Operating rate
<= 18000 cycles/hour no-load
<= 1200 cycles/hour under load
Mechanical durability
Electrical durability
Average coil consumption
Drop-out voltage threshold
Operating time
10000000 cycles
100000 cycles for resistive load depending on mounting position and working environment
0.9 W
>= 0.1 Uc
20 ms
Reset time
20 ms
Average resistance
Rated operational voltage limits
Protection category
Operating position
Product weight
160 Ohm at 20 °C +/- 10 %
9.6...13.2 V DC
RT I
Any position
0.037 kg
Device presentation
Complete product
Environment
Dielectric strength
1300 V AC between contacts with micro disconnection insulation
2000 V AC between coil and contact with reinforced insulation
2000 V AC between poles with basic insulation
Product certifications
CE
CSA
GOST
RoHS
UL
REACH
Lloyd's
Standards
EN/IEC 61810-1
UL 508
CSA C22.2 No 14
Ambient air temperature for storage
Ambient air temperature for operation
Vibration resistance
-40...85 °C
-40...55 °C
3 gn (f = 10...150 Hz), amplitude +/- 1 mm (on 5 cycles in operation)
5 gn (f = 10...150 Hz), amplitude +/- 1 mm (on 5 cycles not operating)
IP degree of protection
Shock resistance
IP40 conforming to EN/IEC 60529
10 gn in operation
30 gn not operating
Pollution degree
2
Offer Sustainability
Sustainable offer status
RoHS (date code: YYWW)
Green Premium product
Compliant - since 0710 - Schneider Electric declaration of conformity
Schneider Electric declaration of conformity
REACh
Reference not containing SVHC above the threshold
Reference not containing SVHC above the threshold
Product environmental profile
Product end of life instructions
Available
Product Environmental Profile
Need no specific recycling operations
Contractual warranty
Warranty period
18 months
