IXTT40N50L2 IXTQ40N50L2
IXTH40N50L2
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 10V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
11
15
19
S
Ciss
Coss
Crss
10.4
655
155
nF
pF
pF
td(on)
tr
td(off)
tf
50
133
127
44
ns
ns
ns
ns
Resistive Switching Times
V
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 2 (External)
Qg(on)
Qgs
320
64
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
198
RthJC
RthCS
0.23 C/W
C/W
(TO-247&TO-3P)
0.25
Safe Operating Area Specification
Symbol
SOA
Test Conditions
Min.
Typ.
Max.
VDS = 400V, ID = 0.8A, TC = 75°C, tp = 3s
320
W
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
40
A
A
ISM
VSD
trr
Repetitive, Pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
IF = IS, -di/dt = 100A/μs, VR = 100V
160
1.5
V
500
ns
Note 1: Pulse test, t 300s, duty cycle, d 2%.
