Part Number: XZM2CRK53W-1
1.6 x 0.8mm SMD Chip LED Lamp
Features
Package Schematics
● Ideal for indication light on hand held products
● Long life and robust package
● Standard Package: 2,000pcs/ Reel
● MSL (Moisture Sensitivity Level): 3
● Halogenꢀfree
● RoHS compliant
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
DISCHARGE
SENSITIVE
DEVICES
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is ±0.1(0.004") unless otherwise noted.
3. Specifications are subject to change without notice.
Absolute Maximum Ratings
(TA=25°C)
Red
(AlGaInP)
Operating Characteristics
Unit
Red
(AlGaInP)
Unit
V
(TA=25°C)
Forward Voltage (Typ.)
(IF=20mA)
Reverse Voltage
Forward Current
VR
IF
5
V
VF
VF
IR
2.2
2.8
10
30
mA
Forward Voltage (Max.)
(IF=20mA)
V
Forward Current (Peak)
1/10 Duty Cycle
0.1ms Pulse Width
iFS
150
mA
mW
°C
Reverse Current (Max.)
(VR=5V)
ꢁA
Power Dissipation
PD
TA
84
Wavelength of Peak
Emission CIE127ꢀ2007* (Typ.)
(IF=20mA)
λP
λD
640*
625*
nm
nm
Operating Temperature
Storage Temperature
ꢀ40 ~ +85
ꢀ40 ~ +85
Wavelength of Dominant
Emission CIE127ꢀ2007* (Typ.)
(IF=20mA)
Tstg
A Relative Humidity between 40% and 60% is recommended in
ESDꢀprotected work areas to reduce static build up during assembly
process (Reference JEDEC/JESD625ꢀA and JEDEC/JꢀSTDꢀ033)
Spectral Line Full Width
At HalfꢀMaximum (Typ.)
(IF=20mA)
△λ
20
27
nm
pF
Capacitance (Typ.)
(VF=0V, f=1MHz)
C
Luminous Intensity
Wavelength
CIE127ꢀ2007*
nm
Viewing
Angle
2θ 1/2
Part
Number
Emitting
Color
Emitting
Material
CIE127ꢀ2007*
(IF=20mA)
mcd
Lensꢀcolor
λP
min.
typ.
700
200*
1095
347*
XZM2CRK53Wꢀ1
Red
AlGaInP
Water Clear
640*
120°
*Luminous intensity value and wavelength are in accordance with CIE127ꢀ2007 standards.
Nov 26,2020
XDSB7137 V5ꢀX Layout: Maggie L.
P. 1/4
