ZXTDAM832
ABSOLUTE MAXIMUM RATINGS.
PARAMETER
SYMBOL
LIMIT
40
UNIT
V
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
V
V
V
CBO
CEO
EBO
15
V
7.5
V
Peak Pulse Current
I
I
I
I
15
A
CM
Continuous Collector Current (a)(f)
Continuous Collector Current (b)(f)
Base Current
4.5
A
C
C
B
5.0
A
1000
mA
Power Dissipation at TA=25°C (a)(f)
Linear Derating Factor
P
P
P
P
P
P
1.5
12
W
D
D
D
D
D
D
mW/°C
Power Dissipation at TA=25°C (b)(f)
Linear Derating Factor
2.45
19.6
W
mW/°C
Power Dissipation at TA=25°C (c)(f)
Linear Derating Factor
1
8
W
mW/°C
Power Dissipation at TA=25°C (d)(f)
Linear Derating Factor
1.13
9
W
mW/°C
Power Dissipation at TA=25°C (d)(g)
Linear Derating Factor
1.7
13.6
W
mW/°C
Power Dissipation at TA=25°C (e)(g)
Linear Derating Factor
3
24
W
mW/°C
Operating and Storage Temperature Range
T :T
-55 to +150
°C
j
stg
THERMAL RESISTANCE
PARAMETER
SYMBOL
VALUE
83.3
51
UNIT
°C/W
°C/W
°C/W
°C/W
°C/W
°C/W
Junction to Ambient (a)(f)
Junction to Ambient (b)(f)
Junction to Ambient (c)(f)
Junction to Ambient (d)(f)
Junction to Ambient (d)(g)
Junction to Ambient (e)(g)
R
R
R
R
R
R
θJA
θJA
θJA
θJA
θJA
θJA
125
111
73.5
41.7
Notes
(a) For a dual device surface mounted on 8 sq cm single sided 2oz copper on FR4 PCB, in still air conditions with all exposed pads attached. The copper
area is split down the centre line into two separate areas with one half connected to each half of the dual device.
(b) Measured at t<5 secs for a dual device surface mounted on 8 sq cm single sided 2oz copper on FR4 PCB, in still air conditions with all exposed pads
attached. The copper area is split down the centre line into two separate areas with one half connected to each half of the dual device.
(c) For a dual device surface mounted on 8 sq cm single sided 2oz copper on FR4 PCB, in still air conditions with minimal lead connections only.
(d) For a dual device surface mounted on 10 sq cm single sided 1oz copper on FR4 PCB, in still air conditions with all exposed pads attached attached.
The copper area is split down the centre line into two separate areas with one half connected to each half of the dual device.
(e) For a dual device surface mounted on 85 sq cm single sided 2oz copper on FR4 PCB, in still air conditions with all exposed pads attached attached.
The copper area is split down the centre line into two separate areas with one half connected to each half of the dual device.
(f) For a dual device with one active die.
(g) For dual device with 2 active die running at equal power.
(h) Repetitive rating - pulse width limited by max junction temperature. Refer to Transient Thermal Impedance graph.
(i) The minimum copper dimensions required for mounting are no smaller than the exposed metal pads on the base of the device as shown in the
package dimensions data. The thermal resistance for a dual device mounted on 1.5mm thick FR4 board using minimum copper 1 oz weight, 1mm wide
tracks and one half of the device active is Rth = 250°C/W giving a power rating of Ptot = 500mW.
