IXTV270N055T2
IXTV270N055T2S
Symbol
Test Conditions
Characteristic Values
Min. Typ. Max.
TO-263 Outline
(TJ = 25°C, Unless Otherwise Specified)
gfs
VDS = 10V, ID = 60A, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
48
80
S
Ciss
Coss
Crss
9700
1470
250
pF
pF
pF
td(on)
tr
td(off)
tf
19
20
40
37
ns
ns
ns
ns
Resistive Switching Times
V
GS = 10V, VDS = 0.5 • VDSS, ID = 100A
RG = 2Ω (External)
Qg(on)
Qgs
167
35
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
43
RthJC
RthCH
0.24 °C/W
°C/W
0.21
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min. Typ.
Max.
270
1080
1.3
IS
VGS = 0V
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = 100A, VGS = 0V, Note 1
TO-220 Outline
trr
63
3.8
ns
A
IF = 0.5 • ID25, VGS = 0V
IRM
QRM
-di/dt = 100A/μs
VR = 27V
120
nC
Note: 1. Pulse test, t ≤ 300μs, duty cycle, d ≤ 2%.
Pins: 1 - Gate
3 - Source
2 - Drain
ADVANCE TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from a subjective evaluation of the design, based upon prior knowledge and experience, and constitute a
"considered reflection" of the anticipated result. IXYS reserves the right to change limits, test
conditions, and dimensions without notice.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
