1W005 - 1W10
Single Phase 1.0 AMP. Silicon Bridge Rectifiers
RB-15
Features
ꢀ
ꢀ
ꢀ
ꢀ
UL Recognized File # E-96005
Surge overload ratings to 30 amperes peak
Ideal for printed circuit board
Reliable low cost construction technique
results in inexpensive product
ꢀ
High temperature soldering guaranteed:
o
260 C / 10 seconds / 0.375” ( 9.5mm )
lead length at 5 lbs., ( 2.3 kg ) tension
Mechanical Data
ꢀ
ꢀ
ꢀ
ꢀ
Case: Molded plastic
Dimensions in inches and (millimeters)
Lead: Pure tin plated, Lead free.
Polarity: As marked
Weight: 1.07 grams
Maximum Ratings and Electrical Characteristics
o
Rating at 25 C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Type Number
Symbol 1W005 1W01 1W02 1W04 1W06 1W08 1W10 Units
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
VRRM
VRMS
VDC
50
35
50
100 200 400 600 800 1000
70 140 280 420 560 700
V
V
V
Maximum DC Blocking Voltage
100 200 400 600 800 1000
1.0
Maximum Average Forward Rectified Current
I(AV)
A
A
V
o
@TA = 50 C
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated IFSM
30
Load (JEDEC method )
Maximum Instantaneous Forward Voltage
VF
1.0
@ 1.0A
Maximum DC Reverse Current
o
@ TA=25 C at Rated DC Blocking Voltage
IR
10
uA
uA
o
@ TA=125 C
500
Typical Thermal resistance (Note)
R
36
13
o
θJA
C/W
R
θJL
o
Operating Temperature Range
Storage Temperature Range
TJ
-55 to +125
-55 to +150
C
o
TSTG
C
Note: Thermal Resistance from Junction to Ambient and from Junction to Lead Mounted on
P.C.B. with 0.2” x 0.2” (5mm x 5mm) Copper Pads.
Version: A06
