FemtoClock® Crystal-to-LVDS, LVCMOS
10-Output Clock Synthesizer
8V44S269
Datasheet
General Description
Features
The 8V44S269 is a ten LVDS/LVTTL output clock synthesizer
designed for instrumentation and wireless applications. The device
generates four copies of a 125MHz, two copies of a 100MHz
differential LVDS clock and one 50MHz (LVCMOS) signal with
excellent phase jitter performance. The PLL is optimized for a
reference frequency of 25MHz. Both a crystal interface and a
single-ended input are supported for the reference frequency. Three
LVCMOS outputs duplicate the reference frequency and are
provided for clock tree cascade purpose. Each of the four LVCMOS
outputs can be supplied with either 3.3V, 2.5V or 1.8V, forming the
respective LVCMOS output levels of 3.3V, 2.5V or 1.8V. The device
uses IDT’s third generation FemtoClock® technology for an optimum
of high clock frequency and low phase noise performance, combined
with a low power consumption. The device supports a 3.3V voltage
supply and is packaged in a small, lead-free (RoHS 6) 48-lead
VFQFN package.
• Third generation FemtoClock® technology
• 125MHz, 100MHz and 50MHz output clocks synthesized from a
25MHz reference clock or fundamental mode crystal
• Six differential LVDS clock outputs
• QA[0:3] outputs (125MHz) are LVDS compatible
• QB[0:1] outputs (100MHz) are LVDS compatible
• Four single-ended LVCMOS-compatible reference clock outputs
• QC output (50MHz) is LVCMOS 3.3V, 2.5V or 1.8V compatible
• QREF[0:2] (25MHz) are LVCMOS 3.3V, 2.5V or 1.8V compatible
• Crystal interface designed for 25MHz XTAL
• RMS phase jitter @ 125MHz, using a 25MHz crystal
(12kHz - 20MHz): 0.57 (typical)
• RMS phase jitter @ 100MHz, using a 25MHz crystal
(12kHz - 20MHz): 0.58 (typical)
• LVCMOS interface levels for the control input
• I/O supply voltages for LVDS:
Core/Output
3.3V/2.5V
• I/O supply voltages for LVCMOS:
Core/Output
3.3V/3.3V
3.3V/2.5V
3.3V/1.8V
• Lead-free (RoHS 6) 48-lead VFQFN packaging
• -55°C to 105°C ambient operating temperature
©2016 Integrated Device Technology, Inc.
1
May 9, 2016
8V44S269 Datasheet
Block Diagram
Pull-down (4)
nOEA[0:3]
4
QA0
Pull-down
nQA0
BYPASS
QA1
nQA1
XTAL_IN
OSC
125 MHz
f
= 25 MHz
REF
1
0
÷20
÷25
1
0
FemtoClock®
VCO
2500MHz
QA2
nQA2
PFD
&
LPF
XTAL_OUT
25 MHz
Pull-down
REF_CLK
QA3
nQA3
Pull-down
÷2
REF_SEL
100
QB0
100 MHz
nQB0
QB1
nQB1
Pull-down (2)
nOEB[0:1]
2
50 MHz
25 MHz
QC
Pull-down
nOEC
QREF0
QREF1
QREF2
Pull-down (2)
nOER[0:1]
2
©2016 Integrated Device Technology, Inc.
2
May 9, 2016
8V44S269 Datasheet
Pin Assignment
48 47 46 45 44 43 42 41 40 39 38 37
36
35
34
33
32
31
30
29
28
27
26
25
1
GND
QA0
nQA0
QA1
nQA1
VDDOA
QA2
nQA2
QA3
nQA3
GND
nc
REF_CLK
GND
2
3
VDDOC
4
QC
5
VDDOR2
QREF2
GND
6
8V44S269
7
8
VDDOR1
QREF1
VDDOR0
QREF0
GND
9
10
11
12
13 14 15 16 17 18 19 20 21 22 23 24
Pin Description and Characteristic Tables
1
Table 1. Pin Descriptions
Number
Name
REF_CLK
GND
Type
Description
1
2
3
4
5
Input
Power
Power
Output
Power
Pull-down
Single-ended reference clock input. LVCMOS/LVTTL interface levels.
Ground power supply (0V).
VDDOC
QC
Output supply for the QC output.
Single-ended clock output. LVCMOS/LVTTL interface levels.
Output supply for the QREF2 output.
VDDOR2
Single-ended clock output (copy 2 of the reference clock). 
LVCMOS/LVTTL interface levels.
6
QREF2
Output
7
8
GND
Power
Power
Ground power supply (0V).
VDDOR1
Output supply for the QREF1 output.
Single-ended clock output (copy 1 of the reference clock). 
LVCMOS/LVTTL interface levels.
9
QREF1
VDDOR0
QREF0
GND
Output
Power
Output
Power
10
11
12
Output supply for the QREF0 output.
Single-ended clock output (copy 0 of the reference clock).
LVCMOS/LVTTL interface levels.
Ground power supply (0V).
©2016 Integrated Device Technology, Inc.
3
May 9, 2016
8V44S269 Datasheet
1
Table 1. Pin Descriptions
Number
Name
nOEC
VDD
Type
Description
Output enable inputs for the individual QC output. See Table 3E on page 6
for function. LVCMOS/LVTTL interface levels.
13
Input
Power
Input
Pull-down
14
Core supply.
Output enable inputs for the QREF2 output. See Table 3F on page 6 for
function. LVCMOS/LVTTL interface levels.
15
nOER1
Pull-down
Pull-down
Pull-down
Pull-down
Output enable inputs for the QREF[0:1] outputs. See Table 3F on page 6
for function. LVCMOS/LVTTL interface levels.
16
17
18
nOER0
nOEB1
nOEB0
Input
Input
Input
Output enable inputs for the QB1 output. See Table 3D on page 6 for
function. LVCMOS/LVTTL interface levels.
Output enable inputs for the QB0 output. See Table 3D on page 6 function.
LVCMOS/LVTTL interface levels.
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
VDDOB
nQB1
QB1
Power
Output
Output
Output
