8N80
Power MOSFET
ABSOLUTE MAXIMUM RATINGS (TC=25°C, unless otherwise specified)
PARAMETER
SYMBOL
VDSS
VGSS
ID
RATINGS
800
UNIT
V
Drain-Source Voltage
Gate-Source Voltage
±30
V
Drain Current (Continuous) (TC=25°C)
Drain Current (Pulsed) (Note 1)
Avalanche Current (Note 1)
8
A
IDM
32
A
IAR
8
A
Single Pulse Avalanche Energy (Note 2)
Repetitive Avalanche Energy (Note 1)
Peak Diode Recovery dv/dt (Note 3)
EAS
850
mJ
mJ
V/ns
EAR
17.8
4.5
dv/dt
TO-220
178
TO-220F1
TO-220F2
TO-220F
TO-220
59
Power Dissipation
W
62
38
PD
1.43
0.47
0.5
TO-220F1
TO-220F2
TO-220F
Linear Derating Factor above TC=25°C
W/°C
0.304
+150
-55 ~ +150
Junction Temperature
Storage Temperature
TJ
°C
°C
TSTG
Note: 1. Repetitive Rating: Pulse width limited by maximum junction temperature
2. L = 25mH, IAS = 8A, VDD = 50V, RG = 25 Ω, Starting TJ = 25°C
3. ISD ≤ 8A, di/dt ≤ 200A/µs, VDD ≤ BVDSS, Starting TJ = 25°C
4. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied
THERMAL DATA
PARAMETER
SYMBOL
RATINGS
62.5
0.7
UNIT
°C/W
Junction to Ambient
Junction to Case
θJA
TO-220
TO-220F1
TO-220F2
TO-220F
2.1
θJC
°C/W
2.0
3.25
ELECTRICAL CHARACTERISTICS (TC=25°C, unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN TYP MAX UNIT
OFF CHARACTERISTICS
Drain-Source Breakdown Voltage
Breakdown Voltage Temperature Coefficient
BVDSS
△BVDSS/△TJ
ID=250µA, VGS=0V
800
V
Reference to 25°C, ID=250µA
DS=800V, VGS=0V
0.5
V/°C
V
10
Drain-Source Leakage Current
IDSS
IGSS
µA
VDS=640V, TC=125°C
VGS=±30V, VDS=0V
100
Gate- Source Leakage Current
ON CHARACTERISTICS
Gate Threshold Voltage
±100 nA
VGS(TH)
RDS(ON)
gFS
VDS=VGS, ID=250µA
VGS=10V, ID=4A
VDS=50V, ID=4A
3.0
5.0
V
Ω
S
Static Drain-Source On-State Resistance
Forward Transconductance (Note 1)
DYNAMIC PARAMETERS
Input Capacitance
1.18 1.45
5.6
CISS
COSS
CRSS
1580 2050 pF
VGS=0V, VDS=25V,
f=1.0MHz
Output Capacitance
135 175
13 17
pF
pF
Reverse Transfer Capacitance
