ Programmable Serial I/O Port
— Framing Error Detection
■ 256-Kbyte Expanded External Code/Data
Memory Space
■ ROM/OTPROM/EPROM Options:
16 Kbytes (SB/SQ), 8 Kbytes (SA/SP), or
without ROM/OTPROM/EPROM
— Automatic Address Recognition
■ High-performance CHMOS Technology
■ Static Standby to 16-MHz Operation
■ 16-bit Internal Code Fetch
■ Complete System Development
■ 64-Kbyte Extended Stack Space
Support
■ On-chip Data RAM Options:
— Compatible with Existing Tools
1-Kbyte (SA/SB) or 512-Byte (SP/SQ)
— New MCS 251 Tools Available:
■ 8-bit, 2-clock External Code Fetch in
Compiler, Assembler, Debugger, ICE
Page Mode
■ Fast MCS 251 Instruction Pipeline
■ Package Options (PDIP, PLCC, and
Ceramic DIP)
A member of the Intel family of 8-bit MCS 251 microcontrollers, the 8XC251SA/SB/SP/SQ is binary-code
compatible with MCS 51 microcontrollers and pin compatible with 40-pin PDIP and 44-pin PLCC MCS 51
microcontrollers. MCS 251 microcontrollers feature an enriched instruction set, linear addressing, and
efficient C-language support. The 8XC251SA/SB/SP/SQ has 512 bytes or 1 Kbyte of on-chip RAM and is
available with 8 Kbytes or 16 Kbytes of on-chip ROM/OTPROM/EPROM, or without ROM/OTPROM/EPROM.
A variety of features can be selected by new user-programmable configurations.
COPYRIGHT © INTEL CORPORATION, 1996
May 1996
Order Number: 272783-003
Information in this document is provided in connection with Intel products. No license, express or implied, by
estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in
Intel’s Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel
disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or
warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright
or other intellectual property right. Intel products are not intended for use in medical, life saving, or life
sustaining applications.
Intel retains the right to make changes to specifications and product descriptions at any time, without notice.
*Third-party brands and names are the property of their respective owners.
Copies of documents which have an ordering number and are referenced in this document, or other Intel
literature, may be obtained from:
Intel Corporation
P.O. Box 7641
Mt. Prospect IL 60056-764
or call 1-800-548-4725
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
I/O Ports and
Peripheral Signals
System Bus and I/O Ports
P0.7:0
P1.7:0
P2.7:0
P3.7:0
Code
OTPROM/ROM
8 Kbytes
or
Data RAM
512 Bytes
or
Port 0
Drivers
Port 2
Drivers
Port 1
Drivers
Port 3
Drivers
1024 Bytes
16 Kbytes
Memory Data (16)
Watchdog
Timer
Memory Address (16)
Peripheral
Interface
Bus Interface
Timer/
Counters
Code Bus (16)
Code Address (24)
Interrupt
Handler
Instruction Sequencer
PCA
SRC1 (8)
SRC2 (8)
Serial I/O
Clock
&
Reset
Data
Register
File
Memory
Interface
ALU
Peripherals
DST (16)
®
MCS 251 Microcontroller Core
Clock & Reset
8XC251SA/SB/SP/SQ Microcontroller
A4214-01
Figure 1. 8XC251SA/SB/SP/SQ Block Diagram
PRELIMINARY
3
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
1.0 NOMENCLATURE
X
XX
8
X
X
XXXXX XX
A2815-01
Figure 2. The 8XC251SA/SB/SP/SQ Family Nomenclature
Table 1. Description of Product Nomenclature
Parameter
Options
Description
Temperature and Burn-in
Options
no mark
Commercial operating temperature range (0°C to 70°C) with
Intel standard burn-in.
T
Express operating temperature range (-40°C to 85°C) with
Intel standard burn-in.
Packaging Options
N
P
44-pin Plastic Leaded Chip Carrier (PLCC)
40-pin Plastic Dual In-line Package (PDIP)
40-pin Ceramic Dual In-line Package (Ceramic DIP)
Without ROM/OTPROM/EPROM
ROM
C
Program Memory Options
0
3
7
User programmable OTPROM/EPROM
CHMOS
Process Information
Product Family
C
251
SA
SB
8-bit control architecture
Device Memory Options
1-Kbyte RAM/8-Kbyte ROM/OTPROM/EPROM
1-Kbyte RAM/16-Kbyte ROM/OTPROM/EPROM or without
ROM/OTPROM/EPROM
SP
SQ
512-byte RAM/8-Kbyte ROM/OTPROM/EPROM
512-byte RAM/16-Kbyte ROM/OTPROM/EPROM or without
ROM/OTPROM/EPROM
Device Speed
16
External clock frequency
4
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
Table 2 lists the proliferation options. See Figure 2 for the 8XC251SA/SB/SP/SQ family nomenclature.
.
Table 2. Proliferation Options
8XC251SA/SB/SP/SQ
(0 – 16 MHz; 5 V ±10%)
80C251SB16
80C251SQ16
83C251SA16
83C251SB16
83C251SP16
83C251SQ16
87C251SA16
87C251SB16
87C251SP16
87C251SQ16
CPU-only
CPU-only
ROM
ROM
ROM
ROM
OTPROM/EPROM
OTPROM/EPROM
OTPROM/EPROM
OTPROM/EPROM
Table 3 lists the 8XC251SA/SB/SP/SQ packages.
Table 3. Package Information
Definition Temperature
44 ld. PLCC
Pkg.
N
0°C to +70°C
0°C to +70°C
0°C to +70°C
-40°C to +85°C
-40°C to +85°C
P
40 ld. Plastic DIP
40 ld. Ceramic DIP
44 ld. PLCC
C
TN
TP
40 ld. Plastic DIP
PRELIMINARY
5
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
2.0 PINOUT
P1.5 / CEX2
P1.6 / CEX3 / WAIT#
P1.7 / CEX4 / A17 / WCLK
RST
7
8
9
39
38
37
36
35
34
33
32
31
30
29
AD4 / P0.4
AD5 / P0.5
AD6 / P0.6
AD7 / P0.7
8XC251SA
8XC251SB
8XC251SP
8XC251SQ
10
11
12
13
14
15
16
17
P3.0 / RXD
EA# / V
PP
V
V
CC2
SS2
P3.1 / TXD
P3.2 / INT0#
P3.3 / INT1#
P3.4 / T0
ALE / PROG#
PSEN#
A15 / P2.7
A14 / P2.6
A13 / P2.5
View of component as
mounted on PC board
P3.5 / T1
A4205-02
Figure 3. 8XC251SA/SB/SP/SQ 44-pin PLCC Package
6
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
V
P1.0 / T2
P1.1 / T2EX
P1.2 / ECI
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
1
CC
AD0 / P0.0
AD1 / P0.1
AD2 / P0.2
AD3 / P0.3
AD4 / P0.4
AD5 / P0.5
AD6 / P0.6
AD7 / P0.7
2
3
P1.3 / CEX0
P1.4 / CEX1
P1.5 / CEX2
P1.6 / CEX3 / WAIT#
P1.7 / CEX4 / A17 / WCLK
RST
4
5
8XC251SA
