SZMMBZH20VAWT1G

型号:

SZMMBZH20VAWT1G

品牌:

ONSEMI[ ONSEMI ]

页数:

5 页

PDF大小:

109 K

MMBZHxxVAWT1G Series,
SZMMBZHxxVAWT1G Series
Diodes, Dual 40 Watt Peak
Power, High Temperature
SC70 Dual Common Anode Zeners
www.onsemi.com
These dual monolithic silicon Zener diodes are designed for
applications requiring transient overvoltage protection capability. They
are intended for use in voltage and ESD sensitive equipment such as
computers, printers, business machines, communication systems,
medical equipment and other applications. Their dual junction common
anode design protects two separate lines using only one package. These
devices are high temperature rated and ideal for use in high reliability
applications where board space is at a premium.
SC70
CASE 419
STYLE 4
Features
CATHODE 1
CATHODE 2
3 ANODE
SC70 Package Allows Either Two Separate Unidirectional
Configurations or a Single Bidirectional Configuration
Standard Zener Breakdown Voltage Range: 15 33 V
Peak Power 40 W @ 1.0 ms (Unidirectional),
MARKING DIAGRAM
per Figure 5 Waveform
ESD Rating:
Class 3B (> 16 kV) per the Human Body Model
Class C (> 400 V) per the Machine Model
XX MG
G
Low Leakage < 5.0 mA
1
Flammability Rating UL 94 V0
XX = Specific Device Code
175°C T
Rated for High Temperature, Mission Critical
J(MAX)
Applications
M
G
= Date Code
= PbFree Package
(Note: Microdot may be in either location)
SZ Prefix for Automotive and Other Applications Requiring Unique
Site and Control Change Requirements
These are PbFree Devices*
ORDERING INFORMATION
Mechanical Characteristics:
Device
Package
Shipping
CASE: Void-free, transfer-molded, thermosetting plastic case
FINISH: Corrosion resistant finish, easily solderable
MAXIMUM CASE TEMPERATURE FOR SOLDERING PURPOSES:
260°C for 10 Seconds
Package designed for optimal automated board assembly
Small package size for high density applications
Available in 8 mm Tape and Reel
MMBZHxxVAWT1G
SC70
(PbFree)
3,000 /
Tape & Reel
SZMMBZHxxVAWT1G
SC70
(PbFree)
3,000 /
Tape & Reel
†For information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
Use the Device Number to order the 7 inch/3,000 unit reel.
DEVICE MARKING INFORMATION
See specific marking information in the device marking
column of the table on page 2 of this data sheet.
© Semiconductor Components Industries, LLC, 2018
1
Publication Order Number:
December, 2018 Rev. 0
MMBZH27VAW/D
MMBZHxxVAWT1G Series, SZMMBZHxxVAWT1G Series
MAXIMUM RATINGS
Rating
Symbol
Value
Unit
Peak Power Dissipation @ 1.0 ms (Note 1)
P
pk
W
@ T 25°C
40
L
Total Power Dissipation on FR5 Board (Note 2)
°P °
D
°
@ T = 25°C
200
1.6
mW
A
Derate above 25°C
mW/°C
Thermal Resistance JunctiontoAmbient
Junction and Storage Temperature Range
R
315
°C/W
°C
q
JA
T , T
J
55 to +175
stg
Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality
should not be assumed, damage may occur and reliability may be affected.
1. Nonrepetitive current pulse per Figure 5 and derate above T = 25°C per Figure 6.
A
2. FR5 = 1.0 x 0.75 x 0.62 in.
ELECTRICAL CHARACTERISTICS
(T = 25°C unless otherwise noted)
A
UNIDIRECTIONAL (Circuit tied to Pins 1 and 3 or 2 and 3)
Symbol
Parameter
I
I
PP
Maximum Reverse Peak Pulse Current
I
F
V
C
Clamping Voltage @ I
PP
V
RWM
Working Peak Reverse Voltage
I
R
Maximum Reverse Leakage Current @ V
RWM
V
BR
Breakdown Voltage @ I
T
V
C
V
V
BR RWM
V
I
Test Current
I
V
F
T
R
T
I
QV
Maximum Temperature Coefficient of V
Forward Current
BR
BR
I
F
V
Forward Voltage @ I
F
F
I
PP
Z
ZT
Maximum Zener Impedance @ I
Reverse Current
ZT
I
ZK
UniDirectional Zener
Z
ZK
Maximum Zener Impedance @ I
ZK
ELECTRICAL CHARACTERISTICS (T = 25°C unless otherwise noted)
A
UNIDIRECTIONAL (Circuit tied to Pins 1 and 3 or Pins 2 and 3)
(V = 0.9 V Max @ I = 10 mA)
F
F
Breakdown Voltage
V
@ I (Note 4)
C
PP
I
V
@
RWM
nA
R
V
(Note 3) (V)
@ I
V
I
PP
V
RWM
QV
BR
T
C
BR
Device
mV/5C
Volts
12
Min
Nom
15
Max
mA
1.0
1.0
1.0
1.0
V
A
Marking
Device*
MMBZH15VAWT1G
MMBZH20VAWT1G*
MMBZH27VAWT1G*
MMBZH33VAWT1G*
AJ
50
50
50
50
14.25
19.00
25.65
31.35
15.75
21.00
28.35
34.65
21
28
40
46
1.9
1.4
12.3
17.2
24.3
30.4
17
20
22
27
1.0
26
33
0.87
3. V measured at pulse test current I at an ambient temperature of 25°C.
BR
T
4. Surge current waveform per Figure 5 and derate per Figure 6
*AECQ release available upon request.
www.onsemi.com
2

