Part Number: XZM2CRK53W-8
1.6 x 0.8mm SMD Chip LED Lamp
Features
Package Schematics
● VersoLEDs: Versatile Solutions
● Ideal for indication light on hand held products
● Long life and robust package
● Standard Package: 2,000pcs/ Reel
● MSL (Moisture Sensitivity Level): 3
● Halogenꢀfree
● RoHS compliant
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
DISCHARGE
SENSITIVE
DEVICES
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is ±0.15(0.006") unless otherwise noted.
3. Specifications are subject to change without notice.
Absolute Maximum Ratings
(TA=25°C)
Red
(AlGaInP)
Operating Characteristics
(TA=25°C)
Red
(AlGaInP)
Unit
Unit
V
Reverse Voltage
Forward Current
VR
IF
5
V
Forward Voltage (Typ.)
(IF=20mA)
VF
VF
IR
2.2
2.8
10
30
mA
Forward Voltage (Max.)
(IF=20mA)
Forward Current (Peak)
1/10 Duty Cycle
0.1ms Pulse Width
V
iFS
150
mA
Reverse Current (Max.)
(VR=5V)
ꢁA
Power Dissipation
PD
TA
84
mW
°C
Wavelength of Peak
EmissionCIE127ꢀ2007* (Typ.)
(IF=20mA)
Operating Temperature
Storage Temperature
ꢀ40 ~ +85
ꢀ40 ~ +85
λP
λD
640*
625*
nm
nm
Tstg
A Relative Humidity between 40% and 60% is recommended in
ESDꢀprotected work areas to reduce static build up during assembly
process (Reference JEDEC/JESD625ꢀA and JEDEC/JꢀSTDꢀ033)
Wavelength of Dominant
Emission CIE127ꢀ2007*(Typ.)
(IF=20mA)
Spectral Line Full Width
At HalfꢀMaximum (Typ.)
(IF=20mA)
△λ
20
27
nm
pF
Capacitance (Typ.)
(VF=0V, f=1MHz)
C
Luminous Intensity
Wavelength
CIE127ꢀ2007*
nm
Viewing
Angle
2θ 1/2
Part
Number
Emitting
Color
Emitting
Material
CIE127ꢀ2007*
(IF=20mA)
mcd
Lensꢀcolor
λP
min.
typ.
2300
500*
2690
895*
XZM2CRK53Wꢀ8
Red
AlGaInP
Water Clear
640*
60°
*Luminous intensity value and wavelength are in accordance with CIE127ꢀ2007 standards.
Nov 27,2020
XDSB7768 V6ꢀX Layout: Maggie L.
