VER :A_2
update : 2016.09.01
AC-DC Switching Power Supply
SZA100 SERIES
100 Watts
KEY FEATURES
Open Frame Switching Power Supply
Universal Input: 85-265 VAC
Single Output
<0.3W No Load Input Power (48Vout <0.5W)
5 VDC to 48 VDC Output
Ultra Compact Size: 4.05 x 2.04 x 1.36 Inches
3-Year Product Warranty
ELECTRICAL SPECIFICATIONS
All specifications valid at normal input voltage, full load and +25°C after warm-up time unless otherwise stated.
Model No.
SZA100-5S
SZA100-12S
SZA100-15S
SZA100-24S
SZA100-48S
Max Output Wattage (Free air Convection) (W)
80 W
100 W
Max Output Wattage (with 20CFM FAN)
(W)
Voltage
85-265 VAC or 120-370 VDC
47-63 Hz
Frequency (Hz)
Input
Current (Full load)
Inrush Current (<2ms)
Leakage Current
Voltage (V.DC.)
3 A max. (115 VAC) / 2 A max. (230 VAC)
40 A max. (115 VAC) / 80 A max. (230 VAC)
0.75 mA max.
5V
12V
15V
24V
48V
Voltage Accuracy
±2%
Current (Free air Convection) (mA) max
Current (with 20CFM FAN) (mA) max
Line Regulation (LL-HL) (typ.)
Load Regulation (5-100%) (typ.)
Maximum Capacitive Load (at 230VAC)
Ripple
12,000
18,000
±1%
6,665
8,330
5,336
6,670
3,336
4,170
1,667
2,084
±1%
Output
35,000µF
150mV
24,640µF
100mV
150mV
86%
13,860µF
100mV
150mV
86%
5,600µF
110mV
200mV
88%
1,638µF
150mV
280mV
88%
Noise
150mV
Efficiency (at 230V)
Trim
80%
±10%
Hold-up Time
10 ms min.
Auto recovery
Zener diode clamp
Auto recovery
Over Power Protection
Over Voltage Protection
Short Circuit Protection
Input-Output (V.AC)
Protection
Isolation
3000VAC or 4242VDC
1500V
Input-FG
(V.AC)
Output-FG .(V.AC)
Operating Temperature
Storage Temperature
Temperature coefficient
Humidity
500V
-25°C…+70°C (with derating)
-40°C…+85°C
±0.02%/°C
Environment
95% RH
MTBF
>130,000 h @ 25°C (MIL-HDBK-217F)
10~500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes.
Vibration
Dimension (L x W x H)
Weight
4.05 x 2.04 x 1.36 Inches ( 102.75 x 51.7 x 34.5 mm ) Tolerance 0.5 mm
Physical
EMC
220 g
Cooling Method
Free air convection
EMI
EN 55022 Class B (Pending)
EN 55024 (Pending)
(Conducted & Radiated Emission)
EMS (Noise Immunity)
http://www.archcorp.com.tw
TEL: +886-2-26989508 FAX: +886-2-26981319
-1-