MMBZHxxVAWT1G Series, SZMMBZHxxVAWT1G Series
TYPICAL CHARACTERISTICS
18
15
12
9
1000
100
10
1
6
3
0
0.1
0.01
40
0
+50
+100
+150
40
+25
+85
+125
TEMPERATURE (°C)
TEMPERATURE (°C)
Figure 1. Typical Breakdown Voltage
versus Temperature
Figure 2. Typical Leakage Current
versus Temperature
(Upper curve for each voltage is bidirectional mode,
lower curve is unidirectional mode)
320
300
280
240
200
160
120
80
250
200
ALUMINA SUBSTRATE
5.6 V
150
100
50
15 V
FR5 BOARD
40
0
0
0
1
2
3
0
25
50
75
100
125
150
175
BIAS (V)
TEMPERATURE (°C)
Figure 3. Typical Capacitance versus Bias Voltage
(Upper curve for each voltage is unidirectional mode,
lower curve is bidirectional mode)
Figure 4. Steady State Power Derating Curve
www.onsemi.com
3
MMBZHxxVAWT1G Series, SZMMBZHxxVAWT1G Series
TYPICAL CHARACTERISTICS
100
PULSE WIDTH (t ) IS DEFINED
P
90
80
70
60
50
40
30
20
10
0
AS THAT POINT WHERE THE
PEAK CURRENT DECAYS TO
t 10 ms
r
50% OF I .
PP
100
PEAK VALUE I
PP
I
PP
HALF VALUE −
2
50
0
t
P
0
1
2
3
4
0
25
50
75
100
125
150 175 200
t, TIME (ms)
T , AMBIENT TEMPERATURE (°C)
A
Figure 5. Pulse Waveform
Figure 6. Pulse Derating Curve
100
100
10
1
RECTANGULAR
WAVEFORM, T = 25°C
RECTANGULAR
WAVEFORM, T = 25°C
A
A
BIDIRECTIONAL
BIDIRECTIONAL
10
UNIDIRECTIONAL
UNIDIRECTIONAL
1
0.1
1
10
100
1000
0.1
1
10
100
1000
PW, PULSE WIDTH (ms)
PW, PULSE WIDTH (ms)
Figure 7. Maximum Nonrepetitive Surge
Figure 8. Maximum Nonrepetitive Surge
Power, Ppk versus PW
Power, Ppk(NOM) versus PW
Power is defined as V
x I (pk) where V
is
Power is defined as V (NOM) x I (pk) where
Z Z
RSM
Z
RSM
the clamping voltage at I (pk).
V (NOM) is the nominal Zener voltage measured at
Z
Z
the low test current used for voltage classification.
www.onsemi.com
4
MMBZHxxVAWT1G Series, SZMMBZHxxVAWT1G Series
PACKAGE DIMENSIONS
SC70 (SOT323)
CASE 41904
ISSUE N
NOTES:
1. DIMENSIONING AND TOLERANCING PER ANSI Y14.5M, 1982.
2. CONTROLLING DIMENSION: INCH.
D
e1
MILLIMETERS
INCHES
DIM
A
A1
A2
b
c
D
E
e
e1
L
MIN
0.80
0.00
NOM
0.90
0.05
0.70 REF
0.35
0.18
2.10
1.24
1.30
0.65 BSC
0.38
MAX
1.00
0.10
MIN
0.032
0.000
NOM
0.035
0.002
0.028 REF
0.014
0.007
0.083
0.049
0.051
0.026 BSC
0.015
MAX
0.040
0.004
3
E
H
E
1
2
0.30
0.10
1.80
1.15
1.20
0.40
0.25
2.20
1.35
1.40
0.012
0.004
0.071
0.045
0.047
0.016
0.010
0.087
0.053
0.055
b
e
0.20
2.00
0.56
2.40
0.008
0.079
0.022
0.095
H
2.10
0.083
E
c
STYLE 4:
A
A2
PIN 1. CATHODE
2. CATHODE
3. ANODE
0.05 (0.002)
L
A1
SOLDERING FOOTPRINT*
0.65
0.025
0.65
0.025
1.9
0.075
0.9
0.035
0.7
0.028
mm
inches
ǒ
Ǔ
SCALE 10:1
*For additional information on our PbFree strategy and soldering
details, please download the ON Semiconductor Soldering and
Mounting Techniques Reference Manual, SOLDERRM/D.
ON Semiconductor and
are trademarks of Semiconductor Components Industries, LLC dba ON Semiconductor or its subsidiaries in the United States and/or other countries.
ON Semiconductor owns the rights to a number of patents, trademarks, copyrights, trade secrets, and other intellectual property. A listing of ON Semiconductor’s product/patent
coverage may be accessed at www.onsemi.com/site/pdf/PatentMarking.pdf. ON Semiconductor reserves the right to make changes without further notice to any products herein.
ON Semiconductor makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does ON Semiconductor assume any liability
arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation special, consequential or incidental damages.
Buyer is responsible for its products and applications using ON Semiconductor products, including compliance with all laws, regulations and safety requirements or standards,
regardless of any support or applications information provided by ON Semiconductor. “Typical” parameters which may be provided in ON Semiconductor data sheets and/or
specifications can and do vary in different applications and actual performance may vary over time. All operating parameters, including “Typicals” must be validated for each customer
application by customer’s technical experts. ON Semiconductor does not convey any license under its patent rights nor the rights of others. ON Semiconductor products are not
designed, intended, or authorized for use as a critical component in life support systems or any FDA Class 3 medical devices or medical devices with a same or similar classification
in a foreign jurisdiction or any devices intended for implantation in the human body. Should Buyer purchase or use ON Semiconductor products for any such unintended or unauthorized
application, Buyer shall indemnify and hold ON Semiconductor and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and
expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such
claim alleges that ON Semiconductor was negligent regarding the design or manufacture of the part. ON Semiconductor is an Equal Opportunity/Affirmative Action Employer. This
literature is subject to all applicable copyright laws and is not for resale in any manner.
PUBLICATION ORDERING INFORMATION
LITERATURE FULFILLMENT:
N. American Technical Support: 8002829855 Toll Free
USA/Canada
Europe, Middle East and Africa Technical Support:
Phone: 421 33 790 2910
ON Semiconductor Website: www.onsemi.com
Order Literature: http://www.onsemi.com/orderlit
Literature Distribution Center for ON Semiconductor
19521 E. 32nd Pkwy, Aurora, Colorado 80011 USA
Phone: 3036752175 or 8003443860 Toll Free USA/Canada
Fax: 3036752176 or 8003443867 Toll Free USA/Canada
Email: orderlit@onsemi.com
For additional information, please contact your local
Sales Representative
MMBZH27VAW/D
厂商 型号 描述 页数 下载