8XC251SB
8XC251SP
8XC251SQ
6
7
8
9
V
EA# /
P3.0 / RXD
10
11
12
13
14
15
16
17
18
19
20
PP
P3.1 / TXD
ALE / PROG#
PSEN#
P3.2 / INT0#
P3.3 / INT1#
P3.4 / T0
A15 / P2.7
A14 / P2.6
A13 / P2.5
A12 / P2.4
A11 / P2.3
A10 / P2.2
A9 / P2.1
View of
component
as mounted
on PC board
P3.5 / T1
P3.6 / WR#
P3.7 / RD# / A16
XTAL2
XTAL1
V
A8 / P2.0
SS
A4206-03
Figure 4. 8XC251SA/SB/SP/SQ 40-pin PDIP and Ceramic DIP Packages
PRELIMINARY
7
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
Table 4. 8XC251SA/SB/SP/SQ Pin Assignment
PLCC
1
DIP
Name
PLCC
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
DIP
Name
VSS1
VSS2
2
1
2
P1.0/T2
21
22
23
24
25
26
27
28
29
30
A8/P2.0
A9/P2.1
3
P1.1/T2EX
P1.2/ECI
4
3
A10/P2.2
A11/P2.3
A12/P2.4
A13/P2.5
A14/P2.6
A15/P2.7
PSEN#
5
4
P1.3/CEX0
P1.4/CEX1
P1.5/CEX2
P1.6/CEX3/WAIT#
P1.7/CEX4/A17/WCLK
RST
6
5
7
6
8
7
9
8
10
11
12
13
14
15
16
17
18
19
20
21
22
9
10
P3.0/RXD
VCC2
ALE/PROG#
VSS2
11
12
13
14
15
16
17
18
19
20
P3.1/TXD
P3.2/INT0#
P3.3/INT1#
P3.4/T0
31
32
33
34
35
36
37
38
39
40
EA#/VPP
AD7/P0.7
AD6/P0.6
AD5/P0.5
AD4/P0.4
AD3/P0.3
AD2/P0.2
AD1/P0.1
AD0/P0.0
VCC
P3.5/T1
P3.6/WR#
P3.7/RD#/A16
XTAL2
XTAL1
VSS
8
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
Table 5. 8XC251SA/SB/SP/SQ PLCC/DIP Pin Assignments Arranged by Functional Category
Address & Data
Name PLCC
AD0/P0.0
Input/Output
Name PLCC
DIP
39
38
37
36
35
34
33
32
21
22
23
24
25
26
27
28
17
8
DIP
1
43
42
41
40
39
38
37
36
24
25
26
27
28
29
30
31
19
9
P1.0/T2
2
3
AD1/P0.1
AD2/P0.2
AD3/P0.3
AD4/P0.4
AD5/P0.5
AD6/P0.6
AD7/P0.7
A8/P2.0
P1.1/T2EX
P1.2/ECI
2
4
3
P1.3/CEX0
P1.4/CEX1
P1.5/CEX2
P1.6/CEX3/WAIT#
P1.7/CEX4/A17/WCLK
P3.0/RXD
5
4
6
5
7
6
8
7
9
8
11
13
16
17
10
11
14
15
A9/P2.1
P3.1/TXD
A10/P2.2
P3.4/T0
A11/P2.3
P3.5/T1
A12/P2.4
A13/P2.5
Power & Ground
Name PLCC
A14/P2.6
DIP
A15/P2.7
VCC
44
12
40
P3.7/RD#/A16
P1.7/CEX4/A17/WCLK
VCC2
VSS
22
20
31
VSS1
1
VSS2
23, 34
35
Processor Control
Name PLCC
EA#/VPP
DIP
12
13
31
9
P3.2/INT0#
P3.3/INT1#
EA#/VPP
RST
14
15
35
10
21
20
Bus Control & Status
Name
PLCC
18
DIP
P3.6/WR#
P3.7/RD#/A16
ALE/PROG#
PSEN#
16
19
17
30
29
XTAL1
18
19
33
XTAL2
32
PRELIMINARY
9
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
3.0 SIGNALS
Table 6. Signal Descriptions
Signal
Alternate
Function
Type
Description
Name
A17
O
18th Address Bit (A17). Output to memory as 18th external address
P1.7/CEX4/
bit (A17) in extended bus applications, depending on the values of bits WCLK
RD0 and RD1 in configuration byte UCONFIG0 (see Chapter 4,
“Device Configuration,” of the 8XC251SA/SB/SP/SQ Embedded
Microcontroller User’s Manual). See also RD# and PSEN#.
A16
O
O
Address Line 16. See RD#.
RD#
A15:8†
AD7:0†
Address Lines. Upper address lines for the external bus.
P2.7:0
P0.7:0
I/O
Address/Data Lines. Multiplexed lower address lines and data lines
for external memory.
ALE
O
Address Latch Enable. ALE signals the start of an external bus cycle PROG#
and indicates that valid address information is available on lines A15:8
and AD7:0. An external latch can use ALE to demultiplex the address
from the address/data bus.
CEX4:0
EA#
I/O
I
Programmable Counter Array (PCA) Input/Output Pins. These are P1.6:3
input signals for the PCA capture mode and output signals for the PCA P1.7/A17/
compare mode and PCA PWM mode.
WAIT#
External Access. Directs program memory accesses to on-chip or off- VPP
chip code memory. For EA# = 0, all program memory accesses are off-
chip. For EA# = 1, an access is to on-chip ROM/OTPROM/EPROM if
the address is within the range of the on-chip
ROM/OTPROM/EPROM; otherwise the access is off-chip. The value
of EA# is latched at reset. For devices without on-chip
ROM/OTPROM/EPROM, EA# must be strapped to ground.
ECI
I
I
PCA External Clock Input. External clock input to the 16-bit PCA
P1.2
timer.
INT1:0#
External Interrupts 0 and 1. These inputs set bits IE1:0 in the TCON P3.3:2
register. If bits IT1:0 in the TCON register are set, bits IE1:0 are set by
a falling edge on INT1#/INT0#. If bits INT1:0 are clear, bits IE1:0 are
set by a low level on INT1:0#.
PROG#
P0.7:0
I
Programming Pulse. The programming pulse is applied to this pin for ALE
programming the on-chip OTPROM.
I/O
I/O
Port 0. This is an 8-bit, open-drain, bidirectional I/O port.
AD7:0
P1.0
Port 1. This is an 8-bit, bidirectional I/O port with internal pullups.
T2
P1.1
T2EX
P1.2
ECI
P1.7:3
CEX3:0
CEX4/A17/
WAIT#/
WCLK
P2.7:0
I/O
Port 2. This is an 8-bit, bidirectional I/O port with internal pullups.
A15:8
†
The descriptions of A15:8/P2.7:0 and AD7:0/P0.7:0 are for the nonpage-mode chip configuration (com-
patible with 44-pin PLCC and 40-pin DIP MCS 51 microcontrollers). If the chip is configured for page-
mode operation, port 0 carries the lower address bits (A7:0), and port 2 carries the upper address bits
(A15:8) and the data (D7:0).
10
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
Table 6. Signal Descriptions (Continued)
Alternate
Signal
Name
Type
Description
Function
P3.0
P3.1
I/O
Port 3. This is an 8-bit, bidirectional I/O port with internal pullups.
RXD
TXD
P3.3:2
P3.5:4
P3.6
INT1:0#
T1:0
WR#
P3.7
RD#/A16
PSEN#
O
O
I
Program Store Enable. Read signal output. This output is asserted
for a memory address range that depends on bits RD0 and RD1 in
configuration byte UCONFIG0 (see RD# and Chapter 4, “Device Con-
figuration,” in the 8XC251SA/SB/SP/SQ Embedded Microcontroller
User’s Manual).
—
RD#
Read or 17th Address Bit (A16). Read signal output to external data P3.7/A16
memory or 17th external address bit (A16), depending on the values of
