SZP-5026Z-EVB2

型号：

SZP-5026Z-EVB2

描述：

的4.9GHz到5.9GHz 2W的InGaP放大器[ 4.9GHz to 5.9GHz 2W InGaP AMPLIFIER ]

品牌：

SIRENZA[ SIRENZA MICRODEVICES ]

页数：

14 页

PDF大小：

398 K

下载PDF手册
SZP-5026Z
4.9GHz to
5.9GHz 2W
InGaP Ampli-
fier
Preliminary
SZP-5026Z
4.9GHz to 5.9GHz 2W InGaP AMPLIFIER
RFMD Green, RoHS Compliant, Pb-Free
Package: Proprietary SOF-26
Product Description
Features
RFMD’s SZP-5026Z is a high-linearity, single-stage, class AB Heterojunction Bipolar
Transistor (HBT) power amplifier. It is designed with InGaP-on-GaAs device technol-
ogy and fabricated with MOCVD for an ideal combination of low cost and high reli-
ability. This product is specifically designed for use as a driver or final stage power
amp for 802.16 equipment in the 4.9GHz to 5.9GHz bands. It is pre-matched on
both ports to simplify external application circuit design. It features an input power
detector, on/off power control, ESD protection, excellent overall robustness, and a
hand reworkable and thermally enhanced surface-mount SOF-26 package.
„ P1dB=33dBm @ 5V
„ 802.11a 54Mb/s Class AB Per-
formance
„ POUT=25dBm @ 2.5% EVM,
5.9GHz, 5V, 680mA
„ On-Chip Input Power Detector
„ Internally Prematched Input and
Output
Optimum Technology
Matching® Applied
Vcc
„ Proprietary Low Thermal Resis-
GaAs HBT
tance Package
GaAs MESFET
„ Power Up/Down Control<1μs
SZP-5026
InGaP HBT
9
SiGe BiCMOS
RFOUT
Applications
„ 802.16 WiMAX Driver or Output
Stage
RFIN
Si BiCMOS
SiGe HBT
GaAs pHEMT
Si CMOS
Active Bias
Vbias
„ 5GHz 802.11 WLAN and ISM
Applications
Power
Power
Detector
Up/Down
Control
Si BJT
GaN HEMT
RF MEMS
Specification
Typ.
Parameter
Unit
Condition
Min.
4900
Max.
5900
Frequency of Operation
Output Power at 1dB Compression
Small Signal Gain
EVM at 25dBm Output Power
Third Order Suppression
MHz
dBm
dBm
%
32.5
8.8
2.5
5.9GHz
5.9GHz
5.9GHz, 802.11a 54Mb/s
5.9GHz, P =23dBm per tone
OUT
-45.0
dBc
Noise Figure
5.4
19.0
13.0
dB
dB
dB
V
5.9GHz
5.7GHz to 5.9GHz
5.7GHz to 5.9GHz
Worst Case Input Return Loss
Worst Case Output Return Loss
Output Voltage Range
0.8
2.0
P
=10dBm to 33dBm
OUT
Quiescent Current
602
2.7
mA
mA
V
V
V
=5V
CC
PC
CC
Power Up Control Current
=5V
=5V, V =0V
V
Leakage Current
100
μA
CC
PC
Thermal Resistance
14.0
°C/W
Junction-to-Lead
Test Conditions: Z =50Ω, V =5V, I =602mA, T =30°C
0
CC
Q
BP
RF MICRO DEVICES®, RFMD®, Optimum Technology Matching®, Enabling Wireless Connectivity™, PowerStar®, POLARIS™ TOTAL RADIO™ and UltimateBlue™ are trademarks of RFMD, LLC. BLUETOOTH is a trade-
mark owned by Bluetooth SIG, Inc., U.S.A. and licensed for use by RFMD. All other trade names, trademarks and registered trademarks are the property of their respective owners. ©2006, RF Micro Devices, Inc.
7628 Thorndike Road, Greensboro, NC 27409-9421 · For sales or technical
support, contact RFMD at (+1) 336-678-5570 or sales-support@rfmd.com.
EDS-105366 Rev C
1 of 14
Preliminary
SZP-5026Z
Absolute Maximum Ratings
Parameter
Caution! ESD sensitive device.
Rating
1500
6.0
Unit
mA
V
Exceeding any one or a combination of the Absolute Maximum Rating conditions may
cause permanent damage to the device. Extended application of Absolute Maximum
Rating conditions to the device may reduce device reliability. Specified typical perfor-
mance or functional operation of the device under Absolute Maximum Rating condi-
tions is not implied.
VC1 Collector Bias Current (I
)
VC1
Device Voltage (V )*
CC
Power Dissipation (P
)
6
W
DISS
RoHS status based on EUDirective2002/95/EC (at time of this document revision).
Operating Lead Temperature (T )
L
-40 to +85
30
°C
The information in this publication is believed to be accurate and reliable. However, no
responsibility is assumed by RF Micro Devices, Inc. ("RFMD") for its use, nor for any
infringement of patents, or other rights of third parties, resulting from its use. No
license is granted by implication or otherwise under any patent or patent rights of
RFMD. RFMD reserves the right to change component circuitry, recommended appli-
cation circuitry and specifications at any time without prior notice.
**Max RF output Power for 50Ω con-
dBm
tinuous long term operation
Max Modulated (***OFDM) RF Input
28
21
dBm
dBm
Power for 50Ω output load
Max Modulated (***OFDM) RF Input
Power for 10:1 VSWR output load
Storage Temperature Range
-40 to +150
+150
°C
°C
Operating Junction Temperature (T )
J
ESD Human Body Model
Moisture Sensitivity Level
1000
V
MSL 1
*No RF Drive
**With specified application circuit
***Modulation schemes include 802.11a/g, 802.16
Operation of this device beyond any one of these limits may cause permanent dam-
age. For reliable continuous operation, the device voltage and current must not
exceed the maximum operating values specified in the table on page one.
Bias Conditions should also satisfy the following expression:
I V <(T -T )/R , j-l
D
D
J
L
TH
Typical 5V Performance with Appropriate Application Circuit (VCC=5V, ICQ=602mA, 802.11a 54Mb/s)
Parameter
Units 5.15GHz 5.35GHz 5.7GHz 5.9GHz
Gain @ P =26dBm
dB
8.8
9.0
9.4
8.8
OUT
P1dB
@ 2.5% EVM
dBm
dBm
32.7
25.3
32.2
25.1
33.2
25.3
32.5
25.0
P
OUT
Current @ P
2.5% EVM
mA
632
631
670
670
OUT
Input Return Loss
Output Return Loss
dB
dB
10
15
13
13
19
15
19
13
Simplified Device Schematic
GND
VBIAS
RFIN
VPC
1
2
3
6
5
NC
RFOUT/VCC
VDET
4
GND
7628 Thorndike Road, Greensboro, NC 27409-9421 · For sales or technical
support, contact RFMD at (+1) 336-678-5570 or sales-support@rfmd.com.
2 of 14
