FZT489TA

型号:

FZT489TA

品牌:

DIODES[ DIODES INCORPORATED ]

页数:

7 页

PDF大小:

216 K

A Product Line of
Diodes Incorporated
Green
FZT489
30V NPN SILICON PLANAR MEDIUM POWER TRANSISTOR IN SOT223
Features
Mechanical Data
Case: SOT223
Case material: molded plastic. “Green” molding compound.
UL Flammability Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish - Matte Tin Plated Leads, Solderable per
MIL-STD-202, Method 208
BVCEO > 30V
Max Continuous Current IC = 1A
Low Saturation Voltage
Complementary PNP Type: FZT589
Lead-Free Finish; RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
PPAP capable (Note 4)
Weight: 0.112 grams (approximate)
C
SOT223
B
E
Top View
Pin-Out
Top View
Device Symbol
Ordering Information (Notes 4 & 5)
Product
FZT489TA
FZT489QTA
Compliance
AEC-Q101
Automotive
Marking
FZT489
FZT489
Reel size (inches)
Tape width (mm)
Quantity per reel
1,000
7
7
12
12
1,000
Notes:
1. EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. All applicable RoHS exemptions applied.
2. See http://www.diodes.com for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. Automotive products are AEC-Q101 qualified and are PPAP capable. Automotive, AEC-Q101 and standard products are electrically and thermally
the same, except where specified.
5. For packaging details, go to our website at http://www.diodes.com
Marking Information
FZT489 = Product Type Marking Code
FZT
489
1 of 7
www.diodes.com
October 2012
© Diodes Incorporated
FZT489
Document Number DS33134 Rev. 4 - 2
A Product Line of
Diodes Incorporated
FZT489
Maximum Ratings (@TA = +25°C, unless otherwise specified.)
Characteristic
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Symbol
VCBO
VCEO
VEBO
IC
Value
50
30
7
Unit
V
V
V
Continuous Collector Current
Base Current
1
A
200
4
mA
A
IB
Peak Pulse Current
ICM
Thermal Characteristics (@TA = +25°C, unless otherwise specified.)
Characteristic
Symbol
Value
2
3
62.5
41.7
19.41
-55 to +150
Unit
W
W
°C/W
°C/W
°C/W
°C
(Note 6)
(Note 7)
(Note 6)
(Note 7)
Power Dissipation
PD
Thermal Resistance, Junction to Ambient
RθJA
Thermal Resistance, Junction to Leads (Note 8)
Operating and Storage Temperature Range
RθJL
TJ, TSTG
ESD Ratings (Note 9)
Characteristic
Electrostatic Discharge - Human Body Model
Electrostatic Discharge - Machine Model
Symbol
ESD HBM
ESD MM
Value
8,000
400
Unit
V
V
JEDEC Class
3B
C
Notes:
6. For a device surface mounted on 25mm X 25mm FR4 PCB with high coverage of single sided 1 oz copper, in still air conditions; device measured when
operating in steady state condition.
7. Same as note (6), except the device is mounted on 50mm X 50mm single sided 2oz weight copper.
8. Thermal resistance from junction to solder-point (at the end of the collector lead).
9. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
2 of 7
www.diodes.com
October 2012
© Diodes Incorporated
FZT489
Document Number DS33134 Rev. 4 - 2
A Product Line of
Diodes Incorporated
FZT489
Thermal Characteristics and Derating Characteristics
70
60
50
40
30
20
10
0
50
Tamb=25°C
Tamb=25°C
25mm x 25mm
2oz FR4
40
30
20
10
0
50mm x 50mm
2oz FR4
D=0.5
D=0.5
Single Pulse
D=0.05
Single Pulse
D=0.2
D=0.2
D=0.05
D=0.1
D=0.1
10
100µ 1m 10m 100m
1
100
1k
100µ 1m 10m 100m
1
10
100
1k
Pulse Width (s)
Pulse Width (s)
Transient Thermal Impedance
Transient Thermal Impedance
3.0
Single Pulse
Tamb=25°C
50mm x 50mm
2oz FR4
100
2.5
2.0
1.5
1.0
0.5
0.0
25mm x 25mm
2oz FR4
50mm x 50mm
2oz FR4
10
25mm x 25mm
2oz FR4
1
100µ 1m 10m 100m
1
10
100
1k
0
20 40 60 80 100 120 140 160
Pulse Width (s)
Temperature (°C)
Pulse Power Dissipation
Derating Curve
3 of 7
www.diodes.com
October 2012
© Diodes Incorporated
FZT489
Document Number DS33134 Rev. 4 - 2
A Product Line of
Diodes Incorporated
FZT489
Electrical Characteristics (@TA = +25°C, unless otherwise specified.)
Characteristic
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage (Note 10)
Emitter-Base Breakdown Voltage
Collector Cut-off Current
Symbol
BVCBO
BVCEO
BVEBO
ICBO
Min
50
30
7
Typ
Max
Unit
V
Test Condition
IC = 100µA
IC = 10mA
IE = 100µA
VCB = 30V
VCE = 30V
VEB = 4V
V
V
100
100
100
nA
nA
nA
Collector Cut-off Current
ICES
Emitter Cut-off Current
IEBO
IC = 1A, IB = 100mA
IC = 2A, IB = 200mA
IC = 1A, IB = 100mA
IC = 1A, VCE = 2V
0.3
0.6
Collector-Emitter Saturation Voltage (Note 10)
V
VCE(sat)
Base-Emitter Saturation Voltage (Note 10)
Base-Emitter Turn-On Voltage (Note 10)
1.1
1.0
V
V
VBE(sat)
VBE(on)
IC = 1mA, VCE = 2V
300
100
100
60
I
C = 1A, VCE = 2V
IC = 2A, VCE = 2V
C = 4A, VCE = 2V
CE = 10V, IC = 50mA
DC Current Gain (Note 10)
hFE
20
I
V
