SZA-5044

型号:

SZA-5044

描述:

4.9 - 5.9 GHz的5V电源功放[ 4.9 - 5.9 GHz 5V Power Amplifier ]

品牌:

SIRENZA[ SIRENZA MICRODEVICES ]

页数:

7 页

PDF大小:

210 K

SZA-5044
SZA-5044Z
RoHS Compliant
& GreenPackage
Product Description
Pb
Sirenza Microdevices’ SZA-5044 is a high efficiency class AB
Heterojunction Bipolar Transistor (HBT) amplifier housed in a
low-cost surface-mountable plastic package. This HBT ampli-
fier is made with InGaP on GaAs device technology and fabri-
cated with MOCVD for an ideal combination of low cost and
high reliability. This product is specifically designed as a final
or driver stage for 802.11a equipment in the 4.9 - 5.9 GHz
band for a 5V supply. Optimized on-chip impedance matching
circuitry provides a 50W nominal RF input impedance. A sin-
gle external output matching circuit covers the entire 4.9-
5.9GHz band simultaneously. The external output match
allows for load line optimization for other applications or opti-
mized performance over narrower bands. This product is
available in a RoHS Compliant and Green package with matte
tin finish, designated by the “Z” package suffix.
4.9 – 5.9 GHz 5V Power Amplifier
4mm x 4mm QFN Package
Product Features
802.11a 54Mb/s Class AB Performance
Pout = 22dBm @ 3% EVM, 5V, 343mA
High Gain = 33dB
Output Return Loss < -11dB for Linear Tune
On-chip Output Power Detector
P1dB = 30dBm @ 5V
Simultaneous 4.9- 5.9GHz Performance
Robust - Survives RF Input Power = +15dBm
Power up/down control < 1ms, Vpc 2.9V to 5V
Functional Block Diagram
Vcc
Power
Up/Down
Control
Active
Bias
Active
Bias
Active
Bias
RFIN
RFOUT
Applications
802.11a WLAN, OFDM
5.8GHz ISM Band, 802.16 WiMAX
Power Detector
Vout
Key Specifications
Parameters: Test Conditions, App circuit page 4
Z0 = 50W, VCC = 5.0V, Icq = 270mA, TBP = 25ºC
Symbol
Unit
Min.
Typ.
Max.
fO
Frequency of Operation
MHz
4900
5900
Output Power at 1dB Compression – 5.15 GHz
Output Power at 1dB Compression – 5.875 GHz
Gain at 4.9 GHz
30.2
29
P1dB
dBm
27.5
30.7
dB
dB
dB
32.7
33.0
27.7
21
34.7
29.7
S21
Gain at 5.15 GHz
Gain at 5.875 GHz
25.7
Output power at 3% EVM 802.11a 54Mb/s - 5.15GHz
Output Power at 3% EVM 802.11a 54Mb/s - 5.875GHz
Noise Figure at 5.875 GHz
Pout
dBm
22
NF
IM3
dB
6.3
Third Order Intermod at 18dBm per tone - 5.875GHz
Worst Case Input Return Loss 4.9-5.875GHz
Worst Case Output Return Loss 4.9-5.875GHz
Output Voltage Range for Pout=10dBm to 26dBm
Vcc Quiescent Current
dBc
-39
-35
IRL
8.6
9.3
11.6
12.3
0.8 to 1.9
270
1.7
dB
ORL
Vdet Range
Icq
V
mA
mA
uA
230
310
100
IVPC
Power Up Control Current, Vpc=5V ( IVPC1 + IVPC2 + IVPC3
Off Vcc Leakage Current Vpc=0V
)
ILEAK
Rth, j-l
8
Thermal Resistance (junction - lead)
ºC/W
24
The information provided herein is believed to be reliable at press time. Sirenza Microdevices assumes no responsibility for ina ccuracies or ommisions.
Sirenza Microdevices assumes no responsibility for the use of this information, and all such information shall be entirely at the user’s own risk. Prices and specifications are subject to change without notice. No patent
rights or licenses to any of the circuits described herein are implied or granted to any third party. Sirenza Microdevices does not authorize or warrant any Sirenza Microdevices product for use in life-support devices
and/or systems.
Copyright 2002 Sirenza Microdevices, Inc. All worldwide rights reserved.
303 South Technology Court Broomfield, CO 80021
Phone: (800) SMI-MMIC
1
http://www.sirenza.com
EDS-103585 Rev H
SZA-5044 4.9-5.9 GHz Power Amp
Pin Out Description
Pin #
Function
Description
1,3,5,9,
11,15,17
N/C
Pins are not used. May be grounded, left open, or connected to adjacent pin.
VPC1 is the bias control pin for the stage 1 active bias circuit and can be run from 2.9V to 5V control. An
external series resistor is required for proper setting of bias levels depending on control voltage. Refer to