Output
Unused
Unused
Power
Output
Output
Output
Output
Power
Output
Output
Output
Output
Power
Power
Power
Power
Output supply for the Bank B outputs.
Inverted differential clock output pair. LVDS interface levels.
Non-inverted Differential clock output pair. LVDS interface levels.
Inverted differential clock output pair. LVDS interface levels.
Non-inverted Differential clock output pair. LVDS interface levels.
No internal connection.
nQB0
QB0
nc
nc
No internal connection.
GND
nQA3
QA3
Ground power supply (0V).
Inverted differential clock output pair. LVDS interface levels.
Non-inverted Differential clock output pair. LVDS interface levels.
Inverted differential clock output pair. LVDS interface levels.
Non-inverted Differential clock output pair. LVDS interface levels.
Output supply for the Bank A outputs.
nQA2
QA2
VDDOA
nQA1
QA1
Inverted differential clock output pair. LVDS interface levels.
Non-inverted Differential clock output pair. LVDS interface levels.
Inverted differential clock output pair. LVDS interface levels.
Non-inverted Differential clock output pair. LVDS interface levels.
Ground power supply (0V).
nQA0
QA0
GND
GND
VDD
Ground power supply (0V).
Core supply.
VDDA
Analog power supply.
Output enable inputs for the QA3 output. See Table 3C on page 6 for
function. LVCMOS/LVTTL interface levels.
40
41
nOEA3
nOEA2
Input
Input
Pull-down
Pull-down
Output enable inputs for the QA2 output. See Table 3C on page 6 for
function. LVCMOS/LVTTL interface levels.
©2016 Integrated Device Technology, Inc.
4
May 9, 2016
8V44S269 Datasheet
1
Table 1. Pin Descriptions
Number
Name
Type
Description
Output enable inputs for the QA1 output. See Table 3C on page 6 for
function. LVCMOS/LVTTL interface levels.
42
nOEA1
Input
Input
Input
Pull-down
Pull-down
Pull-down
Pull-down
Output enable inputs for the QA0 output. See Table 3C on page 6 for
function. LVCMOS/LVTTL interface levels.
43
44
45
nOEA0
REF_SEL
BYPASS
Reference select. See Table 3A on page 6 for function.
LVCMOS/LVTTL interface levels.
PLL bypass mode select. See Table 3B on page 6 for function.
LVCMOS/LVTTL interface levels.
Input
46
47
48
—
GND
Power
Ground power supply (0V).
Crystal
Output
XTAL_OUT
XTAL_IN
Crystal Output. Crystal oscillator interface.
Crystal Input. Crystal oscillator interface.
Crystal Input
Ground
Ground power supply (0V). The exposed pad is a ground return path of the
circuit and requires a connection to 0V.
Exposed Pad
NOTE 1. Pull-down refers to internal input resistors. See Table 2, “Pin Characteristics”.
1
Table 2. Pin Characteristics
Symbol
Parameter
Test Conditions
Minimum
Typical
Maximum
Units
REF_CLK,
nOEA[0:3],
nOEB[0:1], 
nOEC,
nOER[0:1],
REF_SEL,
BYPASS
Input
Capacitance
CIN
2
pF
RPULLDOWN
Input Pull-down Resistor
51
18
23
35
k
QREF[0:2], QC, VDDOn = 3.3V
QREF[0:2], QC, VDDOn = 2.5V
QREF[0:2], QC, VDDOn = 1.8V
ROUT
Output Impedance
NOTE 1. VDDOn denotes VDDOC, VDDOR0, VDDOR1, VDDOR2.
©2016 Integrated Device Technology, Inc.
5
May 9, 2016
8V44S269 Datasheet
Function Tables
1
1
Table 3A. PLL Reference Clock Select Function Table
Input
Table 3D. Outputs QB[0:1] Enable Function Table
Input
REF_SEL
Operation
nOEBn
0 (default)
Operation
0 (default)
The REF_CLK input is selected as reference clock
Outputs QBn, nQBn are enabled
The crystal interface is selected as reference
clock
Outputs QBn, nQBn are disabled in
high-impedance state
1
1
NOTE 1. REF_SEL is an asynchronous control input.
NOTE 1. n = 0 to 1. 
Each QBn, nQBn output is individually controlled by the
corresponding nOEBn input. nOEBn are synchronous
control inputs.
1
1
Table 3B. PLL Bypass Select Function Table
Input
Table 3E. Outputs QC Enable Function Table
Input
BYPASS
Operation
nOEC
0 (default)
1
Operation
0 (default)
PLL mode
Output QC is enabled
PLL bypass mode. The reference clock is routed
to the output dividers. 
AC specifications do not apply in PLL bypass
Output QC is disabled in high-impedance state
1
NOTE 1. nOEC is an asynchronous control input.
mode.
NOTE 1. BYPASS is an asynchronous control input.
1
Table 3C. Outputs QA[0:3] Enable Function Table
Input
nOEAn
Operation
0 (default)
Output QAn, nQAn is enabled
Output QAn, nQAn is disabled in high-impedance
state
1
NOTE 1. n = 0 to 3. 
Each QAn, nQAn output is individually controlled by the
corresponding nOEAn input. nOEAn are asynchronous
control inputs.
1
Table 3F. Outputs QREF[0:2] Enable Function Table
Input
nOER1
Operation
nOER0
Outputs QREF[0:1]
Enabled
Output QREF2
0 (default)
0 (default)
Enabled
0
1
1
1
0
1
Enabled
Disabled in high-impedance state
Enabled
Disabled in high-impedance state
Disabled in high-impedance state
Disabled in high-impedance state