bits RD0 and RD1 in configuration byte UCONFIG0. (See PSEN# and
Chapter 4, “Device Configuration,” in the 8XC251SA/SB/SP/SQ
Embedded Microcontroller User’s Manual).
RST
Reset. Reset input to the chip. Holding this pin high for 64 oscillator
periods while the oscillator is running resets the device. The port pins
are driven to their reset conditions when a voltage greater than VIH1 is
applied, whether or not the oscillator is running. This pin has an inter-
nal pulldown resistor, which allows the device to be reset by connect-
—
ing a capacitor between this pin and VCC
.
Asserting RST when the chip is in idle mode or powerdown mode
returns the chip to normal operation.
RXD
T1:0
T2
I/O
I
Receive Serial Data. RXD sends and receives data in serial I/O mode P3.0
0 and receives data in serial I/O modes 1, 2, and 3.
Timer 1:0 External Clock Inputs. When timer 1:0 operates as a
counter, a falling edge on the T1:0 pin increments the count.
P3.5:4
I/O
Timer 2 Clock Input/Output. For the timer 2 capture mode, this signal P1.0
is the external clock input. For the clock-out mode, it is the timer 2
clock output.
T2EX
TXD
I
Timer 2 External Input. In timer 2 capture mode, a falling edge ini-
tiates a capture of the timer 2 registers. In auto-reload mode, a falling
edge causes the timer 2 registers to be reloaded. In the up-down
counter mode, this signal determines the count direction: 1 = up, 0 =
down.
P1.1
O
Transmit Serial Data. TXD outputs the shift clock in serial I/O mode 0 P3.1
and transmits serial data in serial I/O modes 1, 2, and 3.
VCC
PWR Supply Voltage. Connect this pin to the +5V supply voltage.
—
—
VCC2
PWR Secondary Supply Voltage 2. This supply voltage connection is pro-
vided to reduce power supply noise. Connection of this pin to the +5V
supply voltage is recommended. However, when using the 8XC251SB
as a pin-for-pin replacement for the 8XC51FX, VSS2 can be uncon-
nected without loss of compatibility. (Not available on DIP)
†
The descriptions of A15:8/P2.7:0 and AD7:0/P0.7:0 are for the nonpage-mode chip configuration (com-
patible with 44-pin PLCC and 40-pin DIP MCS 51 microcontrollers). If the chip is configured for page-
mode operation, port 0 carries the lower address bits (A7:0), and port 2 carries the upper address bits
(A15:8) and the data (D7:0).
PRELIMINARY
11
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
Table 6. Signal Descriptions (Continued)
Signal
Alternate
Function
Type
Description
Name
VPP
I
Programming Supply Voltage. The programming supply voltage is
applied to this pin for programming the on-chip OTPROM/EPROM.
EA#
VSS
GND Circuit Ground. Connect this pin to ground.
—
—
VSS1
GND Secondary Ground. This ground is provided to reduce ground bounce
and improve power supply bypassing. Connection of this pin to ground
is recommended. However, when using the 8XC251SA/SB/SP/SQ as
a pin-for-pin replacement for the 8XC51BH, VSS1 can be unconnected
without loss of compatibility. (Not available on DIP)
VSS2
GND Secondary Ground 2. This ground is provided to reduce ground
bounce and improve power supply bypassing. Connection of this pin to
ground is recommended. However, when using the 8XC251SB as a
pin-for-pin replacement for the 8XC51FX, VSS2 can be unconnected
without loss of compatibility. (Not available on DIP)
—
WAIT#
I
Real-time Wait State Input. The real-time WAIT# input is enabled by P1.6/CEX3
writing a logical ‘1’ to the WCON.0 (RTWE) bit at S:A7H. During bus
cycles, the external memory system can signal ‘system ready’ to the
microcontroller in real time by controlling the WAIT# input signal on the
port 1.6 input.
WCLK
O
Wait Clock Output. The real-time WCLK output is driven at port 1.7
(WCLK) by writing a logical ‘1’ to the WCON.1 (RTWCE) bit at S:A7H.
When enabled, the WCLK output produces a square wave signal with
a period of one-half the oscillator frequency.
P1.7/CEX4/
A17
WR#
O
I
Write. Write signal output to external memory.
P3.6
—
XTAL1
Input to the On-chip, Inverting, Oscillator Amplifier. To use the
internal oscillator, a crystal/resonator circuit is connected to this pin. If
an external oscillator is used, its output is connected to this pin. XTAL1
is the clock source for internal timing.
XTAL2
O
Output of the On-chip, Inverting, Oscillator Amplifier. To use the
internal oscillator, a crystal/resonator circuit is connected to this pin. If
an external oscillator is used, leave XTAL2 unconnected.
—
†
The descriptions of A15:8/P2.7:0 and AD7:0/P0.7:0 are for the nonpage-mode chip configuration (com-
patible with 44-pin PLCC and 40-pin DIP MCS 51 microcontrollers). If the chip is configured for page-
mode operation, port 0 carries the lower address bits (A7:0), and port 2 carries the upper address bits
(A15:8) and the data (D7:0).
12
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
Table 7. Memory Signal Selections (RD1:0)
P1.7/CEX/
A17/WCLK
RD1:0
P3.7/RD#/A16
PSEN#
WR#
Features
0
0
1
0
1
0
A17
A16
Asserted for
all addresses all memory locations
Asserted for writes to 256-Kbyte external
memory
P1.7/CEX4/
WCLK
A16
Asserted for Asserted for writes to 128-Kbyte external
all addresses all memory locations memory
P1.7/CEX4/
WCLK
P3.7 only
Asserted for Asserted for writes to 64-Kbyte external
all addresses all memory locations
memory. One
additional port pin.
1
1
P1.7/CEX4/
WCLK
RD# asserted
for addresses
≤ 7F:FFFFH
Asserted for
≥ 80:0000H
Asserted only for
writes to MCS 51
microcontroller data
memory locations.
64-Kbyte external
memory. Compatible
with MCS 51 micro-
controllers.
PRELIMINARY
13
