Advanced Technical Information
IXUN 280N10
VDSS = 100 V
ID25 = 280 A
RDS(on) = 3.9 mΩ (typ.)
Trench Power MOSFET
Very low RDS(on)
KS
SOT-227 B,
miniBLOC
D
S
G
G
S
KS
D
G = Gate
D = Drain
S = Source
KS = Kelvin Source
Symbol
VDSS
Conditions
Maximum Ratings
Features
TJ = 25°C to 150°C
100
V
• trench MOSFET
• very low on state resistance RDSon
• fast switching
• fast body diode
• industry standard outline
• isolated package
VGS
VGSM
Continuous
Transient
20
30
V
V
ID25
ID90
TC = 25°C
TC = 90°C
280
210
A
A
• high reliability
ID(RMS)
PD
Package lead current limit
TC = 25°C
150
770
A
W
Applications
TJ
TJM
Tstg
-55 ... +150
175
-55 ... +175
°C
°C
°C
• automotive
• converters for fuel cells
• AC drives
• choppers to replace series dropping
resistors used for motors, heaters etc.
• DC-DC converters
• electronic switches
• replacing relays and fuses
• power supplies
VISOL
50/60 Hz, RMS, t = 1 min
2500
3000
V~
V~
IISOL ≤ 1 mA,
t = 1 s
Md
Mounting torque
Terminal connection torque
1.5/13 Nm/lb.in.
1.5/13 Nm/lb.in.
Weight
30
g
• solar inverters
• battery supplied systems
• choppers or inverters for motor control
in hand tools
Symbol
RDS(on)
Conditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
• battery chargers
VGS = 10 V,
Pulse test, t ≤ 300 µs, duty cycle d < 2 %
ID = 140 A
3.9
5
mΩ
Advantages
• Easy to mount
• Space savings
• High power density
VGH(th)
IDSS
VDS = VGS,
ID = 4 mA
2
4
V
VDS = VDSS
VGS = 0 V,
,
TJ = 25°C
TJ = 125°C
400
2
µA
mA
IGSS
VGS = 20 VDC, VDS = 0
400
nA
IXYS reserves the right to change limits, test conditions, and dimensions.
© 2004 IXYS All rights reserved
1 - 2