NOTE 1. nOER[0:1] are asynchronous control inputs.
©2016 Integrated Device Technology, Inc.
6
May 9, 2016
8V44S269 Datasheet
Absolute Maximum Ratings
NOTE: Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These ratings are stress
specifications only. Functional operation of the product at these conditions or any conditions beyond those listed in the DC Characteristics or
AC Characteristics is not implied. Exposure to absolute maximum rating conditions for extended periods may affect product reliability.
Table 4. Absolute Maximum Ratings
Item
Rating
Supply Voltage, VDD
4.6V
Inputs, VI
XTAL_IN
Other Inputs
0V to 2V
-0.5V to VDD + 0.5V
Outputs, VO (LVCMOS)
-0.5V to VDDOn1 + 0.5V
Outputs, IO (LVDS)
Continuous Current
Surge Current
10mA
15mA
Storage Temperature, TSTG
-65C to 150C
125C
Junction Temperature, TJ
NOTE 1. VDDOn denotes VDDOC, VDDOR0, VDDOR1, VDDOR2.
DC Electrical Characteristics
Table 5A. Power Supply DC Characteristics,
1
V
= 3.3V 5ꢀ, V
= V
= 2.5V 5ꢀ, V
V
= (2.5V to 3.3V) 5ꢀ, 1.8V 0.2V, T = -55°C to 105°C
DDOC A
DD
DDOA
DDOB
DDORn,
Symbol
VDD
Parameter
Test Conditions
Minimum
3.135
Typical
3.3
Maximum
3.465
Units
Core Supply Voltage
V
V
VDDA
Analog Supply Voltage
VDD – 0.16
3.3
VDD
LVDS
Output Supply Voltage
VDDOA, B
2.375
2.5
2.625
V
1.6
1.8
2.5
3.3
80
2.0
2.625
3.465
91
V
V
V
DDOR0, VDDOR1,LVCMOS 
2.375
3.135
VDDOR2, VDDOC
Output Supply Voltage2
V
IDD
Core Supply Current
mA
mA
IDDA
Analog Supply Current
12
16
LVDS
Output Supply Current
IDDOA + DDOB
I
122
2
137
3
mA
mA
LVCMOS
Output Power Current
QC, QREF[0:2];
No External Load
3
IDDORn + IDDOC
NOTE 1. VDDOn denotes VDDOR0, VDDOR1, VDDOR2.
NOTE 2. Each VDDORn (n = 0 to 2) and VDDOC voltage may be left open, connected to GND or supplied by 1.8V, 2.5V or 3.3V.
NOTE 3. IDDORn denotes IDDOR0, DDOR1, DDOR2.
I
I
©2016 Integrated Device Technology, Inc.
7
May 9, 2016
8V44S269 Datasheet
Table 5B. LVCMOS/LVTTL DC Characteristics, 
1
V
= 3.3V 5ꢀ, V
, VDD = (2.5V to 3.3V) 5ꢀ, 1.8V 0.2V, T = -55°C to 105°C
DD
DDORn OC A
Symbol
VIH
Parameter
Test Conditions
VDD = 3.3V
Minimum
2.2
Typical
Maximum
VDD + 0.3
0.8
Units
Input High Voltage2
V
V
VIL
Input Low Voltage
VDD = 3.3V
-0.3
REF_SEL,
nOEA[0:3],
nOEB[0:1],
Input
IIH
VDD = VIN = 3.465V
150
µA
µA
High Current nOER[0:1],
BYPASS,
REF_CLK
REF_SEL,
nOEA[0:3],
nOEB[0:1],
nOER[0:1],
BYPASS,
REF_CLK
Input
Low Current
IIL
VDD = 3.465V, VIN = 0V
-5
VDDOn4 = 3.465V
VDDOn4 = 2.625V
VDDOn4 = 2V
2.6
1.8
1.5
V
V
V
V
V
V
Output
High
QC,
QREF[0:2]
VOH
Voltage3
VDDOn4 = 3.465V
VDDOn4 = 2.625V
VDDOn4 = 2V
0.5
0.5
0.4
Output
QC,
VOL
Low Voltage3 QREF[0:2]
NOTE 1. VDDORn denotes VDDOR0, VDDOR1, VDDOR2.
NOTE 2. nOEA[0:3], nOEB[0:1], nOER[0:1], nOEC, BYPASS and REF_CLK inputs are 3.3V tolerant.
NOTE 3. Output terminated with 50to VDD/ 2. See Section, “Parameter Measurement Information”.
NOTE 4. VDDOn denotes VDDOC, VDDOR0, VDDOR1, VDDOR2.
Table 5C. LVDS DC Characteristics, VDD = 3.3V 5ꢀ, VDDOA = VDDOB = 2.5V 5ꢀ, T = -55°C to 105°C
A
Symbol
VOD
Parameter
Test Conditions
Minimum
Typical
Maximum
Units
mV
mV
V
Differential Output Voltage
VOD Magnitude Change
Offset Voltage
247
488
VOD
VOS
50
0.975
1.375
VOS
VOS Magnitude Change
50
mV
Table 6. Crystal Characteristics
Parameter
Test Conditions
Minimum
Typical
Fundamental
25
Maximum
Units
Mode of Oscillation
Frequency
MHz
Equivalent Series Resistance (ESR)
Shunt Capacitance
80
7
pF
Capacitive Loading (CL)
12
pF
©2016 Integrated Device Technology, Inc.
8
May 9, 2016
8V44S269 Datasheet
AC Electrical Characteristics
Table 7. AC Characteristics, 
1
2, 3
V
= 3.3V 5ꢀ, V
= V
= 2.5V 5ꢀ, V
VDD = (2.5V to 3.3V) 5ꢀ, 1.8V 0.2V, T = -55°C to 105°C
DDORn, OC A
DD
DDOA
DDOB
Symbol
Parameter
Test Conditions
Minimum
Typical
Maximum
Units
MHz
MHz
MHz
MHz
MHz
MHz
fVCO
VCO Frequency
BYPASS = 0
2500
125
100
50
Output Frequency, QA[0:3]
Output Frequency, QB[0:1]
Output Frequency, QC
fOUT
Output Frequency, QREF[0:2]
Reference Frequency
25
fREF
25
fOUT = 125MHz,
Integration Range: 12kHz – 20MHz
QA[0:3]
0.57
0.58
0.78
0.85
0.8
0.8
ps
ps
ps
ps
f
OUT = 100MHz,
QB[0:1]
Integration Range: 12kHz – 20MHz
RMS Phase
Jitter (Random)
tjit(Ø)
fOUT = 50MHz,
Integration Range: 12kHz – 20MHz
QC
1.20
1.32
fOUT = 25MHz,
Integration Range: 12kHz – 5MHz
QREF[0:2]
N(1k)
1kHz Offset from Carrier
10kHz Offset from Carrier
100kHz Offset from Carrier
1MHz Offset from Carrier
-126
-132
-130
-141
-119
-126.9
-127.4
-138
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
N(10k)
N(100k)
N(1M)
Single-side Band Phase Noise
100MHz Output Frequency
10MHz Offset from Carrier and
Noise Floor
N(10M)
-153
-150
dBc/Hz
N(1k)
1kHz Offset from Carrier
10kHz Offset from Carrier
100kHz Offset from Carrier