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
4.0 ADDRESS MAP
Table 8. 8XC251SA/SB/SP/SQ Address Map
Internal
Description
Address)
Notes
1, 3, 10
3, 4, 5
3
FF:FFFFH
FF:4000H
External Memory except the top eight bytes (FF:FFF8H–FF:FFFFH) which are
reserved for the configuration array.
FF:3FFFH
FF:0000H
External memory or on-chip nonvolatile memory (8Kbytes FF:0000H - FF:1FFFH,
16Kbytes FF:0000H - FF:3FFFH).
FE:FFFFH
FE:0000H
External Memory
FD:FFFFH
02:0000H
Reserved
6
01:FFFFH
01:0000H
External Memory
3
00:FFFFH
00:E000H
External memory or with configuration bit EMAP# = 0, addresses in this range
access on-chip code memory in region FF: (16 Kbyte devices only).
5, 7
7
00:DFFFH
00:0420H
External Memory
00:041FH
00:0080H
On-chip RAM (512 bytes 00:0020H - 00:021FH, 1024 bytes 00:0020H -
00:041FH)
7
00:007FH
00:0020H
On-chip RAM
8
00:001FH
00:0000H
Storage for R0–R7 of Register File
2, 9
NOTES:
1. 18 address lines are bonded out (A15:0, A16:0, or A17:0 selected during chip configuration).
2. The special function registers (SFRs) and the register file have separate internal address spaces.
3. Data in this area is accessible by indirect addressing only.
4. Devices reset into internal or external starting locations depending on the state of EA# and configura-
tion byte information See EA#. See also UCONFIG1:0 bit definitions in the 8XC251SA/SB/SP/SQ
Embedded Microcontroller User’s Manual.
5. The 16-Kbyte ROM/OTPROM/EPROM devices allow internal locations FF:2000H–FF:3FFFH to map
into region 00:. In this case, if EA# = 1, a data read to 00:E000H–00:FFFFH is redirected to internal
ROM/OTPROM/EPROM (see bit 1 in UCONFIG0). This is not available for 8-Kbyte
ROM/OTPROM/EPROM devices.
6. This reserved area returns indeterminate values.
7. Data is accessible by direct and indirect addressing.
8. Data is accessible by direct, indirect, and bit addressing.
9. Data is accessible by direct, indirect, and register addressing.
10. Eight addresses at the top of all external memory maps are reserved for current and future device
configuration byte information.
14
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
5.0 ELECTRICAL CHARACTERISTICS
ABSOLUTE MAXIMUM RATINGS
NOTICE: This document contains preliminary
information on new products in production. The
specifications are subject to change without notice.
Verify with your local Intel sales office that you
have the latest datasheet before finalizing a
design.
Storage Temperature ................................... -65°C to +150°C
Voltage on EA#/VPP Pin to VSS ......................... 0 V to +13.0 V
Voltage on Any other Pin to VSS ..................... -0.5 V to +6.5 V
IOL per I/O Pin................................................................. 15 mA
Power Dissipation .......................................................... 1.5 W
† WARNING: Stressing the device beyond the
“Absolute Maximum Ratings” may cause perma-
nent damage. These are stress ratings only. Oper-
ation beyond the “Operating Conditions” is not
recommended and extended exposure beyond the
“Operating Conditions” may affect device
reliability.
OPERATING CONDITIONS†
TA (Ambient Temperature Under Bias):
Commercial ................................................. 0°C to +70°C
Express .................................................... -40°C to +85°C
V
CC (Digital Supply Voltage) .............................. 4.5 V to 5.5 V
VSS ..................................................................................... 0 V
NOTE
Maximum power dissipation is
based on package heat-transfer
limitations, not device power
consumption.
PRELIMINARY
15
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
5.1 D.C. Characteristics
Parameter values apply to all devices unless otherwise indicated.
Table 9. DC Characteristics at VCC = 4.5 – 5.5 V
Symbol
Parameter
Min
Typical
Max
Units
Test Conditions
VIL
Input Low Voltage
(except EA#)
-0.5
0.2VCC – 0.1
V
VIL1
VIH
Input Low Voltage
(EA#)
0
0.2VCC – 0.3
VCC + 0.5
V
V
V
V
Input High Voltage
(except XTAL1, RST)
0.2VCC + 0.9
0.7VCC
VIH1
VOL
Input High Voltage
(XTAL1, RST)
VCC + 0.5
Output Low Voltage
(Port 1, 2, 3)
0.3
0.45
1.0
IOL = 100 µA
IOL = 1.6 mA
IOL = 3.5 mA
(Note 1, Note 2)
VOL1
Output Low Voltage
(Port 0, ALE, PSEN#)
0.3
0.45
1.0
V
V
IOL = 200 µA
IOL = 3.2 mA
IOL = 7.0 mA
(Note 1, Note 2)
VOH
Output High Voltage
(Port 1, 2, 3, ALE,
PSEN#)
VCC – 0.3
VCC – 0.7
VCC – 1.5
IOH = -10 µA
IOH = -30 µA
IOH = -60 µA
(Note 3)
NOTES:
1. Under steady-state (non-transient) conditions, IOL must be externally limited as follows:
Maximum IOL per port pin: 10 mA
Maximum IOL per 8-bit port:
port 0
ports 1–3
26 mA
15 mA
Maximum Total IOL for
all output pins
71 mA
If IOL exceeds the test conditions, VOL may exceed the related specification. Pins are not guaranteed
to sink current greater than the listed test conditions.
2. Capacitive loading on ports 0 and 2 may cause spurious noise pulses above 0.4 V on the low-level
outputs of ALE and ports 1, 2, and 3. The noise is due to external bus capacitance discharging into
the port 0 and port 2 pins when these pins change from high to low. In applications where capacitive
loading exceeds 100 pF, the noise pulses on these signals may exceed 0.8 V. It may be desirable to
qualify ALE or other signals with a Schmitt trigger or CMOS-level input logic.
3. Capacitive loading on ports 0 and 2 causes the VOH on ALE and PSEN# to drop below the specifica-
tion when the address lines are stabilizing.
4. Typical values are obtained using VCC = 5.0, TA = 25°C and are not guaranteed.
16
PRELIMINARY

