SZM-3166Z
3.3GHz to
3.6GHz 2W
Power Ampli-
fier
SZM-3166Z
3.3GHz to 3.6GHz 2W POWER AMPLIFIER
Package: QFN, 6mmx6mm
Product Description
Features
RFMD’s SZM-3166Z is a high linearity class AB Heterojunction Bipolar Transistor (HBT) amplifier
housed in a low-cost surface-mountable plastic Q-FlexN multi-chip module package. This HBT
amplifier is made with InGaP on GaAs device technology and fabricated with MOCVD for an
ideal combination of low cost and high reliability. This product is specifically designed for
802.16 customer premises equipment (CPE) terminals in the 3.3GHz to 3.6GHz bands. It can
run from a 3V to 5.2V supply. The external output match and bias adjustability allows load line
optimization for other applications covering 3.5GHz to 3.8GHz. It features an output power
detector, on/off power control and high RF overdrive robustness. A 20dB step attenuator fea-
ture can be utilized by switching the second stage Power up/down control. This product fea-
tures a RoHS compliant and Green package with matte tin finish, designated by the ‘Z’ suffix.
P1dB=35dBm at 5.2V
Three Stages of Gain:35dB
802.11g 54Mb/s Class AB Perfor-
mance
POUT=27dBm at 2.5% EVM, VCC
5.2V, 900mA
Active Bias with Adjustable Current
On-Chip Output Power Detector
Low Thermal Resistance
Vcc = 5V
Optimum Technology
Matching® Applied
GaAs HBT
Power Up/Down Control <1s
Attenuator Step 20dB at VPC2=0V
GaAs MESFET
InGaP HBT
SiGe BiCMOS
Class 1C ESD Rating
RFIN
RFOUT
Si BiCMOS
SiGe HBT
GaAs pHEMT
Si CMOS
Applications
802.16 WiMAX Driver or Output
Stage
Stage 1
Bias
Stage 2
Bias
Stage 3
Bias
Vbias = 5V
Si BJT
Fixed Wireless, WLL
GaN HEMT
RF MEMS
CPE Terminal Applications
Power
Detector
Power
Up/Down
Control
Specification
Typ.
Parameter
Unit
Condition
Min.
3300
Max.
3600
Frequency of Operation
Output Power at 1dB Compression
Gain
MHz
dBm
dBm
34.5
35.0
3.5Ghz
3.5Ghz, P =26dBm
32.0
38.0
-37
OUT
% EVM
2.5
-42
%
3.5GHz, P =27dBm, 802.11g 54Mb/s
OUT
Third Order Suppression
dBc
3.5GHz, P =23dBm per tone
OUT
Noise Figure
5.0
14.0
9.0
dB
dB
dB
V
3.5GHz
2.3GHz to 3.5GHz
2.3GHz to 3.5GHz
Worst Case Input Return Loss
Worst Case Output Return Loss
Supply voltage rang
11.0
6.0
5.2
Output Voltage Range
0.9 to 2.2
V
P
=10dBm to 33dBm
OUT
Quiescent Current
720
800
5.0
880
0.1
mA
mA

V
V
V
=5.2V
CC
PC
CC
Power Up Control Current
=5.2V, I
+I
+I
VCP1 VPC2 VPC3
V
Leakage Current
=5.2V, V =0V
PC
CC
Thermal Resistance
12.0
°C/W
junction - lead
Test Conditions: Z =50, V =5.2V, I =800mA, T =30°C
0
CC
Q
BP
RF MICRO DEVICES®, RFMD®, Optimum Technology Matching®, Enabling Wireless Connectivity™, PowerStar®, POLARIS™ TOTAL RADIO™ and UltimateBlue™ are trademarks of RFMD, LLC. BLUETOOTH is a trade-
mark owned by Bluetooth SIG, Inc., U.S.A. and licensed for use by RFMD. All other trade names, trademarks and registered trademarks are the property of their respective owners. ©2006, RF Micro Devices, Inc.
7628 Thorndike Road, Greensboro, NC 27409-9421 · For sales or technical
support, contact RFMD at (+1) 336-678-5570 or sales-support@rfmd.com.
DS110620
1 of 12
SZM-3166Z
Absolute Maximum Ratings
Parameter
Caution! ESD sensitive device.
Rating
1500
600
Unit
mA
mA
mA
V
Exceeding any one or a combination of the Absolute Maximum Rating conditions may
cause permanent damage to the device. Extended application of Absolute Maximum
Rating conditions to the device may reduce device reliability. Specified typical perfor-
mance or functional operation of the device under Absolute Maximum Rating condi-
tions is not implied.
VC3 Collector Bias Current (I
VC2 Collector Bias Current (I
VC1 Collector Bias Current (I
)
)
)
VC3
VC2
VC1
300
RoHS status based on EUDirective2002/95/EC (at time of this document revision).
**Device Voltage (V )
9.0
D
The information in this publication is believed to be accurate and reliable. However, no
responsibility is assumed by RF Micro Devices, Inc. ("RFMD") for its use, nor for any
infringement of patents, or other rights of third parties, resulting from its use. No
license is granted by implication or otherwise under any patent or patent rights of
RFMD. RFMD reserves the right to change component circuitry, recommended appli-
cation circuitry and specifications at any time without prior notice.
Power Dissipation (P
)
6
W
DISS
Operating Temp Range (T )
-40 to +85
30
°C
L
*Max RF output Power for 50con-
dBm
tinuous long term operation
Max RF Input Power (CW) for 50
29
5
dBm
dBm
output load
Max RF input Power for 10:1 VSWR
output load
Max Storage Temp
+150
+150
°C
°C
Operating Junction Temperature (T )
J
ESD Rating - Human Body Model
(HBM)
Class IC
*With specified application circuit
**No RF Drive
Operation of this device beyond any one of these limits may cause permanent dam-
age. For reliable continuous operation, the device voltage and current must not
exceed the maximum operating values specified in the table on page one.
Bias Conditions should also satisfy the following expression:
I V <(T -T )/R ,
TH j-l
D
D
J
L
Typical Performance 3.3GHz to 3.6GHz App Circuit (VCC=5.2V, ICQ=800mA, *802.11g 54Mb/s 64QAM)
Parameter
Unit
dB
3.3GHz 3.4GHz 3.5GHz 3.6Ghz 3.7GHz 3.8GHz
Gain @ P =26dBm
35
34.0
2.7
35
34.5
2.5
35
35.0
2.5
35
34.5
2.6
33
34.0
3.1
31.5
33.0
4.0
OUT
P
dBm
%
1dB
% EVM @ P =27dBm*
OUT
Current @ P
2.5% EVM*
mA
930
930
920
893
910
885
OUT
Input Return Loss
Output Return Loss
dB
dB
14.0
9
15.0
10
15.5
10
17.0
9
18.5
8
15.5
7
Simplified Device Schematic
31
30
40
1
GND
VC1
GND
NC
VBIAS12
NC
RFOUT
RFOUT
RFOUT
NC
RFIN
NC
RFOUT
RFOUT
VPC1
VPC2
GND
RFOUT
NC
21
20
10
11
GND