1MHz Offset from Carrier
-124
-129
-128
-139
-116
-124.9
-125.4
-137
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
N(10k)
N(100k)
N(1M)
Single-side Band Phase Noise
125MHz Output Frequency
10MHz Offset from Carrier and
Noise Floor
N(10M)
-151
-150
dBc/Hz
QA[0:3]
QB[0:1]
fOUT = 125MHz
fOUT = 100MHz
3.0
3.2
6
8.1
7.4
28
ps
ps
ps
ps
ps
ps
fOUT = 50MHz, VDDOC = 3.3V
Period Jitter,
Peak-to-Peak
tjit(per)
QC
f
OUT = 50MHz, VDDOC = 2.5V
7
33
fOUT = 50MHz, VDDOC = 1.8V
fOUT = 25MHz
11
2.4
39
QREF[0:2]
4.0
©2016 Integrated Device Technology, Inc.
9
May 9, 2016
8V44S269 Datasheet
Table 7. AC Characteristics, (Continued)
1
2, 3
V
= 3.3V 5ꢀ, V
= V
= 2.5V 5ꢀ, V
VDD = (2.5V to 3.3V) 5ꢀ, 1.8V 0.2V, T = -55°C to 105°C
DDORn, OC A
DD
DDOA
DDOB
Symbol
Parameter
Test Conditions
Minimum
Typical
9
Maximum
Units
ps
QA[0:3]
QB[0:1]
fOUT = 125MHz
16
20
27
41
113
33
25
30
65
f
OUT = 100MHz
OUT = 50MHz, VDDOC = 3.3V
fOUT = 50MHz, VDDOC = 2.5V
11
ps
f
12
ps
Cycle-to-Cycle
Jitter
tjit(cc)
QC
13
ps
f
OUT = 50MHz, VDDOC = 1.8V
fOUT = 25MHz
44
ps
QREF[0:2]
QA[0:3]
19
ps
ps
tsk(b)
tR / tF
Bank Skew4, 5 QB[0:1]
ps
QREF[0:2]
ps
Differential
Outputs
20ꢀ to 80ꢀ
20ꢀ to 80ꢀ
150
375
250
750
ps
ps
Output
Rise/Fall Time
Single-ended
Outputs
tLOCK
PLL Lock Time
73
50
50
50
ms
ꢀ
QA[0:3]
QB[0:1]
QC
fOUT = 125MHz
48
48
48
52
52
52
Output
Duty Cycle
odc
f
OUT = 100MHz
fOUT = 50MHz
ꢀ
ꢀ
NOTE 1. VDDORn denotes VDDOR0, VDDOR1, VDDOR2.
NOTE 2. Electrical parameters are guaranteed over the specified ambient operating temperature range, which is established when the device
is mounted in a test socket with maintained transverse airflow greater than 500 lfpm. The device will meet specifications after thermal
equilibrium has been reached under these conditions.
NOTE 3. fREF = 25MHz.
NOTE 4. Defined as skew within a bank of outputs at the same voltage and with equal load conditions.
NOTE 5. This parameter is defined in accordance with JEDEC Standard 65.
©2016 Integrated Device Technology, Inc.
10
May 9, 2016
8V44S269 Datasheet
Typical Phase Noise at 125MHz, 2.5V (QA Outputs)
Offset Frequency (Hz)
©2016 Integrated Device Technology, Inc.
11
May 9, 2016
8V44S269 Datasheet
Typical Phase Noise at 100MHz, 2.5V (QB Outputs)
Offset Frequency (Hz)
©2016 Integrated Device Technology, Inc.
12
May 9, 2016
8V44S269 Datasheet
Parameter Measurement Information
1.65V 5ꢀ
3.3V 5ꢀ
2.5V 5ꢀ
1.65V 5ꢀ
SCOPE
V
SCOPE
DD
V
V
V
DD,
Qx
V
DDA
DDOC,
+ +
POWER
SUPPLY
Float GND
–
V
V
DDOA,
DDOB
DDOR[0:2]
V
Qx
DDA
nQx
GND
-1.65V 5ꢀ
LVDS 3.3V Core/2.5V Output Load AC Test Circuit
LVCMOS 3.3V Core/3.3V Output Load AC Test Circuit
2.4V 0.065V
0.9V 0.1V
2.05V 5ꢀ
1.25V 5ꢀ
2.05V 5ꢀ
2.4V 0.065V
V
V
DD
SCOPE
DD
SCOPE
V
V
DDOC,
V
V
DDOC,
DDOR[0:2]
DDOR[0:2]
Qx
Qx
V
DDA
V
DDA
GND
GND
-0.9V 0.1V
-1.25V 5ꢀ
LVCMOS 3.3V Core/2.5V Output Load AC Test Circuit
LVCMOS 3.3V Core/1.8V Output Load AC Test Circuit
VOH
VREF
VOL
t jit (pk-pk)
Histogram
Reference Point
(Trigger Edge)
Mean Period
(First edge after trigger)
10,000 cycles
Period Jitter
RMS Phase Jitter
©2016 Integrated Device Technology, Inc.
13
May 9, 2016
8V44S269 Datasheet
Parameter Measurement Information, continued
nQA[0:3],
nQB[0:1]
VDDOX
2
VDDOX
2
VDDOX
2
QC,
QREF[0:2]
QA[0:3],
QB[0:1]
➤
➤
tcycle n
tcycle n+1
tcycle n
tcycle n+1
➤
➤
tjit(cc) = tcycle n – tcycle n+1
|
|
tjit(cc) = tcycle n – tcycle n+1
|
|
1000 Cycles
1000 Cycles
LVDS Cycle-to-Cycle Jitter
LVCMOS Cycle-to-Cycle Jitter
nQXx
QXx
VDDO
QREFx
QREFy
2
nQXy
VDDO
2
QXy
tsk(o)
tsk(b)
X = Bank A or Bank B
LVDS Bank Skew
LVCMOS Bank Skew
nQA[0:3],
nQB[0:1]
80ꢀ
tF
80ꢀ
tF
80ꢀ
tR
80ꢀ
VOD
20ꢀ
20ꢀ
20ꢀ
QC,
QREF[0:2]
20ꢀ
QA[0:3],
QB[0:1]
tR
LVDS Output Rise/Fall Time
LVCMOS Output Rise/Fall Time
©2016 Integrated Device Technology, Inc.
14
May 9, 2016
8V44S269 Datasheet
Parameter Measurement Information, continued
nQA[0:3],
nQB[0:1]
VDDO
2
QA[0:3],
QB[0:1]
QC,
QREF[0:2]
tPW
tPERIOD
tPW
x 100ꢀ
odc =
tPERIOD
LVDS Output Duty Cycle/Pulse Width/Period
LVCMOS Output Duty Cycle/Pulse Width/Period
PLL Lock Time
Offset Voltage Setup
Differential Offset Voltage Setup
©2016 Integrated Device Technology, Inc.
15
May 9, 2016
8V44S269 Datasheet
Applications Information
Recommendations for Unused Input and Output Pins
Inputs:
Outputs:
LVCMOS Outputs
REF_CLK
All unused LVCMOS outputs can be left floating We recommend that
there is no trace attached.
For applications not requiring the use of the reference clock, it can be
left floating. Though not required, but for additional protection, a 1k
resistor can be tied from the REF_CLK to ground.
LVDS Outputs
Crystal Inputs
All unused LVDS output pairs can be either left floating or terminated
with 100across. If they are left floating there should be no trace
