CZD772M
-3A, -40V
PꢀP Plastic Encapsulate Transistor
Elektronische Bauelemente
RoHS Compliant Product
A suffix of “-C” specifies halogen & lead-free
FEATURES
TO-252 (D-Pack)
ꢀ
Low Speed Switching
PACKAGE INFORMATION
Package
MPQ
Leader Size
TO-252
2.5K
13 inch
A
B
C
D
ORDER INFORMATION
Part Number
Type
CZD772M-Y
Lead (Pb)-free
G E
CZD772M-Y-C
Lead (Pb)-free and Halogen-free
K
H F
N
O
P
M
J
Collector
2
Millimeter
Millimeter
Min. Max.
2.3 REF.
0.89 REF.
0.45 1.14
1.55 Typ.
REF.
REF.
Min.
Max.
A
B
C
D
E
F
6.3
4.95
2.1
0.4
6
6.9
5.53
2.5
0.9
7.7
J
K
M
N
O
P
1
Base
0
0.15
2.90 REF
0.58 REF.
3
Emitter
G
H
5.4
0.6
6.4
1.2
ABSOLUTE MAXIMUM RATINGS (TA=25°C unless otherwise specified)
Parameter
Symbol
VCBO
VCEO
VEBO
IC
Rating
-40
Unit
Collector to Base Voltage
V
V
Collector to Emitter Voltage
Emitter to Base Voltage
-30
-6
V
Collector Current
-3
A
Total Power Dissipation
PC
1.25
100
W
Thermal Resistance, junction to Ambient
Junction and Storage Temperature
RθJA
°C / W
°C
TJ, TSTG
150, -55 ~ 150
ELECTRICAL CHARACTERISTICS (TA=25°C unless otherwise specified)
Parameter
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector Cut-Off Current
Symbol
V(BR)CBO
V (BR)CEO
V(BR)EBO
ICBO
Min.
Typ.
Max.
Unit
V
Test Condition
IC= -100µA, IE=0
-40
-30
-6
-
-
-
-
-
V
IC= -10mA, IB=0
IE= -100µA, IC=0
VCB= -40V, IE=0
VCE= -30V, IB=0
VEB= -6V, IC=0
-
-
V
-
-1
uA
Collector Cut-Off Current
ICEO
-
-
-10
-1
Emitter Cut-Off Current
IEBO
-
-
uA
V
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
DC Current Gain
VCE(sat)
VBE(sat)
hFE
-
-
-0.5
-1.5
320
-
IC= -2A, IB= -0.2A
IC= -2A, IB= -0.2A
VCE= -2V, IC= -1A
-
-
V
160
50
-
Transition Frequency
fT
80
MHz VCE= -5V, IC= -0.1A, f=10MHz
http://www.SeCoSGmbH.com/
Any changes of specification will not be informed individually.
24-Oct-2017 Rev. A
Page 1 of 2
