IXTU01N100D

型号:

IXTU01N100D

描述:

N沟道,耗尽型高电压MOSFET[ N-Channel, Depletion Mode High Voltage MOSFET ]

品牌:

IXYS[ IXYS CORPORATION ]

页数:

2 页

PDF大小:

93 K

IXTP 01N100D
IXTU 01N100D
IXTY 01N100D
VDSS = 1000 V
ID25 = 100 mA
RDS(on) = 110 Ω
High Voltage MOSFET
N-Channel,DepletionMode
PreliminaryDataSheet
Symbol
TestConditions
Maximum Ratings
TO-220 (IXTP)
VDSX
VDGX
TJ = 25°C to 150°C
TJ = 25°C to 150°C
1000
1000
V
V
VGS
Continuous
Transient
± 20
± 30
V
V
AB)
G
VGSM
D
S
IDSS
IDM
TC = 25°C; TJ = 25°C to 150°C
100
400
mA
mA
TC = 25°C, pulse width limited by TJ
TO-251 (IXTU)
PD
TC = 25°C
TA = 25°C
25
1.1
W
W
TJ
-55 ... +150
150
°C
°C
°C
TJM
Tstg
G
D
-55 ... +150
D (TAB)
S
TL
1.6 mm (0.063 in.) from case for 10 s
Plastic case for 10 s (IXTU)
300
300
°C
°C
TISOL
Md
TO-252 (IXTY)
Mounting torque
TO-220
1.3 / 10 Nm/lb.
Weight
TO-220
TO-251
TO-252
4
0.8
0.8
g
g
g
G
S
D (TAB)
Pins: 1 - Gate
2 - Drain
3 - Source TAB - Drain
Symbol
TestConditions
Characteristic Values
min. typ. max.
Features
(TJ = 25°C, unless otherwise specified)
z Normally ON mode
VDSX
VGS(off)
VGS = -10 V, ID = 25 μA
VDS = 25V, ID = 25 μA
1000
-2.5
V
V
z Low RDS (on) HDMOSTM process
z Ruggedpolysilicongatecellstructure
z Fastswitchingspeed
-5
IGSS
VGS = ± 20 VDC, VDS = 0
±100 nA
IDSX(off)
VDS = VDSX,VGS = -10 V
10 μA
Applications
TJ = 125°C
Note 1
250 μA
z
Level shifting
z
RDS(on)
ID(on)
VGS = 0 V, ID = 50 mA
VGS = 0 V, VDS = 25V
90
110
Ω
Triggers
z
Solid state relays
Note 1
100
mA
z
Currentregulators
© 2006 IXYS All rights reserved
98809B (01/06)
IXTP 01N100D
TO-220 AD Outline
Symbol
gfs
TestConditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
VDS = 50 V; ID = 100 mA
Note1
100
150
mS
Ciss
Coss
Crss
120
25
5
pF
pF
pF
VGS = -10 V, VDS = 25 V, f = 1 MHz
td(on)
tr
td(off)
tf
VDS = 100 V V, ID = 50 mA
VGS = 0 V to -10
8
6
ns
ns
ns
ns
RG = 30Ω (External)
30
51
Pins: 1 - Gate
3 - Source
2 - Drain
TAB - Drain
RthJC
RthCS
5
K/W
K/W
TO-220
0.25
Source-DrainDiode
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
Symbol
TestConditions
VSD
trr
VGS = -10 V, IF = 100 mA
Note1
1.0
1.5
V
IF = 0.75 A, -di/dt = 10 A/μs,
VDS = 25 V, VGS = -10V
1.5 μs
TO-251 AA Outline
Note1: Pulse test, t 300 μs, duty cycle d 2 %
TO-252 AA Outline
Dim. Millimeter
Inches
Min. Max. Min.
Max.
A
A1
2.19 2.38 0.086 0.094
0.89 1.14 0.035 0.045
A2
b
0
0.13
0
0.005
0.64 0.89 0.025 0.035
b1
b2
0.76 1.14 0.030 0.045
5.21 5.46 0.205 0.215
Pins: 1 - Gate
3 - Source
2 - Drain
TAB - Drain
c
c1
0.46 0.58 0.018 0.023
0.46 0.58 0.018 0.023
Dim.
Millimeter
Inches
Min. Max.
Min.
Max.
D
D1
5.97 6.22 0.235 0.245
4.32 5.21 0.170 0.205
A
A1
2.19
0.89
2.38
1.14
.086
0.35
.094
.045
b
b1
b2
0.64
0.76
5.21
0.89
1.14
5.46
.025
.030
.205
.035
.045
.215
E
E1
6.35 6.73 0.250 0.265
4.32 5.21 0.170 0.205
e
e1
2.28 BSC
4.57 BSC
0.090BSC
0.180BSC
c
c1
0.46
0.46
0.58
0.58
.018
.018
.023
.023
H
L
9.40 10.42 0.370 0.410
0.51 1.02 0.020 0.040
D
5.97
6.22
.235
.245
E
e
e1
6.35
2.28
4.57
6.73
BSC
BSC
.250
.090
.180
.265
BSC
BSC
Pins: 1 - Gate
3 - Source
2 - Drain
TAB - Drain
L1
L2
L3
0.64 1.02 0.025 0.040
0.89 1.27 0.035 0.050
2.54 2.92 0.100 0.115
H
17.02
17.78
.670
.700
L
8.89
1.91
0.89
1.15
9.65
2.28
1.27
1.52
.350
.075
.035
.045
.380
.090
.050
.060
L1
L2
L3
IXYS reserves the right to change limits, test conditions, and dimensions.
IXYSMOSFETs andIGBTsarecovered by
oneormoreofthefollowingU.S.patents:
4,835,592
4,850,072
4,881,106
4,931,844
5,017,508
5,034,796
5,049,961
5,063,307
5,187,117
5,237,481
5,381,025
5,486,715
6,162,665
6,259,123B1
6,306,728 B1
6,404,065B1
6,534,343
6,583,505
6,683,344
6,710,405B2
6,710,463
6,727,585
6,759,692
