Type 300 Specification
Transducer Input
4 or 6 wire connection to any full bridge transducer with a bridge
Resistance 120-2000 ohms
Strain Input
Accuracy
See Adaptor Unit 331 for ¼ and ½ bridge connections
1:4000 in 2mV/V~
Display
5 digits plus units (Nm, lb ft, N, T, lb, kg)
1:100000 (0:99999 display)
1% f.s.d.
Display Resolution
Peak Hold Accuracy
Peak Hold Time Resolution <1/100 Sec
Trips
2 Independent change-over contacts rated to 1A @ 24V dc
Serial Output
Analogue Output
RS232
0-10V dc and 4-20mA
Operation Temperature Range 0°C to 50°C
Storage Temperature Range
Environmental
Calibration
-20°C to +80°C
IP54
Zero push button to memory. Full Scale as mV/V from menu
12-15V dc mains adaptor supplied
Power Supply
Printer Output
Enclosure
RS232
Desktop/Wall Mounted 225mm x 200mm x 80mm
Connections
Transducer
Trips
7 pin socket 2mtr 6-core cable and plug supplied
6 pin plug 2mtr 6-core cable and socket supplied
9 pin D type socket 2mtr cable supplied with 9 – 25 pin adaptor
Requires printer option cable (not standard)
RS232
Printer
Analogue Output
3 pin socket, 2mtr 2-core cable supplied
Datum Electronics Limited
Park Road, Ryde, Isle of Wight, PO33 2BE
Tel: +44 (0)1983 810310
Fax: +44 (0)1983 810318
e-mail: slaes@datum-electronics.co.uk
www.datum-electronics.co.uk