ETC

SZM-01T-P0.7 可拆卸式压接式的线对线连接器[ Disconnectable Crimp style Wire-to-wire connectors ] 5 页

SIRENZA

SZM-2066Z 2.4-2.7GHz 2W功率放大器[ 2.4-2.7GHz 2W Power Amplifier ] 13 页

SIRENZA

SZM-2166Z 2.3-2.7GHz 2W功率放大器[ 2.3-2.7GHz 2W Power Amplifier ] 16 页

SIRENZA

SZM-2166Z-EVB1 2.3-2.7GHz 2W功率放大器[ 2.3-2.7GHz 2W Power Amplifier ] 16 页

SIRENZA

SZM-2166Z-EVB2 2.3-2.7GHz 2W功率放大器[ 2.3-2.7GHz 2W Power Amplifier ] 16 页

SIRENZA

SZM-2166Z-EVB3 2.3-2.7GHz 2W功率放大器[ 2.3-2.7GHz 2W Power Amplifier ] 16 页

SIRENZA

SZM-3066Z 3.3-3.8GHz 2W功率放大器[ 3.3-3.8GHz 2W Power Amplifier ] 9 页

SIRENZA

SZM-3166Z 3.3-3.6GHz 2W功率放大器[ 3.3-3.6GHz 2W Power Amplifier ] 9 页

SIRENZA

SZM-3166Z-EVB1 3.3-3.6GHz 2W功率放大器[ 3.3-3.6GHz 2W Power Amplifier ] 9 页

ETC

SZM-41T-P0.7 可拆卸式压接式的线对线连接器[ Disconnectable Crimp style Wire-to-wire connectors ] 5 页

PDF索引:

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引:

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

0.313466s