8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
Table 9. DC Characteristics at VCC = 4.5 – 5.5 V (Continued)
Symbol
Parameter
Min
Typical
Max
Units
Test Conditions
VOH1
Output High Voltage
(Port 0 in External
Address)
V
CC – 0.3
V
I
OH = -200 µA
IOH = -3.2 mA
IOH = -7.0 mA
VCC – 0.7
VCC – 1.5
VOH2
Output High Voltage
(Port 2 in External
Address during Page
Mode)
V
CC – 0.3
V
IOH = -200 µA
IOH = -3.2 mA
IOH = -7.0 mA
VCC – 0.7
VCC – 1.5
IIL
ILI
ITL
Logical 0 Input Cur-
rent (Port 1, 2, 3)
-50
+/-10
-650
µA
µA
µA
VIN = 0.45 V
0.45 < VIN < VCC
VIN = 2.0 V
Input Leakage Cur-
rent (Port 0)
Logical 1-to-0 Transi-
tion Current (Port 1,
2, 3)
RRST
CIO
RST Pulldown Resis-
tor
40
225
kΩ
Pin Capacitance
10
pF
FOSC = 16 MHz
TA = 25 °C
(Note 4)
IPD
Powerdown Current
Idle Mode Current
Operating Current
10
20
15
80
µA
mA
mA
(Note 4)
IDL
12
FOSC = 16 MHz
FOSC = 16 MHz
(Note 4)
ICC
45
(Note 4)
NOTES:
1. Under steady-state (non-transient) conditions, IOL must be externally limited as follows:
Maximum IOL per port pin: 10 mA
Maximum IOL per 8-bit port:
port 0
ports 1–3
26 mA
15 mA
Maximum Total IOL for
all output pins
71 mA
If IOL exceeds the test conditions, VOL may exceed the related specification. Pins are not guaranteed
to sink current greater than the listed test conditions.
2. Capacitive loading on ports 0 and 2 may cause spurious noise pulses above 0.4 V on the low-level
outputs of ALE and ports 1, 2, and 3. The noise is due to external bus capacitance discharging into
the port 0 and port 2 pins when these pins change from high to low. In applications where capacitive
loading exceeds 100 pF, the noise pulses on these signals may exceed 0.8 V. It may be desirable to
qualify ALE or other signals with a Schmitt trigger or CMOS-level input logic.
3. Capacitive loading on ports 0 and 2 causes the VOH on ALE and PSEN# to drop below the specifica-
tion when the address lines are stabilizing.
4. Typical values are obtained using VCC = 5.0, TA = 25°C and are not guaranteed.
PRELIMINARY
17
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
VCC
IPD
VCC
P0
VCC
EA#
RST
8XC251SA
8XC251SB
8XC251SP
8XC251SQ
(NC)
XTAL2
XTAL1
VSS
All other 8XC251SA/SB/SP/SQ pins are unconnected.
A4208-01
Figure 5. IPD Test Condition, Powerdown Mode, VCC = 2.0 – 5.5V
70
60
50
40
30
20
10
0
1
2
3
4
5
6
7
8
9
10 11 12 13 14 15 16
Frequency at XTAL (MHz)
A4400-01
Figure 6. ICC vs. Frequency (Mhz)
18
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
5.2 Definition of AC Symbols
Table 10. AC Timing Symbol Definitions
Signals
Conditions
A
D
L
Address
Data In
ALE
H
L
High
Low
V
X
Z
Valid
Q
R
W
Data Out
RD#/PSEN#
WR#
No Longer Valid
Floating
5.3 A.C. Characteristics
Test Conditions: Capacitive load on all pins = 50 pF.
Table 11 lists AC timing parameters for the
8XC251SA/SB/SP/SQ with no wait states. External
wait states can be added by extending
PSEN#/RD#/WR# and/or by extending ALE. In the
table, Notes 3 and 5 mark parameters affected by an
ALE wait state, and Notes 4 and 5 mark parameters
affected by a PSEN#/RD#/WR# wait state.
Figures 8–10 show the bus cycles with the timing
parameters.
Table 11. AC Characteristics
@ Max Fosc (1)
Min Max
N/A N/A
N/A
Fosc Variable
Min Max
16
Symbol
Parameter
Units
FOSC
TOSC
XTAL1 Frequency
1/FOSC
0
MHz
ns
N/A
83.3
62.5
@ 12 MHz
@ 16 MHz
TLHLL
ALE Pulse Width
@ 12 MHz
ns
73.3
52.5
(1+2M)
TOSC – 10
(3)
@ 16 MHz
TAVLL
Address Valid to ALE Low
@ 12 MHz
ns
58.3
37.5
(1+2M)
(3)
T
OSC – 25
@ 16 MHz
TLLAX
Address Hold after ALE Low
@ 12 MHz
ns
15
15
15
@ 16 MHz
NOTES:
1. 16 MHz.
2. Specifications for PSEN# are identical to those for RD#.
3. In the formula, M=Number of wait states (0 or 1) for ALE.
4. In the formula, N=Number of wait states (0,1,2, or 3) for RD#/PSEN#/WR#.
5. “Typical” specifications are untested and not guaranteed.
PRELIMINARY
19



