SUMMARY
CYTMA568
Document History Page
Document Title: CYTMA568, TrueTouch® Multi-Touch All-Points Touchscreen Controller
Document Number: 001-90891
Orig. of
Change
Submission
Date
Rev.
ECN
Description of Change
**
4379995
5284373
SWU
ELG
05/14/2014 New datasheet
*A
05/26/2016 Removed Windows Phone Support.
Revised grammar for charger noise.
Aligned charger noise support in order information table with features list.
Updated template.
