Niu Hang
Electronic Co. Ltd
Production
Data Sheet
RYBS3006 THRU RYBS3010
FAST RECOVERY BRIDGE RECTIFIERS
600~1000
Ampers
4.0
Marking
VOLTAGE
Volts CURRENT
FEATURES
Glass passivated junction.
·
·
·
·
·
Ideal for printed circuit board.
Reliable low cost construction utilizing molded plastic technique.
High surge current capability.
High temperature soldering guaranteed:
260℃/10 seconds at terminals.
MECHANICAL DATA
Case: Molded plastic, TMBF
·
·
·
·
·
Epoxy: UL 94V-O rate flame retardant
Terminals: Leads solderable per MIL-STD-202,method 208 guaranteed
Mounting position: Any
RYBS30XX
Weight: 0.204g (approximately)
Maximum Ratings and electrical characteristics(TA=25°C Unless otherwise noted)
Rating at 25℃ ambient temperature unless otherwise specified.Resistive or Inductive load,60HZ.For Capacitive load derate by20%.
Type Number
Symbol
RYBS3006
RYBS3008
RYBS3010
Units
V RRM
V RMS
V DC
600
420
600
800
560
800
1000
700
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
V
V
V
1000
Maximum DC Blocking Voltage
Maximum Average Rectified Output Current
4.0
I(AV)
A
A
@Tc=70℃(see fig.1)
Peak forward surge current (Non-repetitive)@8.3ms
single half sine-wave superimposed on rated
load,1cycle
100
IFSM
I 2 t
V F
A2sec
V
41.50
1.3
5
Current Squared Time Per diode(1ms≤t<8.3ms)
Maximum Instantaneous Forward Voltage
@4.0A (Note 1)
@ TA=25℃
Maximum DC Reverse Current
uA
ns
IR
at Rated DC Blocking Voltage
@ TA=125℃
500
(Note 2)
250
500
T RR
T J
Maximum Reverse Recovery Time (Note 3)
Operating Temperature Range
-55 to +150
-55 to +150
℃
T STG
Storage Temperature Range
Note:
1.Pulse test: 300 μs pulse width,1% duty cycle
2.Pulse test: pulse width≤40ms
3.Test Conditions: IF = 0.5A, IR = -1.0A, IRR = -0.25A
Http://www.nhel.com.cn
Data: 2014/10/20
Rev.: A/1
Page:
1 of 5
Niu Hang
Electronic Co. Ltd
Production
Data Sheet
RYBS3006 THRU RYBS3010
FAST RECOVERY BRIDGE RECTIFIERS
RATINGANDCHARACTERISTICCURVES
10
1
5
4
3
2
1
0
0.1
0.01
Single phase half wave 60HZ
Resistive or inductive Load
0
50
100
150
0.4
0.6
0.8
1
1.2
1.4
TL,LEAD TEMPERATURE(°C）
Fig.1-FORWARD CURRENT DERATING CURVE
Tc, Case Temp (℃)
Fig.2- TYPEICAL FORWARD CHARACTERISTICS
100
100
80
60
40
20
0
10
1
0.1
0.01
0
20
40
60
80
100
1
10
100
25℃
125℃
PERCENT OF RATED PEAK REVERSE VOLTAGE%
Fig.3-TYPICAL REVERSE CHARACTERISTICS
REVERSE VOLTAGE,(V)
Fig.4- MAX. NON-REPETITIVE SURGE CURRENT
Fig.5- TEST CIRCUIT DIAGRAM AND REVERSE RECOVERY TIME CHARACTERISTIC
Http://www.nhel.com.cn
Data: 2014/10/20
Rev.: A/1
Page
2
of 5
Niu Hang
Electronic Co. Ltd
Production
Data Sheet
RYBS3006 THRU RYBS3010
FAST RECOVERY BRIDGE RECTIFIERS
OUTLINE DRAWINGS
OUTLINE DIMENSIONS
MILLIME TERS
INCHES
DIM
MIN.
TYP.
MAX.
7.600
6.900
1.500
8.900
5.200
1.400
1.150
0.250
0.900
0.200
MIN.
0.189
0.252
0.051
0.331
0.189
0.032
0.035
0.006
0.020
0.002
MAX.
