1T409
Variable Capacitance Diode
Description
M-290
The 1T409 is a variable capacitance diode
designed for UHF-band VCO using a super-small-
miniature flat package (SSVC).
Features
• Super-small-miniature flat package
• Low series resistance: 0.4 Ω Max. (f=470 MHz)
• Large capacitance ratio: 2.5 Typ.
(C2/C10)
• Small leakage current: 3 nA Max. (VR=15 V)
Absolute Maximum Ratings (Ta=25 °C)
• Reverse voltage
• Operating temperature Topr
• Storage temperature
VR
15
V
Applications
–35 to +85
°C
• UHF-band VCO
Tstg –65 to +150 °C
• Local oscillator for cordless telephone
• Local oscillator for cellular equipment
Structure
Silicon epitaxial planar type diode
Electrical Characteristics
(Ta=25 °C)
Item
Symbol
Conditions
VR=15 V
Min.
Typ.
Max.
Unit
Reverse current
Diode capacitance
IR
C2
3
nA
pF
pF
VR=2 V, f=1 MHz
VR=10 V, f=1 MHz
14.26
5.46
2.2
15.96
6.46
C10
C2/C10
rs
Capacitance ratio
Series resistance
2.5
0.3
VR=5V, f=470 MHz
0.4
Ω
