IXTH30N50L2 IXTQ30N50L2
IXTT30N50L2
Symbol
Test Conditions
Characteristic Values
TO-247 (IXTH) Outline
(TJ = 25°C, unless otherwise specified)
Min.
Typ.
Max.
gfs
VDS = 10V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
9
12
15
S
Ciss
Coss
Crss
8100
530
pF
pF
pF
∅ P
1
2
3
115
RGi
Integrated gate input resistor
3.5
Ω
td(on)
tr
td(off)
tf
35
117
94
ns
ns
ns
ns
Resistive Switching Times
e
V
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Terminals: 1 - Gate
2 - Drain
Tab - Drain
3 - Source
RG = 0Ω (External)
40
Dim.
Millimeter
Min. Max.
Inches
Min. Max.
Qg(on)
Qgs
240
58
nC
nC
nC
A
A1
A2
4.7
2.2
2.2
5.3
2.54
2.6
.185 .209
.087 .102
.059 .098
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
135
b
b1
b2
1.0
1.65
2.87
1.4
2.13
3.12
.040 .055
.065 .084
.113 .123
RthJC
RthCS
0.31 °C/W
°C/W
(TO-247, TO-3P)
0.25
C
D
E
.4
.8
.016 .031
.819 .845
.610 .640
20.80 21.46
15.75 16.26
Safe Operating Area Specification
e
5.20
5.72 0.205 0.225
L
L1
19.81 20.32
4.50
.780 .800
.177
Symbol
SOA
Test Conditions
Min.
Typ.
Max.
VDS = 400V, ID = 0.5A, TC = 75°C, tp = 2s
200
W
∅P 3.55
Q
3.65
.140 .144
5.89
6.40 0.232 0.252
R
S
4.32
6.15 BSC
5.49
.170 .216
242 BSC
Source-Drain Diode
Characteristic Values
(TJ = 25°C, unless otherwise specified)
Symbol
Test Conditions
Min.
Typ.
Max.
TO-3P (IXTQ) Outline
IS
VGS = 0V
30
A
A
ISM
VSD
trr
Repetitive, pulse width limited by TJM
IF = IS, VGS = 0V, Note 1
IF = IS, -di/dt = 100A/μs, VR = 100V
120
1.5
V
500
ns
Note 1: Pulse test, t ≤ 300μs; duty cycle, d ≤ 2%.
TO-268 (IXTT) Outline
IXYS reserves the right to change limits, test conditions, and dimensions.
