XZMDK45W

型号:

XZMDK45W

描述:

3.5x2.8毫米SMD贴片LED LAMP[ 3.5x2.8 mm SMD CHIP LED LAMP ]

品牌:

ETC[ ETC ]

页数:

3 页

PDF大小:

220 K

part number:
3.5x2.8 mm SMD CHIP LED LAMP
XZMDK45W
www.SunLED.com
Features
SINGLE COLOR.
SUITABLE FOR ALL SMT ASSEMBLY AND SOLDER
PROCESS.
AVAILABLE ON TAPE AND REEL.
IDEAL FOR BACKLIGHTING.
PACKAGE : 1500PCS / REEL.
RoHS COMPLIANT.
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is ± 0.25(0.01") unless otherwise noted.
Operating Characteristics
(T =25°C)
Absolute maximum ratings
MDK
MDK
(InGaAlP)
Unit
Unit
(InGaAlP)
A
(TA=25°C)
Forward voltage (typ.)
(I =20mA)
Reverse voltage
V
R
5
V
V
F
F
1.95
2.5
10
V
V
F
Forward current
IF
30
mA
Forward voltage (max.)
(I =20mA)
V
Forward current (peak)
1/10Duty cycle
0.1ms pulse width
F
iFS
185
mA
Reverse current
(V =5V)
IR
uA
R
Power dissipation
P
T
A
75
mW
°C
Wavelength at peak
emission
(IF=20mA)
Operating temperature
Storage temperature
T
-40 ~ +85
-40 ~ +85
λ peak
λ D
650
635
nm
nm
Tstg
Wavelength of Dominant
emission
(IF=20mA)
Spectral Line half-width
(IF=20mA)
∆λ
28
35
nm
pF
Capacitance
(V =0V, f=1MHz)
C
F
Luminous
Wavelength
Viewing
Angle
2 θ 1/2
Part
Number
Emitting
Color
Emitting
Material
Intensity
(IF=20mA)
mcd
Lens-color
nm
λ P
min.
70
typ.
198
XZMDK45W
Red
InGaAlP
Water Clear
650
120°
Published Date : MAR 15,2005
Drawing No :XDSA0532
V4
Checked : B.L.LIU
P. 1/3
part number:
3.5x2.8 mm SMD CHIP LED LAMP
XZMDK45W
www.SunLED.com
MDK
Published Date : MAR 15,2005
Drawing No :XDSA0532
V4
Checked : B.L.LIU
P. 2/3
part number:
3.5x2.8 mm SMD CHIP LED LAMP
XZMDK45W
www.SunLED.com
Recommended Soldering Pattern (Units : mm;Tolerance:±0.1)
Tape Specification (Units : mm)
If special sorting is required (e.g. binning based on forward voltage, luminous intensity, or wavelength),
the typical accuracy of the sorting process is as follows:
1. Wavelength: +/-1nm
2. Luminous Intensity: +/-15%
3. Forward Voltage: +/-0.1V
Note: Accuracy may depend on the sorting parameters.
Published Date : MAR 15,2005
Drawing No :XDSA0532
V4
Checked : B.L.LIU
P. 3/3
