Part Number: XZMYK53W-8ST
1.6 x 0.8 mm SMD Chip LED Lamp
Features
Package Schematics
● Ideal for indication light on hand held products
● Long life and robust package
● Standard Package: 4,000pcs/ Reel
● MSL (Moisture Sensitivity Level): 3
● RoHS compliant
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
DISCHARGE
SENSITIVE
DEVICES
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is ±0.15(0.006") unless otherwise noted.
3. Specifications are subject to change without notice.
Absolute Maximum Ratings
(TA=25°C)
Yellow
(AlGaInP)
Operating Characteristics
(TA=25°C)
Yellow
(AlGaInP)
Unit
Unit
V
Reverse Voltage
Forward Current
VR
IF
5
V
Forward Voltage (Typ.)
(IF=20mA)
VF
VF
IR
2
30
mA
Forward Voltage (Max.)
(IF=20mA)
Forward Current (Peak)
1/10 Duty Cycle
0.1ms Pulse Width
2.5
10
V
iFS
175
mA
Reverse Current (Max.)
(VR=5V)
uA
Power Dissipation
PD
TA
75
mW
°C
Wavelength of Peak
Emission CIE127-2007* (Typ.)
(IF=20mA)
Operating Temperature
Storage Temperature
-40 ~ +85
-40 ~ +85
λP
λD
590*
590*
nm
nm
Tstg
A Relative Humidity between 40% and 60% is recommended in
ESD-protected work areas to reduce static build up during assembly
process (Reference JEDEC/JESD625-A and JEDEC/J-STD-033)
Wavelength of Dominant
Emission CIE127-2007* (Typ.)
(IF=20mA)
Spectral Line Full Width
At Half-Maximum (Typ.)
(IF=20mA)
△λ
20
20
nm
pF
Capacitance (Typ.)
(VF=0V, f=1MHz)
C
Luminous Intensity
Wavelength
CIE127-2007*
nm
Viewing
Angle
2θ 1/2
Part
Number
Emitting
Color
Emitting
Material
CIE127-2007*
(IF=20mA)
mcd
Lens-color
λP
min.
80*
typ.
XZMYK53W-8ST
Yellow
AlGaInP
Water Clear
208*
590*
100°
*Luminous intensity value and wavelength are in accordance with CIE127-2007 standards.
Jun 01,2017
XDSB8568 V1-Z Layout: Maggie L.
P. 1/4