8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
Table 11. AC Characteristics (Continued)
@ Max Fosc (1)
Fosc Variable
Symbol
Parameter
Units
Min
Max
Min
Max
TRLRH (2) RD# or PSEN# Pulse Width
ns
146.6
105
2(1+N)
@ 12 MHz
@ 16 MHz
(4)
T
OSC – 20
TWLWH
WR# Pulse Width
@ 12 MHz
ns
146.6
105
2(1+N)
TOSC – 20
(4)
@ 16 MHz
TLLRL (2) ALE Low to RD# or PSEN# Low
ns
58.3
37.5
@ 12 MHz
@ 16 MHz
TOSC – 25
TLHAX
ALE High to Address Hold
@ 12 MHz
ns
83.3
62.5
(1+2M)TOSC
(3)
@ 16 MHz
T
RLDV (2) RD#/PSEN# Low to valid Data/Instruction In
ns
(4)
106.6
65
2(1+N)
Tosc – 60
@ 12 MHz
@ 16 MHz
TRHDX (2) Data/Instruction Hold Time. Occurs after
RD#/PSEN# are exerted to VOH
0
0
ns
ns
TRLAZ (2) RD#/PSEN# Low to Address Float
Typ.=0
(5)
2
Typ. = 0
(5)
2
TRHDZ1
Instruction Float after RD#/PSEN# High
commercial @ 12 MHz and 16 MHz
express @ 12 MHz and 16 MHz
ns
Typ.=2 18
Typ.=25
Typ.=25
(5)
18
10
5
Typ.=2
5
10
(5)
TRHDZ2
TRHLH1
TRHLH2
Data Float after RD#/PSEN# High
@ 12 MHz
ns
ns
ns
156.6
115
2Tosc – 10
@ 16 MHz
RD#/PSEN# High to ALE High (Instruction)
10
10
@ 12 MHz
@ 16 MHz
10
RD#/PSEN# High to ALE High (Data)
@ 12 MHz
156.6
115
2Tosc - 10
@ 16 MHz
TWHLH
WR# High to ALE High
@ 12 MHz
ns
171.6
130
2Tosc + 5
@ 16 MHz
NOTES:
1. 16 MHz.
2. Specifications for PSEN# are identical to those for RD#.
3. In the formula, M=Number of wait states (0 or 1) for ALE.
4. In the formula, N=Number of wait states (0,1,2, or 3) for RD#/PSEN#/WR#.
5. “Typical” specifications are untested and not guaranteed.
20
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
Table 11. AC Characteristics (Continued)
@ Max Fosc (1)
Fosc Variable
Symbol
Parameter
Units
Min
Max
Min
Max
TAVDV1
Address (P0) Valid to Valid Data/Instruction In
ns
243.2
160
4(1+M/2)
OSC – 90
@ 12 MHz
@ 16 MHz
(3)
T
TAVDV2
Address (P2) Valid to Valid Data/Instruction In
ns
268.2
185
4(1+M/2)
TOSC – 65
@ 12 MHz
@ 16 MHz
(3)
TAVDV3
Address (P0) Valid to Valid Instruction In
ns
116.6
75
2TOSC – 50
@ 12 MHz
@ 16 MHz
T
AVRL (2) Address Valid to RD#/PSEN# Low
ns
121.6
80
2(1+M)
@ 12 MHz
@ 16 MHz
(3)
T
OSC – 45
TAVWL1
TAVWL2
TWHQX
TQVWH
TWHAX
NOTES:
Address (P0) Valid to WR# Low
@ 12 MHz
ns
126.6
85
2(1+M)
(3)
TOSC – 40
@ 16 MHz
Address (P2) Valid to WR# Low
@ 12 MHz
ns
(3)
146.6
105
2(1+M)
TOSC – 20
@ 16 MHz
Data Hold after WR# High
@ 12 MHz
ns
63.3
42.5
TOSC – 20
@ 16 MHz
Data Valid to WR# High
@ 12 MHz
ns
138.6
97
2(1+N)
TOSC – 28
(4)
@ 16 MHz
WR# High to Address Hold
@ 12 MHz
ns
156.6
115
2TOSC – 10
@ 16 MHz
1. 16 MHz.
2. Specifications for PSEN# are identical to those for RD#.
3. In the formula, M=Number of wait states (0 or 1) for ALE.
4. In the formula, N=Number of wait states (0,1,2, or 3) for RD#/PSEN#/WR#.
5. “Typical” specifications are untested and not guaranteed.
PRELIMINARY
21
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
5.3.1 EXTERNAL BUS CYCLES, NONPAGE MODE
T
OSC
XTAL1
ALE
†
T
LHLL
†
T
RLRH
T
RHLH1
†
T
LLRL
RD#/PSEN#
†
T
RLDV
T
RLAZ
†
T
LHAX
T
RHDZ1
†
T
T
LLAX
AVLL
T
RHDX
P0
A7:0
D7:0
†
Instruction In
T
AVRL
†
T
T
AVDV1
†
AVDV2
P2/A16/A17
A15:8/A16/A17
†
The value of this parameter depends on wait states. See the table of AC characteristics.
A4211-03
Figure 7. External Bus Cycle: Code Fetch (Nonpage Mode)
22
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
T
OSC
XTAL1
ALE
†
T
LHLL
†
T
RLRH
†
T
T
RHLH2
LLRL
RD#/PSEN#
†
T
RLDV
T
RLAZ
†
T
LHAX
T
RHDZ2
†
T
AVLL
T
LLAX
T
RHDX
D7:0
P0
A7:0
†
Data In
T
AVRL
†
T
AVDV1
†
T
AVDV2
A15:8/A16/A17
P2/A16/A17
†
The value of this parameter depends on wait states. See the table of AC characteristics.
A4210-03
Figure 8. External Bus Cycle: Data Read (Nonpage Mode)
PRELIMINARY
23
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
T
OSC
XTAL1
†
ALE
T
LHLL
†
T
WLWH
T
WHLH
WR#
†
T
LHAX
†
T
QVWH
T
T
AVLL
LLAX
T
WHQX
P0
A7:0
D7:0
†
Data Out
T
AVWL1
†
T
T
AVWL2
WHAX
P2/A16/A17
A15:8/A16/A17
†
The value of this parameter depends on wait states. See the table of AC characteristics.
A4179-01
Figure 9. External Bus Cycle: Data Write (Nonpage Mode)
24
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
5.3.2 EXTERNAL BUS CYCLES, PAGE MODE
T
OSC
XTAL1
ALE
†
T
LHLL
†
T
LLRL
†††
RD#/PSEN#
†
T
RLDV
T
RLAZ
†
T
T
RHDZ1
T
LHAX
†
T
AVLL
T
RHDX
LLAX
P2
A15:8
D7:0
D7:0
†
Instruction In
Instruction In
T
AVRL
†
T
T
AVDV3
AVDV1
†
T
AVDV2
P0/A16/A17
A7:0/A16/A17
A7:0/A16/A17
††
††
Page Miss
Page Hit
†
The value of this parameter depends on wait states. See the table of AC characteristics.
A page hit (i.e., a code fetch to the same 256-byte "page" as the previous code fetch) requires one
state (2TOSC); a page miss requires two states (4TOSC).
††
†††
During a sequence of page hits, PSEN# remains low until the end of the last page-hit cycle.
A4213-02
Figure 10. External Bus Cycle: Code Fetch (Page Mode)
PRELIMINARY
25
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
T
OSC
XTAL1
ALE
†
T
LHLL
†
T
RLRH
†
T
T
RHLH2
LLRL
RD#/PSEN#
†
T
RLDV
T
RLAZ
†
T
LHAX
T
RHDZ2
†
T
AVLL
T
LLAX
T
RHDX
D7:0
P2
A15:8
†
Data In
T
AVRL
†
T
AVDV1
†
T
AVDV2
A7:0/A16/A17
P0/A16/A17
†
The value of this parameter depends on wait states. See the table of AC characteristics.
A4212-03
Figure 11. External Bus Cycle: Data Read (Page Mode)
26
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
T
OSC
XTAL1
ALE
†
T
LHLL
†
T
WLWH
T
WHLH
WR#
†
T
LHAX
†
T
T
QVWH
AVLL
T
LLAX
T
WHQX
P2
A15:8
D7:0
†
Data Out
T
AVWL1
†
T
T
AVWL2
WHAX
P0/A16/A17
A7:0/A16/A17
†
The value of this parameter depends on wait states. See the table of AC characteristics.
A4182-01
Figure 12. External Bus Cycle: Data Write (Page Mode)
PRELIMINARY
27
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
5.3.3 DEFINITION OF REAL-TIME WAIT SYMBOLS
Table 12. Real-time Wait Timing Symbol Definitions
Signals
Conditions
A
Address
Data
L
Low
D
C
Y
X
V
Hold
Setup
WCLK
WAIT#
WR#
W
R
RD#/PSEN#
5.3.4 EXTERNAL BUS CYCLES, REAL-TIME WAIT STATES
State 1
State 2
State 3
State 1 (next cycle)
WCLK
TCLYX min
TCLYX max
ALE
TCLYV
RD#/PSEN#
RD#/PSEN#
stretched
TRLYX max
TRLYX min
TRLYV
WAIT#
P0
A0-A7
D0-D7
stretched
stretched
A0-A7
P2
A8-A15
A8-A15
A5000-01
Figure 13. External Bus Cycle: Code Fetch/Data Read (Nonpage Mode)
28
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
State 1
State 2
State 3
State 4
WCLK
TCLYX min
ALE
TCLYX max
TCLYV
WR#
WR# stretched
TWLYX max
T
WLYX min
TWLYV
WAIT#
P0
D0-D7
A0-A7
stretched
stretched
P2
A8-A15
A5002-01
Figure 14. External Bus Cycle: Data Write (Nonpage Mode)
State 1
State 2
State 3
State 1 (next cycle)
WCLK
TCLYX min
TCLYX max
ALE
TCLYV
RD#/PSEN#
RD#/PSEN# stretched
TRLYX max
TRLYX min
TRLYV
WAIT#
P2
A8-A15
D0-D7
A0-A7
stretched
stretched
A8-A15
P0
A0-A7
A5001-01
Figure 15. External Bus Cycle: Code Fetch/Data Read (Page Mode)
PRELIMINARY
29
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
State 1
State 2
State 3
State 4
WCLK
TCLYX min
ALE
TCLYX max
TCLYV
WR#
WR# stretched
TWLYX max
T
WLYX min
TWLYV
WAIT#
P2
A8-A15
D0-D7