attached.
For applications not requiring the use of the crystal oscillator input,
both XTAL_IN and XTAL_OUT can be left floating. Though not
required, but for additional protection, a 1kresistor can be tied from
XTAL_IN to ground.
LVCMOS Control Pins
All control pins have internal pull-down resistors; additional
resistance is not required but can be added for additional protection.
A 1kresistor can be used.
©2016 Integrated Device Technology, Inc.
16
May 9, 2016
8V44S269 Datasheet
Overdriving the XTAL Interface
The XTAL_INinputcan be overdriven by an LVCMOS driver orby one
side of a differential driver through an AC coupling capacitor. The
XTAL_OUT output can be left floating. The amplitude of the input
signal should be between 500mV and 1.8V and the slew rate should
not be less than 0.2V/ns. For 3.3V LVCMOS inputs, the amplitude
must be reduced from full swing to at least half the swing in order to
prevent signal interference with the power rail and to reduce internal
noise. Figure 1A shows an example of the interface diagram for a
high speed 3.3V LVCMOS driver. This configuration requires that the
sum of the output impedance of the driver (Ro) and the series
resistance (Rs) equals the transmission line impedance. In addition,
matched termination at the crystal input will attenuate the signal in
half. This can be done in one of two ways. First, R1 and R2 in parallel
should equal the transmission line impedance. For most 50
applications, R1 and R2 can be 100. This can also be accomplished
by removing R1 and changing R2 to 50. The values of the resistors
can be increased to reduce the loading for a slower and weaker
LVCMOS driver. Figure 1B shows an example of the interface
diagram for an LVPECL driver. This is a standard LVPECL
termination with one side of the driver feeding the XTAL_IN input. It
is recommended that all components in the schematics be placed in
the layout. Though some components might not be used, they can be
utilized for debugging purposes. The datasheet specifications are
characterized and guaranteed by using a quartz crystal as the input.
VCC
XTAL_OUT
R1
100
C1
Rs
Zo = 50 ohms
Ro
XTAL_IN
.1uf
R2
100
Zo = Ro + Rs
LVCMOS Driver
Figure 1A. Figure 2A. General Diagram for LVCMOS Driver to XTAL Input Interface
XTAL_OUT
C2
Zo = 50 ohms
XTAL_I N
.1uf
Zo = 50 ohms
R1
50
R2
50
LVPECL Driver
R3
50
Figure 1B. Figure 2B. General Diagram for LVPECL Driver to XTAL Input Interface
©2016 Integrated Device Technology, Inc.
17
May 9, 2016
8V44S269 Datasheet
VFQFN EPAD Thermal Release Path
In order to maximize both the removal of heat from the package and
the electrical performance, a land pattern must be incorporated on
the Printed Circuit Board (PCB) within the footprint of the package
corresponding to the exposed metal pad or exposed heat slug on the
package, as shown in Figure 2. The solderable area on the PCB, as
defined by the solder mask, should be at least the same size/shape
as the exposed pad/slug area on the package to maximize the
thermal/electrical performance. Sufficient clearance should be
designed on the PCB between the outer edges of the land pattern
and the inner edges of pad pattern for the leads to avoid any shorts.
and dependent upon the package power dissipation as well as
electrical conductivity requirements. Thus, thermal and electrical
analysis and/or testing are recommended to determine the minimum
number needed. Maximum thermal and electrical performance is
achieved when an array of vias is incorporated in the land pattern. It
is recommended to use as many vias connected to ground as
possible. It is also recommended that the via diameter should be 12
to 13mils (0.30 to 0.33mm) with 1oz copper via barrel plating. This is
desirable to avoid any solder wicking inside the via during the
soldering process which may result in voids in solder between the
exposed pad/slug and the thermal land. Precautions should be taken
to eliminate any solder voids between the exposed heat slug and the
land pattern. Note: These recommendations are to be used as a
guideline only. For further information, please refer to the Application
Note on the Surface Mount Assembly of Amkor’s Thermally/
Electrically Enhance Leadframe Base Package, Amkor Technology.
While the land pattern on the PCB provides a means of heat transfer
and electrical grounding from the package to the board through a
solder joint, thermal vias are necessary to effectively conduct from
the surface of the PCB to the ground plane(s). The land pattern must
be connected to ground through these vias. The vias act as “heat
pipes”. The number of vias (i.e. “heat pipes”) are application specific
