ALUMINUM ELECTROLYTIC CAPACITORS
3.95mmL MAX. Chip Type,
Wide Temperature Range
ZGseries
Chip type with 3.95mmLMAX height. Operating over wide
temperature range of –40
.
~ +105°C
ZT
Designed for surface mounting on high density PC board.
Applicable to automatic mounting machine using carrier tape.
Smaller
ZG
Specifications
Item
Performance Characteristics
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
–40 ~ +105°C
6.3 ~ 50V
0.1 ~ 100µF
± 20% at 120Hz, 20°C
After 2 minutes' application of rated voltage leakage current is not more than 0.01 CV or 3 (µA) , whichever is greater.
,
Rated voltage (V)
tan δ (MAX.)
6.3
0.38
6.3
6
10
0.32
10
16
0.20
16
3
25
0.16
25
3
35
0.14
35
3
50
0.14
50
3
120Hz
20°C
tan
δ
Rated voltage (V)
120Hz
Stability at Low
Temperature
Z–25°C / Z+20°C
Z–40°C / Z+20°C
5
Impedance ratio
ZT / Z20 (MAX.)
10
10
6
6
4
4
Capacitance change
tan δ
Within ±30% of initial value
300% or less of initial specified value
Initial specified value or less
After 1000 hours' application of rated voltage at 105°C,
capacitors meet the characteristic requirements listed at right.
Endurance
Shelf Life
Leakage current
After leaving capacitors under no load at 105°C for 1000 hours, they meet the specified value for endurance characteristics listed above.
Capacitance change
tan δ
Within ±10% of initial value
Initial specified value or less
Initial specified value or less
The capacitors shall be kept on the hot plate maintained at 250°C for 30
seconds. After removing from the hot plate and restored at room temperature,
they meet the characteristic requirements listed at right.
Resistance to
soldering heat
Leakage current
Marking
Black print on the case top.
Type numbering system (Example : 16V 10 F)
µ
Chip Type
Positive
1
2
3
4
5
6
7
8
9 10 11 12 13 14
Voltage
Lot No.
Plastic platform
0.3 MAX.
Series
C±0.2
U Z G 1 C 1 0 0 M C R 1 G B
(mm)
6.3
1.8 2.1 2.4
4.3 5.3 6.6
4.3 5.3 6.6
1.0 1.3 2.2
Taping code
φD
A
B
C
E
4
5
Configuration
Capacitance tolerance (±20%)
Rated Capacitance (10µF)
Rated voltage (16V)
Series name
+0.05
–0.2
Capacitance
3.90
Negative
0.5 ~ 0.8
Voltage
V
6.3
j
10
A
16
C
25
E
35
50
H
Type
Code
V
Dimensions
6.3
0J
10
16
25
35
50
V
Cap. (µF)
0.1
1A
1C
1E
1V
1H
Code
0R1
4
0.9
2.2
2.8
3.3
5.4
9.6
0.22
0.33
0.47
1
R22
R33
R47
010
2R2
3R3
4R7
100
220
330
470
101
4
4
4
4
2.2
4
3.3
4
12.
4.7
4
11
20
33
42
4
13
22
36
5
16.
26.
10
4
16
26
35
44
5
5
6.3
22
4
19
26
32
52
5
24
5
6.3
6.3
6.3
33
5
5
30
40
6.3
6.3
47
5
6.3
Rated
ripple
Case size
φD (mm)
100
6.3
Rated Ripple (mA rms) at 105°C 120Hz
Frequency coefficient of rated ripple current
Taping specifications are given in page 22.
Recommended land size are given in page 23
Please refer to page 3 for the minimum order quantity.
Frequency
50 Hz
120 Hz
300 Hz
1 kHz
10 kHz~
1.50
Coefficient
0.70
1.00
1.17
1.36
CAT.8100T