stretched
stretched
P0
A0-A7
A5003-01
Figure 16. External Bus Cycle: Data Write (Page Mode)
Table 13. Real-time Wait AC Timing
Symbol
TCLYV
Parameter
Min
Max
Units
ns
Wait Clock Low to Wait Set-up
Wait Hold after Wait Clock Low
PSEN#/RD# Low to Wait Set-up
Wait Hold after PSEN#/RD# Low
WR# Low to Wait Set-up
0
TOSC – 20
TCLYX
TRLYV
TRLYX
TWLYV
TWLYX
(2W)TOSC + 5
(1+2W)TOSC – 20
TOSC – 20
ns
0
ns
(2W)TOSC + 5
0
(1+2W)TOSC – 20
TOSC – 20
ns
ns
Wait Hold after WR# Low
(2W)TOSC + 5
(1+2W)TOSC – 20
ns
30
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
5.4 AC Characteristics — Serial Port, Shift Register Mode
Table 14. Serial Port Timing — Shift Register Mode
Symbol
TXLXL
Parameter
Min
12TOSC
Max
Units
ns
Serial Port Clock Cycle Time
TQVSH
TXHQX
TXHDX
TXHDV
Output Data Setup to Clock Rising Edge
Output Data hold after Clock Rising Edge
Input Data Hold after Clock Rising Edge
Clock Rising Edge to Input Data Valid
10TOSC – 133
2TOSC – 117
0
ns
ns
ns
10TOSC – 133
ns
T
XLXL
TXD
T
XHQX
†
†
Set TI
T
QVXH
RXD
(Out)
0
1
2
7
4
6
3
5
†
T
AV
T
T
XHDV
XHDX
Set RI
RXD
(In)
Valid
Valid
Valid
Valid
Valid
Valid
Valid
Valid
†
TI and RI are set during S1P1 of the peripheral cycle following the shift of the eighth bit.
A2592-02
Figure 17. Serial Port Waveform — Shift Register Mode
5.5 External Clock Drive
Table 15. External Clock Drive
Symbol
1/TCLCL
TCHCX
Parameter
Oscillator Frequency (FOSC
High Time
Min
Max
Units
MHz
ns
)
16
20
20
TCLCX
Low Time
ns
TCLCH
Rise Time
10
10
ns
TCHCL
Fall Time
ns
PRELIMINARY
31
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
TCLCH
TCHCX
VCC – 0.5
0.7 VCC
TCLCX
0.2 VCC – 0.1
0.45 V
TCHCL
TCLCL
A4119-01
Figure 18. External Clock Drive Waveforms
Outputs
Inputs
VCC – 0.5
0.45 V
0.2 VCC + 0.9
0.2 VCC – 0.1
VIH MIN
VOL MAX
AC inputs during testing are driven at VCC – 0.5V for a logic 1
and 0.45 V for a logic 0. Timing measurements are made at
a min of VIH for a logic 1 and VOL for a logic 0.
A4118-01
Figure 19. AC Testing Input, Output Waveforms
VLOAD + 0.1 V
VLOAD
VOH – 0.1 V
Timing Reference
Points
VOL + 0.1 V
VLOAD – 0.1 V
For timing purposes, a port pin is no longer floating when a
100 mV change from load voltage occurs and begins to float
when a 100 mV change from the loading VOH/VOL level occurs
with IOL/IOH = ± 20 mA.
A4117-01
Figure 20. Float Waveforms
32
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
6.0 THERMAL CHARACTERISTICS
Table 16. Thermal Characteristics
Package Type
θJA
θJC
All thermal impedance data is approximate for static
air conditions at 1 watt of power dissipation. Values
change depending on operating conditions and
application requirements. The Intel Packaging
Handbook (order number 240800) describes Intel’s
thermal impedance test methodology.
44-pin PLCC
46°C/W
45°C/W
30.5°C/W
16°C/W
16°C/W
10°C/W
40-pin PDIP
40-pin Ceramic DIP
7.0 NONVOLATILE MEMORY PROGRAMMING AND VERIFICATION
CHARACTERISTICS
7.1 Definition of Nonvolatile Memory Symbols
Table 17. Nonvolatile Memory Timing Symbol Definitions
Signals
Conditions
A
D
Q
S
G
E
Address
Data In
Data Out
Supply
H
L
High
Low
V
X
Z
Valid
No Longer Valid
Floating
PROG#
Enable
33
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
7.2 Programming and Verification Timing for Nonvolatile Memory
Programming Cycle
Verification Cycle
P1, P3
P2
Address (16 Bits)
Address
AVQV
T
Data In (8 Bits)
Data Out
T
T
GHDX
DVGL
T
T
GHAX
AVGL
T
GHGL
PROG#
1
2
3
4
5
T
GHSL
T
GLGH
T
SHGL
12.75V
EA#/V
PP
5V
T
T
ELQV
EHQZ
T
EHSH
P0
Mode (8 Bits)
Mode
A4128-01
Figure 21. Timing for Programming and Verification of Nonvolatile Memory
Table 18. Nonvolatile Memory Programming and Verification Characteristics at
TA = 21 – 27 °C, VCC = 5 V, and VSS = 0 V
Symbol
VPP
Definition
Programming Supply Voltage
Programming Supply Current
Oscillator Frequency
Min
Max
13.5
75
Units
12.5
D.C. Volts
mA
IPP
FOSC
4.0
48TOSC
48TOSC
48TOSC
48TOSC
48TOSC
10
6.0
MHz
TAVGL
TGHAX
TDVGL
TGHDX
TEHSH
TSHGL
TGHSL
TGLGH
Address Setup to PROG# Low
Address Hold after PROG#
Data Setup to PROG# Low
Data Hold after PROG#
ENABLE High to VPP
VPP Setup to PROG# Low
VPP Hold after PROG#
PROG# Width
µs
µs
µs
10
90
110
34
PRELIMINARY
8XC251SA/SB/SP/SQ HIGH-PERFORMANCE CHMOS MICROCONTROLLER
Table 18. Nonvolatile Memory Programming and Verification Characteristics at
TA = 21 – 27 °C, VCC = 5 V, and VSS = 0 V(Continued)
TAVQV
TELQV
TEHQZ
TGHGL
Address to Data Valid
48TOSC
48TOSC
48TOSC
ENABLE Low to Data Valid
Data Float after ENABLE
PROG# High to PROG# Low
0
10
µs
memory have been retained in this datasheet.
8.0 ERRATA
8. Signature Byte information has been deleted.
See the 8XC251SA/SB/SP/SQ Embedded
Microcontroller User’s Manual.
There are no known errata for this product.
9. Sections in the datasheet are numbered.
10. New sections have been created to provide
better organization. These include “Nomencla-
ture,” “Pinout,” “Signals,” “Address Map,”
“Electrical Characteristics,” “Thermal Charac-
teristics,” “Nonvolatile Memory Programming
and Verification Characteristics”, “Errata,” and
“Revision History”
11. Proliferation Options and Package Options are
in the Nomenclature section.
12. Temperature range is contained in the Electri-
cal Characteristics section under “Operating
Conditions”
9.0 REVISION HISTORY
This (-003) revision of the 8XC251SA/SB/SP/SQ
datasheet contains information on products with
“[M] [C] '94 '95 C” as the last line of the topside
marking. This datasheet replaces earlier product
information. The following changes appear in the -
003 datasheet:
1. Real-time wait state operation is described in
the datasheet.
2. Memory map reserved locations are newly
defined and the Memory Map is now referred
to as the “Address Map.”
13. Bus timing diagrams have been organized into
subsections.
3. AC Characteristics have been updated. The
following AC parameters have changed: TLLAX
TRLRH, TWLWH, TLLRL, TRLDV, TRHDZ1, TRHDZ2, TRHLH2
WHLH, TAVDV1, TAVDV2, TAVRL, TAVWL1, TAVWL2
TQVWH, and TWHAX
4. DC Characteristics have been updated. The
following DC specs have changed: IPD max, IDL
typical, IDL max, ICC typical, and ICC max.
5. An ICC vs. Frequency graph is included.
6. Process information is no longer contained in
the datasheet.
7. The section “Programming and Verifying Non-
volatile Memory” has been deleted. See the
8XC251SA/SB/SP/SQ Embedded Microcon-
troller User’s Manual. Timing and Characteris-
tics for Programming and Verifying Nonvolatile
,
,
The (-002) revision of the 8XC251SA/SB/SP/SQ
datasheet contains information on products with
“[M] [C] '94 '95 B” as the last line of the topside
marking. This datasheet replaces earlier product
information. The following changes appear in the -
002 datasheet:
T
,
.
1. A corrected PDIP diagram appears on page 7.
2. A corrected formula to calculate TLHLL is
described on page 17.
3. The RD#/PSEN# waveform is changed in Fig-
ure 11 on page 25.
PRELIMINARY
35
厂商 型号 描述 页数 下载

