SZMD15C
150 W, 15 V
Transient Voltage Suppressors
for ESD Protection
Elektronische Bauelemente
RoHS Compliant Product
A suffix of “-C” specifies halogen & lead-free
SOT-23
FEATURES
A
L
z
z
z
SOT-23 package for surface mount application
Protects 15V components
Protects two unidirectional line or one bi-direction line
3
3
Top View
C B
1
1
2
2
K
F
E
D
APPLICATIONS
G
H
REF.
J
z
z
z
z
z
Cellular Handsets and Accessories
Portable devices
Industrial Controls
Set -Top Box
Millimeter
Millimeter
REF.
Min.
Max.
3.00
2.55
1.40
1.15
Min.
0.10 REF.
0.55 REF.
0.08 0.15
Max.
A
B
C
D
2.80
2.25
1.20
0.90
G
H
J
K
0.5 REF.
E
F
1.80
0.30
2.00
0.50
L
0.95 TYP.
Servers, Notebook, and Desktop PC
1
3
Marking Code
2
KDL
ABSOLUTE RATINGS (Tamb = 25°C )
Rating
Symbol
Value
Units
IEC 61000-4-2 (ESD)
Air contact
Contact discharge
±15
±8
kV
kV
ESD voltage
Per human body model
16
kV
Total power dissipation on FR-5 Board (Note 1) @ TA=25℃
Junction and storage temperature range
Lead solder temperature – maximum (10 Second duration)
PD
TJ, TSTG
TL
150
-55 ~ +150
mW
°C
°C
260
Stresses exceeding Maximum Ratings may damage the device. Maximum Rating are stress ratings only. Functional operation above the Recommended
Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect device reliability.
1. FR-5 = 1.0*0.75*0.62 in.
ELECTRICAL CHARACTERISTICS
(Ratings at 25°C ambient temperature unless otherwise specified. VF = 0.9V at IF = 10mA)
VC (V)
@ Max IPP
(Note 3)
Max
IPP
(A)
(Note 3)
Max
5
C
(pF)
(Note 4)
Typ
VRWM
(V)
IR(uA)
@ VRWM
V
BR (V)
IT
PPK
(W)*
Device
@ IT (Note 2) (mA)
Max
15
Max
0.1
Min
mA
5.0
Max
150
SZMD15C
16.8
30
45
1. Other voltages available upon request.
2. VBR is measured with a pulse test current IT at an ambient temperature of 25℃
3. Surge current waveform per Figure 3.
4. Measured at 1MHz 0V.
http://www.SeCoSGmbH.com/
Any changes of specification will not be informed individually.
01-June-2010 Rev. A
Page 1 of 2