SOLDER
SOLDER
PIN
PIN
EXPOSED HEAT SLUG
PIN PAD
GROUND PLANE
LAND PATTERN
(GROUND PAD)
PIN PAD
THERMAL VIA
Figure 2. Figure 3. P.C. Assembly for Exposed Pad Thermal Release Path – Side View (drawing not to scale)
©2016 Integrated Device Technology, Inc.
18
May 9, 2016
8V44S269 Datasheet
LVDS Driver Termination
For a general LVDS interface, the recommended value for the
termination impedance (ZT) is between 90and 132. The actual
value should be selected to match the differential impedance (Z0) of
your transmission line. A typical point-to-point LVDS design uses a
100parallel resistor at the receiver and a 100differential
transmission-line environment. In order to avoid any
transmission-line reflection issues, the components should be
surface mounted and must be placed as close to the receiver as
possible. IDT offers a full line of LVDS compliant devices with two
types of output structures: current source and voltage source. The
standard termination schematic as shown in Figure 3A can be used
with either type of output structure. Figure 3B, which can also be
used with both output types, is an optional termination with center tap
capacitance to help filter common mode noise. The capacitor value
should be approximately 50pF. If using a non-standard termination, it
is recommended to contact IDT and confirm if the output structure is
current source or voltage source type. In addition, since these
outputs are LVDS compatible, the input receiver’s amplitude and
common-mode input range should be verified for compatibility with
the output.
ZO ZT
LVDS
Driver
LVDS
ZT
Receiver
Figure 3A. Standard LVDS Termination
ZT
2
ZO ZT
LVDS
Driver
LVDS
Receiver
C
ZT
2
Figure 3B. Optional LVDS Termination
©2016 Integrated Device Technology, Inc.
19
May 9, 2016
8V44S269 Datasheet
Schematic Layout
Figure 4 (next page) shows an example 8V44S269 application
schematic in which the device is operated at VDD = VDDOR0 = VDDOR1
= VDDOR2 = 3.3V and VDDOA = VDDOB = 2.5V.
In order to achieve the best possible filtering, it is recommended that
the placement of the filter components be on the device side of the
PCB as close to the power pins as possible. If space is limited, the 10
ohm VCCA resistor and the 0.1uF capacitor in each power pin filter
should be placed on the device side. The other components can be
on the opposite side of the PCB. Pull-up and pull-down resistors to
set configuration pins can all be placed on the PCB side opposite the
device side to free up device side area if necessary.
This example focuses on functional connections and is not
configuration specific. Refer to the pin description and functional
tables in the datasheet to ensure that the logic control inputs are
properly set for the application.
Two different differential terminations are depicted. QA0 is the
standard LVDS termination. QA3 is an example demonstrating how
the IDT LVDS outputs can be directly AC coupled to IDT CLK, nCLK
clock receiver inputs where the internal bias resistors of the receiver
guarantee that the AC coupled LVDS clock is within the common
mode range of the receiver.
Power supply filter recommendations are a general guideline to be
used for reducing external noise from coupling into the devices. The
filter performance is designed for a wide range of noise frequencies.
This low-pass filter starts to attenuate noise at approximately 10kHz.
If a specific frequency noise component is known, such as switching
power supplies frequencies, it is recommended that component
values be adjusted and if required, additional filtering be added.
Additionally, good general design practices for power plane voltage
stability suggests adding bulk capacitance in the local area of all
devices.
As with any high speed analog circuitry, the power supply pins are
vulnerable to random noise. To achieve optimum jitter performance,
power supply isolation is required. The 8V44S269 provides separate
power supplies to isolate any high switching noise from coupling into
the internal PLL. The Murata BLM18BB221SN1B ferrite bead shown
in the schematic was selected for the flat frequency response
realized with the associated filter capacitors. The rated current for this
bead is 450mA which will accommodate the maximum current for
each power filter.
For additional layout recommendations and guidelines, contact
clocks@idt.com.
©2016 Integrated Device Technology, Inc.
20
May 9, 2016
8V44S269 Datasheet
3.3V
2.5V
FB1
FB3
1
2
VDD
2
1
2.5V
FB5
1
BLM18BB221SN1
BLM18BB221SN1
C20
C7
0.1uF
C8
10uF
C29
0.1uF
C30
0.1uF
U24
14
2
31
19
3
C32
0.1uF
C21
10uF
0.1uF
VDDOA
VDDOB
VDDOC
BLM18BB221SN1
VDD
VDD
38
C41
0.1uF
C40
10uF
C39
