DC Power Supplies — Tektronix PWS2000 Series
Display
Warranty
Vacuum fluorescent display.
Three years.
Memory
Ordering Information
20 setup memories.
Power Source
Models
Characteristic
110 V AC Setting
220 V AC Setting
Frequency
Description
Model
Description
99 VRMS to 132 VRMS
198 VRMS to 264 VRMS
47 Hz to 63 Hz
PWS2185
PWS2323
PWS2326
PWS2721
DC Power Supply, 18 V, 5 A
DC Power Supply, 32 V, 3 A
DC Power Supply, 32 V, 6 A
DC Power Supply, 72 V, 1.5 A
Power Consumption
PWS2185/2323/2721 350 VA
PWS2326
700 VA
PWS2000 Includes: Power supply, line cord, user manual, Traceable Certificate of
Calibration, and documentation CD (includes user manuals and technical reference).
Note: Please specify power plug and preferred language option when ordering.
Physical Characteristics
Dimension
mm
in.
With Boots and Handle
Optional Accessories
Height
Width
Depth
105
242
384
4.15
9.52
Accessory
RMU2U*1
Description
Rackmount Shelf Kit for 1 or 2 Units
Rackmount Cosmetic Filler Panel
15.12
386-7598-00
Without Boots and Handle
*1 PWS2000 Series power supplies require 3U of height in a rack. The instrument's height, without boots, is
3 mm greater than 2U and 42 mm less than 3U. Filler panel 386-7598-00 may be used to fill the 42 mm gap
above power supplies.
Height
Width
Depth
91
3.57
8.55
217
362
14.24
Power Plug Options
Weight
kg
5.6
6.7
lb.
Option
A0
Description
North America
Universal Euro
United Kingdom
Australia
PWS2185
12.3
14.8
PWS2323/2326/2721
A1
Environmental and Safety
A2
Characteristic
Temperature
Operating
Description
A3
A5
Switzerland
China
0 °C to 40 °C
–20 °C to 70 °C
20 minutes to full uncertainty specifications
A10
A11
A12
Storage
India
Warm up
Brazil
Relative Humidity (Noncondensing)
Operating and
storage
5% to 95% relative humidity (% RH) at up to 40 °C,
noncondensing
Language Options
Option
L0
Description
English
Storage
5% to 95% RH at up to 40 °C, noncondensing
5% to 60% RH above 40 °C to 70 °C, noncondensing
Altitude
L1
French
Operating
Storage
2,000 meters
4,000 meters
L2
Italian
L3
German
Floating Voltage Rating Up to 100 V (DC + peak AC) between earth ground and
any output terminal
L4
Spanish
L6
Portuguese
Simplified Chinese
Traditional Chinese
Korean
Electromagnetic
Compatibility
European Union: EN 55011, Class A; IEC 61000-3-2;
IEC 61000-3-3, IEC 61000-4-2, IEC 61000-4-3,
IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC
61000-4-8, IEC 61000-4-11
L7
L8
L9
USA: FCC, CFR Title 47, Part 15, Subpart B, Class A
Australia: EMC Framework, demonstrated per Emission
Standard AS/NZS 2064 (Industrial, Scientific, and
Medical Equipment)
L10
Russian
Safety
European Union: Low Voltage directive 2006/95/EC;
EN61010-1 2001
USA: Nationally recognized testing laboratory listing
UL61010-1-2004
Canada: CAN/CSA C22.2 No. 61010-1 2004
www.tektronix.com
3