0.205
0.272
0.059
0.350
0.205
0.055
0.045
0.098
0.035
0.008
TYP.
-
A
B
C
D
E
F
7.100
6.400
1.300
8.400
4.800
0.800
0.900
0.170
0.500
0.050
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
G
H
J
K
TMBF
MOUNTING PAD LAYOUT
OUTLINE DIMENSIONS
MILLIME TERS
TYP.
INCHES
DIM
MIN.
MAX.
MIN.
MAX.
TYP.
A
B
5.000
0.197
7.600
0.299
C
D
1.000
0.900
-
-
1.400
1.600
0.039
0.035
-
-
0.055
0.063
(Ratings at 25°C ambient temperature unless otherwise specified )
Thermal Charact
Parameter
Symbl
R θJA
R θJL
R θJC
TMBF
55
Unit
Typical thermal resistance (Note
4)
15
℃/W
5
No4.PCB Mounted with The Suggested PAD Size
Packing Information
Quantity
(pcs/box)
Box Size
L×W×H(mm)
Carton Size
L×W×H(mm)
Quantity
(box/carton)
Product code
Pack
RYBS3006 THRU
RYBS3010
T/R
6000
350×350×40
360×360×310
6
Http://www.nhel.com.cn
Data2014/10/20 Rev.A/1
Page:
3
of
5
Niu Hang
Electronic Co. Ltd
Production
Data Sheet
RYBS3006 THRU RYBS3010
FAST RECOVERY BRIDGE RECTIFIERS
Recommended wave soldering condition
Product
Peak Temperature
260 +0/-5 °C
Soldering Time
Pb-free devices
5 +1/-1 seconds
Recommended temperature profile for IR reflow
Profile feature
Average ramp-up rate
Sn-Pb eutectic Assembly
3°C/second max.
Pb-free Assembly
3°C/second max.
(Tsmax to Tp)
Preheat
−Temperature Min(TS min)
−Temperature Max(TS max)
−Time(ts min to ts max)
100°C
150°C
60-120 seconds
150°C
200°C
60-180 seconds
Time maintained above:
−Temperature (TL)
− Time (tL)
183°C
60-150 seconds
217°C
60-150 seconds
Peak Temperature(TP)
240 +0/-5 °C
260 +0/-5 °C
Time within 5°C of actual peak
temperature(tp)
10-30 seconds
20-40 seconds
Ramp down rate
6°C/second max.
6 minutes max.
6°C/second max.
8 minutes max.
Time 25 °C to peak temperature
Note : All temperatures refer to topside of the package, measured on the package body surface.
Http://www.nhel.com.cn
Data: 2014/10/20 Rev.: A/1
Page:
4
of
5
Niu Hang
Electronic Co. Ltd
Production
Data Sheet
RYBS3006 THRU RYBS3010
FAST RECOVERY BRIDGE RECTIFIERS
Disclaimer
Reproducing and modifying informatiom of the document is prohibited without permission
from niuhang Electronics co., LTD
●
●
●
●
●
Niuhang Electronics co., LTD. reserves the rights to make changes of the content herein
the document anytime without notification.
Niuhang Electronics co., LTD. disclaims any and all liability arising out of the application or
use of any product including damages incidentally and consequentially occurred.
Niuhang Electronics co., LTD. does not assume any and all implied warranties,
including warranties of fitness for particular purpose,non-infringement and merchantability.
Applications shown on the herein document are examples of standard use and operation.
Customers are responsible in comprehending the suitable use in particular applications.
Niuhang Electronics co., LTD.makes no representation or warranty that such applications will
be suitable for the specified use without further testing or modification.
The products shown herein are not designed and authorized for equipments requiring high
level of reliability or relating to human life and for any applications concerning life-saving or
life-sustaining,such as medical instruments.transportation equipment,aerospae machinery
et cetera.Customers usin or selling these products for use in such applications do so at their
own rish and agree to fully indemnify Niuhang Electronics co., LTD.for any damages resulting
resulting from such improper use or sale.
●
●
When the appearance of the product and chip size does not change, in order to product
the customer.
quality, change the internal structure and the production process Niuhang can not notify
Http://www.nhel.com.cn
Data:2014/10/20
Rev.: A/1
Page
5
of
5