0.1uF
FB6
3.3V
1
R20
10
2
Place 0.1uF bypass cap
directly adjacent to the
corresponding VDDO pin.
VDD
39
BLM18BB221SN1
VDDA
C42
0.1uF
C10
0.1uF
C31
0.1uF
C44
0.1uF
C43
10uF
3.3V
XTAL_IN
48
47
FB4
XTAL_IN
10
8
2
1
VDDOR0
VDDOR1
VDDOR2
XTAL_OUT
3.3V
BLM18BB221SN1
XTAL_OUT
Q2
C38
0.1uF
C36
10uF
C35
C34
0.1uF
0.1uF
Ro
Ro+Rz=Zo
R19
Zo = 50 Ohm
5
REF_CLK
1
44
43
42
REF_CLK
REF_SEL
nOEA0
Rz
C37
0.1uF
Place 0.1uF bypass cap
directly adjacent to the
LVCMOS Driver
corresponding VDDO pin.
REF_SEL
Zo = 50 Ohm
+
35
34
QA0
R2
QA0
100
nOEA0
nOEA1
nQA0
Zo = 50 Ohm
nQA0
-
33
32
QA1
LVDS Receiver
1
QA1
nQA1
25 MHz
(12pF)
nOEA1
nQA1
XTAL_IN
2
4
LVDS Termination
X2
IDT
30
29
QA2
603-25-173
crystal
QA2
3
XTAL_OUT
C1
15pF
C2
15pF
nOEA2
nOEA3
nOEB0
41
40
18
nQA2
nOEA2
nOEA3
nOEB0
nQA2
Zo = 50 Ohm
C45
+
28
27
QA3
0.1u
C46
R16
100
QA3
nQA3
Zo = 50 Ohm
nQA3
-
0.1u
IDT Clk/nCLK Receiver
23
22
QB0
QB0
LVDS Termination
nQB0
nQB0
Zo = 50 Ohm
+
21
20
QB1
R17
100
QB1
nOEB
nOEC
17
13
nQB1
Zo = 50 Ohm
nOEB1
nOEC
nQB1
-
LVDS Receiver
Logic Control Input Examples
R1
33
Zo = 50 Ohm
4
QC
QC
QREF0
QREF1
QREF2
Set Logic
Input to '1'
Set Logic
Input to '0'
VDD
VDD
nOER0
nOER1
16
15
LVCMOS Receiver
LVCMOS Termination
nOER0
nOER1
RU1
1k
RU2
Not Install
11
9
QREF0
To Logic
Input
pins
To Logic
Input
pins
BYPASS
45
2
QREF1
QREF2
BYPASS
GND
RD1
Not Install
RD2
1k
7
GND
R18
33
Zo = 50 Ohm
12
26
36
37
46
6
GND
GND
LVCMOS Termination
GND
LVCMOS Receiver
GND
24
25
nc
nc
GND
49
ePAD
IDT8V44S269I
Figure 4. 8V44S269 Application Schematic
©2016 Integrated Device Technology, Inc.
21
May 9, 2016
8V44S269 Datasheet
Power Considerations
The 8V44S269 device was designed and characterized to operate within the ambient extended temperature range of -55°C to 105°C.
The ambient temperature represents the temperature around the device, not the junction temperature. Extreme care must be taken to avoid
exceeding the 125°C junction temperature, potentially damaging the device.
Equations and example calculations are also provided below.
1. Power Dissipation.
The power dissipation for the 8V44S269 is the product of supply voltage and total IDD. 
The following is the power dissipation for VDD = 3.3V + 5ꢀ = 3.465V at ambient temperature of 105°C, QREFn = 25MHz, QC = 50MHz,
QAn = 125MHz, QBn = 100MHz.
IDD_MAX = 91mA
IDDA_MAX = 16mA
IDDOA_MAX + IDD0B_MAX + IDDOC_MAX + IDDORn_MAX = 141mA
•
•
•
Power(core)_max = VDD_MAX * (IDD_MAX + IDDA_MAX) = 3.465V * (91mA + 16mA) = 370.76mW
LVDS and LVCMOS Outputs Power(output)_max = 3.465V * 141mA = 488.57mW
Total Power_max (3.465V, with all outputs switching) = 370.76mW + 488.57mW = 859.33mW
2. Junction Temperature.
Junction temperature, Tj, signifies the hottest point on the device and exceeding the specified limit could cause device reliability issues. 
The maximum recommended junction temperature is 125°C.
For devices like this and in systems where most heat escapes from the bottom exposed pad of the package, JB is the primary thermal
resistance of interest.
The equation to calculate Tj using JB is: Tj = JB * PD + TB
Tj = Junction Temperature
JB = Junction-to-Board Thermal Resistance
PD = Device Power Dissipation (example calculation is in section 1 above)
TB = Board Temperature
In order to calculate junction temperature, the appropriate junction-to-board thermal resistance JB must be used. Assuming a 2-ground plane
board, the appropriate value of JB is 1.93°C/W per Table 8 below.
Therefore, Tj for a PCB maintained at 115°C with the outputs switching is:
115°C + 0.859W * 1.93°C/W = 116.7°C which is below the limit of 125°C.
This calculation is only an example. Tj will obviously vary depending on the number of loaded outputs, supply voltage, air flow, heat transfer
method, the type of board (multi-layer) and the actual maintained board temperature. The below table is for two ground planes. The thermal
resistance will change as the number of layers in the board changes or if the board size change and other changes in other factors impacts
heat dissipation in the system.
1, 2, 3
Table 8. Thermal Resistances for a 48-Lead VFQFN Package
Meters per Second
Theta JB
0
1
2
1.93°C/W
26.11°C/W
18.8°C/W
1.93°C/W
22.53°C/W
18.8°C/W
1.93°C/W
21.04°C/W
18.8°C/W
Theta JA
Theta JC
NOTE 1. Applicable to PCBs with two ground planes.
NOTE 2. ePAD size is 5.65mm x 5.65mm and connected to ground plane in PCB through 5 x5 Thermal Via Array.
NOTE 3. In devices where most of the heat exits through the bottom ePAD, JB is commonly used for thermal calculations.
©2016 Integrated Device Technology, Inc.
22
May 9, 2016
8V44S269 Datasheet
Reliability Information
Table 9. Thermal Resistances for a 48 Lead VFQFN Package
