Mod e l 1W1305-20
Dire c tiona l Coup le rs
20 d B
De sc rip tion
The 1W1305-20 is a low profile 20dB directional coupler in an easy to
use surface mount package covering DCS and PCS band applica-
tions. The 1W1305-20 has larger RF pads and spacing between
ground for improved peak power capabilities and reliability in volume
manufacturing and can be used in most high power designs. Parts
have been run through rigorous qualification testing and units are
100% tested. They are manufactured using materials with x and y
thermal expansion coefficients compatable with common substrates.
Fe a ture s
Ele c tric a l Sp e c ific a tions
• 1.7 - 2.0 GHz
Frequency
Mean Coupling
Insert. Loss
VSWR
Max : 1
GHz
dB
dB Max
• Low Loss
Narrow
Narrow
1.805 - 1.880
1.930 - 1.990
1.7 - 2.0
20.5 ± 1.0
20.5 ± 1.0
20.5 ± 1.5
0.25
0.25
0.25
1.18
1.18
1.20
• High Directivity
• Surface Mountable
• Tape And Reel
• Convenient Package
• 100% Tested
Broad
Freq. Sensitivity
Directivity
dB Min
ΘJC
Power
Watts Ave/CW
dB Max
Narrow
Narrow
±0.075
±0.075
±0.30
24
24
20
12.9
100
Broad
Specifications subject to change without notice.
Outline Dra wing
Dimensions are inches over (mm)
Available on Tape and Reel for Pick and Place Manufacturing.