the evaluation board schematic for resistor value. To prevent potential damage, do not apply voltage to this
pin that is +1V greater than voltage applied to pin 20 (Vbias) unless Vpc supply current capability is less
than 10 mA.
6
7
8
VPC1
VPC2
VPC3
VPC2 is the bias control pin for the stage 2 active bias circuit and can be run from 2.9V to 5V control. An
external series resistor is required for proper setting of bias levels depending on control voltage. Refer to
the evaluation board schematic for resistor value. To prevent potential damage, do not apply voltage to this
pin that is +1V greater than voltage applied to pin 20 (Vbias) unless Vpc supply current capability is less
than 10 mA.
VPC3 is the bias control pin for the stage 3 active bias circuit and can be run from 2.9V to 5V control. An
external series resistor is required for proper setting of bias levels depending on control voltage. Refer to
the evaluation board schematic for resistor value. To prevent potential damage, do not apply voltage to this
pin that is +1V greater than voltage applied to pin 20 (Vbias) unless Vpc supply current capability is less
than 10 mA.
10
Vdet
Ouput power detector voltage. Load with 10K-100K ohms to ground for best performance.
RF input pins. This is DC grounded internal to the IC. Do not apply voltage to this pin. All three pins must be
used for proper operation.
2,4
RFIN
12,13,14
RFOUT RF output pin. This is also another connection to the 3rd stage collector
16
18
19
20
VC3
VC2
3rd stage collector bias pin. Apply 5V to this pin.
2nd stage collector bias pin. Apply 5V to this pin.
1st stage collector bias pin. Apply 5V to this pin.
Active bias network VCC. Apply 5V to this pin.
VC1
Vbias
Exposed area on the bottom side of the package needs to be soldered to the ground plane of the board for
optimum thermal and RF performance. Several vias should be located under the EPAD as shown in the rec-
ommended land pattern (page 5).
EPAD
Gnd
Simplified Device Schematic
Absolute Maximum Ratings
Parameters
Value
500
Unit
mA
mA
mA
V
Pin
6
Pin
20
Pin
19
Pin
7
Pin
18
Pin
8
Pin
16
VC3 Collector Bias Current (pin16)
VC2 Collector Bias Current (pin18)
VC1 Collector Bias Current (pin19)
Device Voltage (VD)
225
75
7.0
Stage 1
Bias
Stage 2
Bias
Stage 3
Bias
Power Dissipation
3.4
W
Operating Lead Temperature (TL)
RF Input Power for 50 ohm RF out load
-40 to +85
15
ºC
dBm
Pin 12,13,14
RF Input Power for 10:1 VSWR RF out
load
2
dBm
Pin 2, 4
Storage Temperature Range
Operating Junction Temperature (TJ)
ESD Human Body Model
-40 to +150
+150
ºC
ºC
V
EPAD
Pin
10
EPAD
EPAD
>1000
Operation of this device beyond any one of these limits may
cause permanent damage. For reliable continuous operation
the device voltage and current must not exceed the maximum
operating values specified in the table on page one.
Caution: ESD Sensitive
Appropriate precaution in handling, packaging
and testing devices must be observed.
Bias conditions should also satisfy the following expression:
IDVD < (TJ - TL) / RTH’ j-l
303 South Technology Court Broomfield, CO 80021
Phone: (800) SMI-MMIC
http://www.sirenza.com
EDS-103585 Rev H
2
SZA-5044 4.9-5.9 GHz Power Amp
4.9 - 5.9 GHz Evaluation Board Data (VBIAS = 5.0V, Iq = 270mA)
Broadband S11 - Input Return Loss
Broadband S21 - Forward Gain
0
-5
40
35
30
25
20
15
10
-10
-15
-20
-25
-30
-35
0.0
1.0
2.0
3.0
Frequency(GHz)
-40C +25C
4.0
5.0
6.0
7.0
0.0
1.0
2.0
3.0
Frequency(GHz)
-40C +25C
4.0
5.0
6.0
7.0
+85C
+85C
Broadband S22 - Output Return Loss
Typical Gain vs Pout, T=+25C
0
-5
38
36
34
32
30
28
26
24
-10
-15
-20
-25
-30
-35
0.0
1.0
2.0
3.0
Frequency(GHz)
-40C +25C
4.0
5.0
6.0
7.0
16
18
4.9GHz
20
22
24
26
28
30
5.875GHz
32
Pout(dBm)
+85C
5.15GHz
5.35GHz
5.725GHz
DC Supply Current vs Pout, T=+25c
Icq (DC bias point) vs Vsupply (V+ and Vpc)
0.8
0.7
0.6
0.5
0.4
0.3
0.6
0.5
0.4
0.3