Current Gain-Bandwidth Product (Note 10)
Output Capacitance (Note 10)
150
MHz
pF
fT
f = 100MHz
10
Cobo
VCB = 10V, f = 1MHz
Notes:
10. Measured under pulsed conditions. Pulse width 300µs. Duty cycle 2%
4 of 7
www.diodes.com
October 2012
© Diodes Incorporated
FZT489
Document Number DS33134 Rev. 4 - 2
A Product Line of
Diodes Incorporated
FZT489
Typical Electrical Characteristics (@TA = +25°C, unless otherwise specified.)
5 of 7
www.diodes.com
October 2012
© Diodes Incorporated
FZT489
Document Number DS33134 Rev. 4 - 2
A Product Line of
Diodes Incorporated
FZT489
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
SOT223
Dim Min Max Typ
1.55 1.65 1.60
A1 0.010 0.15 0.05
A
b1
b2
C
D
E
E1
e
e1
L
2.90 3.10 3.00
0.60 0.80 0.70
0.20 0.30 0.25
6.45 6.55 6.50
3.45 3.55 3.50
6.90 7.10 7.00
4.60
2.30
0.85 1.05 0.95
0.84 0.94 0.89
A
Q
All Dimensions in mm
A1
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.
X1
Y1
Dimensions Value (in mm)
X1
X2
Y1
Y2
C1
C2
3.3
1.2
1.6
1.6
6.4
2.3
C1
Y2
C2
X2
6 of 7
www.diodes.com
October 2012
© Diodes Incorporated
FZT489
Document Number DS33134 Rev. 4 - 2
A Product Line of
Diodes Incorporated
FZT489
IMPORTANT NOTICE
DIODES INCORPORATED MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARDS TO THIS DOCUMENT,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
(AND THEIR EQUIVALENTS UNDER THE LAWS OF ANY JURISDICTION).
Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes
without further notice to this document and any product described herein. Diodes Incorporated does not assume any liability arising out of the
application or use of this document or any product described herein; neither does Diodes Incorporated convey any license under its patent or
trademark rights, nor the rights of others. Any Customer or user of this document or products described herein in such applications shall assume
all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on Diodes Incorporated
website, harmless against all damages.
Diodes Incorporated does not warrant or accept any liability whatsoever in respect of any products purchased through unauthorized sales channel.
Should Customers purchase or use Diodes Incorporated products for any unintended or unauthorized application, Customers shall indemnify and
hold Diodes Incorporated and its representatives harmless against all claims, damages, expenses, and attorney fees arising out of, directly or
indirectly, any claim of personal injury or death associated with such unintended or unauthorized application.
Products described herein may be covered by one or more United States, international or foreign patents pending. Product names and markings
noted herein may also be covered by one or more United States, international or foreign trademarks.
This document is written in English but may be translated into multiple languages for reference. Only the English version of this document is the
final and determinative format released by Diodes Incorporated.
LIFE SUPPORT
Diodes Incorporated products are specifically not authorized for use as critical components in life support devices or systems without the express
written approval of the Chief Executive Officer of Diodes Incorporated. As used herein:
A. Life support devices or systems are devices or systems which:
1. are intended to implant into the body, or
2. support or sustain life and whose failure to perform when properly used in accordance with instructions for use provided in the
labeling can be reasonably expected to result in significant injury to the user.
B. A critical component is any component in a life support device or system whose failure to perform can be reasonably expected to cause the
failure of the life support device or to affect its safety or effectiveness.
Customers represent that they have all necessary expertise in the safety and regulatory ramifications of their life support devices or systems, and
acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products and any
use of Diodes Incorporated products in such safety-critical, life support devices or systems, notwithstanding any devices- or systems-related
information or support that may be provided by Diodes Incorporated. Further, Customers must fully indemnify Diodes Incorporated and its
representatives against any damages arising out of the use of Diodes Incorporated products in such safety-critical, life support devices or systems.
Copyright © 2012, Diodes Incorporated
www.diodes.com
7 of 7
www.diodes.com
October 2012
© Diodes Incorporated
FZT489
Document Number DS33134 Rev. 4 - 2