Meters per Second
Theta JB
0
1
2
1.93°C/W
26.11°C/W
18.8°C/W
1.93°C/W
22.53°C/W
18.8°C/W
1.93°C/W
21.04°C/W
18.8°C/W
Theta JA
Theta JC
Transistor Count
8V44S269 transistor count: 11,242
©2016 Integrated Device Technology, Inc.
23
May 9, 2016
8V44S269 Datasheet
48 Lead VFQFN Package Information
©2016 Integrated Device Technology, Inc.
24
May 9, 2016
8V44S269 Datasheet
48 Lead VFQFN Package Information
©2016 Integrated Device Technology, Inc.
25
May 9, 2016
8V44S269 Datasheet
Ordering Information
Table 10. Ordering Information
Part/Order Number
Marking
Package
Shipping Packaging
Tray
Temperature
-55°C to 105°C
-55°C to 105°C
8V44S269NLGI
8V44S269NLGI8
IDT8V44S269NLGI
IDT8V44S269NLGI
48 Lead VFQFN, Lead-Free
48 Lead VFQFN, Lead-Free
Tape & Reel
©2016 Integrated Device Technology, Inc.
26
May 9, 2016
8V44S269 Datasheet
Revision History Sheet
Table
Page
Description of Change
Date
5/9/2016
1
Corrected datasheet title head.
©2016 Integrated Device Technology, Inc.
27
May 9, 2016
Corporate Headquarters
6024 Silver Creek Valley Road
San Jose, CA 95138 USA
Sales
Tech Support
email: clocks@idt.com
1-800-345-7015 or 408-284-8200
Fax: 408-284-2775
www.IDT.com
DISCLAIMER Integrated Device Technology, Inc. (IDT) and its subsidiaries reserve the right to modify the products and/or specifications described herein at any time and at IDT’s sole discretion. All information in
this document, including descriptions of product features and performance, is subject to change without notice. Performance specifications and the operating parameters of the described products are determined
in the independent state and are not guaranteed to perform the same way when installed in customer products. The information contained herein is provided without representation or warranty of any kind, whether
express or implied, including, but not limited to, the suitability of IDT’s products for any particular purpose, an implied warranty of merchantability, or non-infringement of the intellectual property rights of others. This
document is presented only as a guide and does not convey any license under intellectual property rights of IDT or any third parties.
IDT’s products are not intended for use in applications involving extreme environmental conditions or in life support systems or similar devices where the failure or malfunction of an IDT product can be reasonably
expected to significantly affect the health or safety of users. Anyone using an IDT product in such a manner does so at their own risk, absent an express, written agreement by IDT.
While the information presented herein has been checked for both accuracy and reliability, Integrated Device Technology (IDT) assumes no responsibility for either its use or for the infringement of any patents or
other rights of third parties, which would result from its use. No other circuits, patents, or licenses are implied. This product is intended for use in normal commercial applications. Any other applications, such as
those requiring extended temperature ranges, high reliability or other extraordinary environmental requirements are not recommended without additional processing by IDT. IDT reserves the right to change any
circuitry or specifications without notice. IDT does not authorize or warrant any IDT product for use in life support devices or critical medical instruments.
Integrated Device Technology, IDT and the IDT logo are registered trademarks of IDT. Product specification subject to change without notice. Other trademarks and service marks used herein, including protected
names, logos and designs, are the property of IDT or their respective third party owners.
Copyright ©2016 Integrated Device Technology, Inc. All rights reserved.
厂商 型号 描述 页数 下载

IDT

 		8V41N010I [ Clock Generator for Cavium Processors ] 26 页

IDT

 		8V41N010NLGI [ Clock Generator for Cavium Processors ] 26 页

IDT

 		8V41N010NLGI8 [ Clock Generator for Cavium Processors ] 26 页

IDT

 		8V41N012 [ Clock Generator for Cavium Processors ] 31 页

IDT

 		8V41N012NLGI [ Clock Generator for Cavium Processors ] 31 页

IDT

 		8V41N012NLGI8 [ Clock Generator for Cavium Processors ] 31 页

IDT

 		8V41NS0412 [ NG Ultra Low Jitter HCSL Clock Generator ] 51 页

IDT

 		8V41NS0412NLGI [ NG Ultra Low Jitter HCSL Clock Generator ] 51 页

IDT

 		8V41NS0412NLGI8 [ NG Ultra Low Jitter HCSL Clock Generator ] 51 页

IDT

 		8V43042 [ FemtoClock Crystal-to-3 .3V LVPECL Frequency Synthesizer ] 19 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于达普

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：smail@ic72.com

服务时间：周一至周六 8:30-17:30

达普官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.226733s
