TX7301
RX7301
1.39GHZ CCTV RADIO VIDEO LINK
TECHNICAL SPECIFICATIONS
ABSOLUTE MAXIMUM RATINGS
Storage Temperature:
Operating Temperature:
-30 to +85o Celsius.
-25 to +55o Celsius.
DIMENSIONS:
Transmitter:
Receiver:
Length = 150mm
Length = 157mm
Width = 100mm
Width = 110mm
Height = 35mm
Height = 50mm
ELECTRICAL CHARACTERISTICS
Frequency
Channels
MIN
1.389
TYPICAL
1.394
1
MAX
1.399
DIMENSION
NOTE
MPT1349
GHz
Synchronisation time
Modulation
Range
1.5
2.0
mSec
AM/FM
1000.0
500
4000.0
Metres
mW
RF Power
ERP
Composite
PAL / Mono
Video Input / Output
1
V
Supply Voltage
Supply Current
11
450
12
500
14
550
Volts
mAmps
