IXTA02N250HV
Symbol
Test Conditions
Characteristic Values
TO-263AB (VHV) Outline
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 100V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
88
145
mS
Ciss
Coss
Crss
116
8
pF
pF
pF
3
td(on)
tr
td(off)
tf
19
19
32
33
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 100Ω (External)
PIN: 1 - Gate
2 - Source
3 - Drain
Qg(on)
Qgs
7.4
0.7
5.3
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
RthJC
1.5 °C/W
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
200 mA
800 mA
ISM
VSD
trr
Repetitive, Pulse Width Limited by TJM
IF = 100mA, VGS = 0V, Note 1
2.0
V
IF = 200mA, -di/dt = 50A/μs, VR = 100V
1.5
μs
Note
1. Pulse test, t ≤ 300μs, duty cycle, d ≤ 2%.
*Additional provisions for lead to lead voltage isolation are required at VDS > 1200V.
ADVANCE TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from a subjective evaluation of the design, based upon prior knowledge and experience, and constitute a
"considered reflection" of the anticipated result. IXYS reserves the right to change limits, test
conditions, and dimensions without notice.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
