Product data sheet
Characteristics
RXM2AB3JD
Miniature Plug-in relay - Zelio RXM 2 C/O 12 V
DC 12 A with LED
Main
Range of product
Zelio Relay
Miniature
Plug-in relay
RXM
Series name
Product or component type
Device short name
Contacts type and composition
[Uc] control circuit voltage
2 C/O
12 V DC
[Ithe] conventional enclosed thermal
current
12 A at -40...55 °C
Status LED
With
Control type
Without lockable test button
20 %
Utilisation coefficient
Complementary
Shape of pin
Flat
[Ui] rated insulation voltage
250 V conforming to IEC
300 V conforming to UL
300 V conforming to CSA
[Uimp] rated impulse withstand voltage
Contacts material
4 kV for 1.2/50 µs
AgNi
[Ie] rated operational current
12 A at 28 V DC (NO) conforming to IEC
12 A at 250 V AC (NO) conforming to IEC
6 A at 28 V DC (NC) conforming to IEC
6 A at 250 V AC (NC) conforming to IEC
12 A at 28 V DC conforming to UL
12 A at 277 V AC conforming to UL
Maximum switching voltage
Load current
250 V conforming to IEC
12 A at 250 V AC
12 A at 28 V DC
Maximum switching capacity
Minimum switching capacity
Operating rate
3000 VA/336 W
170 mW at 10 mA, 17 V
<= 18000 cycles/hour no-load
<= 1200 cycles/hour under load
Mechanical durability
Electrical durability
10000000 cycles
100000 cycles for resistive load
Dec 24, 2018
1
