IXTA2N80P IXTP2N80P
IXTU2N80P IXTY2N80P
Symbol
gfs
Test Conditions
Characteristic Values
TO-263 (IXTA) Outline
(TJ = 25°C, unless otherwise specified)
Min.
Typ.
Max.
VDS= 20 V; ID = 0.5 ID25, Note 1
VGS = 0 V, VDS = 25 V, f = 1 MHz
1.4
2.4
S
Ciss
Coss
Crss
440
36
pF
pF
pF
4.4
td(on)
tr
td(off)
tf
25
35
53
28
ns
ns
ns
ns
VGS = 10 V, VDS = 0.5 VDSS, ID = 0.5 ID25
RG = 30 Ω (External)
Qg(on)
Qgs
10.6
3.7
nC
nC
nC
VGS= 10 V, VDS = 0.5 VDSS, ID = 0.5 ID25
Qgd
4.5
RthJC
RthCS
1.80 °C/W
°C/W
(TO-220)
0.25
Source-Drain Diode
Characteristic Values
(TJ = 25°C unless otherwise specified)
Symbol
IS
Test Conditions
Min.
Typ.
Max.
VGS = 0 V
2
A
A
ISM
Repetitive
6
TO-220 (IXTP) Outline
VSD
trr
IF = IS, VGS = 0 V, Pulse test
1.5
V
IF = 2 A, -di/dt = 100 A/μs,
650
ns
VR = 100 V, VGS = 0 V
Note 1: Pulse test, t ≤ 300 μs, duty cycle d ≤ 2 %
Pins: 1 - Gate
3 - Source
2 - Drain
4 - Drain