0.2
0.1
0
2.8 3.0 3.2 3.4 3.6 3.8 4.0 4.2 4.4 4.6 4.8 5.0 5.2 5.4 5.6
Vsupply(V)
16
18
4.9GHz
20
22
24
26
28
30
5.875GHz
32
Pout(dBm)
5.15GHz
5.35GHz
5.725GHz
-40c
+25c
+85c
303 South Technology Court Broomfield, CO 80021
Phone: (800) SMI-MMIC
3
http://www.sirenza.com
EDS-103585 Rev H
SZA-5044 4.9-5.9 GHz Power Amp
4.9 - 5.9 GHz Evaluation Board Data (VBIAS = 5.0V, Iq = 270mA)
802.11a EVM, OFDM, 54Mb/s, 64QAM
EVM vs Pout T=+25c
802.11g, OFDM 54Mb/S, 64QAM
EVM vs Pout F=4.9GHz
802.11g, OFDM 54Mb/S, 64QAM
6
6
5
4
3
2
1
0
5
4
3
2
1
0
12
14
16
18
20
22
24
8
8
8
10
10
10
12
14
16
18
20
22
22
22
24
24
24
Pout(dBm)
5.35GHz
Pout(dBm)
4.9GHz
5.15GHz
5.725GHz
5.875GHz
-40c
+25c
+85c
EVM vs Pout F=5.15GHz
802.11g, OFDM 54Mb/S, 64QAM
EVM vs Pout F=5.35GHz
802.11g, OFDM 54Mb/S, 64QAM
6
5
4
3
2
1
0
6
5
4
3
2
1
0
8
10
12
14
16
18
20
22
24
12
14
16
18
20
Pout(dBm)
Pout(dBm)
-40c
+25c
+85c
-40c
+25c
+85c
EVM vs Pout F=5.875GHz
802.11g, OFDM 54Mb/S, 64QAM
EVM vs Pout F=5.725GHz
802.11g, OFDM 54Mb/S, 64QAM
6
5
4
3
2
1
0
6
5
4
3
2
1
0
12
14
16
18
20
8
10
12
14
16
18
20
22
24
Pout(dBm)
Pout(dBm)
-40c
+25c
+85c
-40c
+25c
+85c
303 South Technology Court Broomfield, CO 80021
Phone: (800) SMI-MMIC
4
http://www.sirenza.com
EDS-103585 Rev H
SZA-5044 4.9-5.9 GHz Power Amp
4.9 - 5.9 GHz Evaluation Board Data (VBIAS = 5.0V, Iq = 270mA)
IM3 vs Pout (2 Tone Avg.),T=+25c
Tone Spacing = 1MHz
RF Power Detector (Vdet) vs Pout, F=4.9GHz
2.2
2
-30
-35
-40
-45
-50
-55
-60
-65
1.8
1.6
1.4
1.2
1
0.8
8
10
4.9GHz
12
14
16
18
20
22
24
16
18
20
22
24
26
28
30
32
32
32
Pout(dBm)
Pout(dBm)
-40c
+25c
+85c
5.15GHz
5.35GHz
5.725GHz
5.875GHz
RF Power Detector (Vdet) vs Pout, F=5.15GHz
RF Power Detector (Vdet) vs Pout, F=5.35GHz
2.2
2
2.2
2
1.8
1.6
1.4
1.2
1
1.8
1.6
1.4
1.2
1
0.8
0.8
16
18
20
22
24
26
28
30
32
16
18
20
22
24
26
28
30
Pout(dBm)
Pout(dBm)
-40c
+25c
+85c
-40c
+25c
+85c
RF Power Detector (Vdet) vs Pout, F=5.725GHz
RF Power Detector (Vdet) vs Pout, F=5.875GHz
2.6
2.4
2.2
2
2.6
2.4
2.2
2
1.8
1.6
1.4
1.2
1
1.8
1.6
1.4
1.2
1
0.8
0.8
16
18
20
22
24
26
28
30
32
16
18
20
22
24
26
28
30
Pout(dBm)
Pout(dBm)
-40c
+25c
+85c
-40c
+25c
+85c
303 South Technology Court Broomfield, CO 80021
Phone: (800) SMI-MMIC
5
http://www.sirenza.com
EDS-103585 Rev H
SZA-5044 4.9-5.9 GHz Power Amp
4.9 - 5.9 GHz Evaluation Board Schematic For V+ = Vcc = 5.0V
Notes:
Pins 1,3,5,9,11,15 and 17 are
unwired (N/C) inside the pack-
age. Refer to page 2 for detailed
pin descriptions. Some of these
pins are wired to adjacent pins or
grounded as shown in the appli-
cation circuit. This is to maintain
consistency with the evaluation
board layout shown below. It is
recommended to use this layout
and wiring to achieve the speci-
fied performance.
To prevent potential damage, do
not apply voltage to the Vpc pin
that is +1V greater than voltage
applied to pin 20 (Vbias/Vcc)
unless Vpc supply current
capability is less than 10 mA.
4.9 - 5.9 GHz Evaluation Board Layout For V+ = Vcc = 5.0V
- Board material GETEK, 10mil thick, Dk=3.9, 2 oz. copper finish
C1
C3
C2
C4
Q1
C5
SZA5044
C7
303 South Technology Court Broomfield, CO 80021
Phone: (800) SMI-MMIC
6
http://www.sirenza.com
EDS-103585 Rev H
SZA-5044 4.9-5.9 GHz Power Amp
Part Symbolization
Part Number Ordering Information
The part will be symbolized with an “SZA-5044” for
Sn/Pb plating or “SZA-5044Z” for RoHS green compli-
ant product. Marking designator will be on the top sur-
face of the package.
Part Number
Reel Size
Devices/Reel
SZA-5044
13”
3000
SZA-5044Z
13”
3000
Package Outline Drawing (dimensions in mm): Refer to package outlline drawing for more detail.
Recommended Land Pattern (dimensions in mm[in])
Recommended PCB Soldermask (SMBOC) for
Land Pattern (dimensions in mm[in]):
303 South Technology Court Broomfield, CO 80021
Phone: (800) SMI-MMIC
http://www.sirenza.com
EDS-103585 Rev H
7
厂商 型号 描述 页数 下载