INTEL

 		8XC151SA 高性能CHMOS微控制器[ HIGH-PERFORMANCE CHMOS MICROCONTROLLER ] 33 页

INTEL

 		8XC151SB 高性能CHMOS微控制器[ HIGH-PERFORMANCE CHMOS MICROCONTROLLER ] 33 页

INTEL

 		8XC152JA 通用通信控制器8位微控制器[ UNIVERSAL COMMUNICATION CONTROLLER 8-BIT MICROCONTROLLER ] 17 页

INTEL

 		8XC152JB 通用通信控制器8位微控制器[ UNIVERSAL COMMUNICATION CONTROLLER 8-BIT MICROCONTROLLER ] 17 页

INTEL

 		8XC152JC 通用通信控制器8位微控制器[ UNIVERSAL COMMUNICATION CONTROLLER 8-BIT MICROCONTROLLER ] 17 页

INTEL

 		8XC152JD 通用通信控制器8位微控制器[ UNIVERSAL COMMUNICATION CONTROLLER 8-BIT MICROCONTROLLER ] 17 页

INTEL

 		8XC196JQ 商业/ EXPRESS CHMOS单片机[ COMMERCIAL/EXPRESS CHMOS MICROCONTROLLER ] 25 页

INTEL

 		8XC196JR 商业/ EXPRESS CHMOS单片机[ COMMERCIAL/EXPRESS CHMOS MICROCONTROLLER ] 25 页

INTEL

 		8XC196KB 先进的16位微控制器CHMOS无ROM或ROM[ ADVANCED 16-BIT CHMOS MICROCONTROLLER ROMless OR ROM ] 17 页

INTEL

 		8XC196KB16 商业/ EXPRESS CHMOS单片机[ COMMERCIAL/EXPRESS CHMOS MICROCONTROLLER ] 22 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于达普

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：smail@ic72.com

服务时间：周一至周六 8:30-17:30

达普官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.250439s