SIRENZA

SZA-2044 2.0-2.7 GHz的5V 1W功率放大器[ 2.0-2.7 GHz 5V 1W Power Amplifier ] 8 页

SIRENZA

SZA-2044Z 2.0-2.7 GHz的5V 1W功率放大器[ 2.0-2.7 GHz 5V 1W Power Amplifier ] 8 页

SIRENZA

SZA-3044 2.7-3.8GHz 5V 1W功率放大器[ 2.7-3.8GHz 5V 1W Power Amplifier ] 8 页

SIRENZA

SZA-3044Z 2.7-3.8GHz 5V 1W功率放大器[ 2.7-3.8GHz 5V 1W Power Amplifier ] 8 页

SIRENZA

SZA-5044Z 4.9 - 5.9 GHz的5V电源功放[ 4.9 - 5.9 GHz 5V Power Amplifier ] 7 页

SIRENZA

SZA-6044 5.1 5.9 GHz的1/4瓦功率放大器的有源偏置[ 5.1- 5.9 GHz 1/4 Watt Power Amplifier with Active Bias ] 6 页

SEOUL

SZA05A0A ž电源指示灯 - 超高光通量输出,高亮度[ Z Power LED - Super high Flux output and high Luminance ] 21 页

ARCH

SZA100-12S [ Open Frame Switching Power Supply ] 5 页

ARCH

SZA100-15S [ Open Frame Switching Power Supply ] 5 页

ARCH

SZA100-24S [ Open Frame Switching Power Supply ] 5 页

PDF索引:

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引:

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

0.201912s
