General Purpose Relays
Power PCB Relay RX1
I
I
I
I
I
1 pole 12 or 16 A, 1 CO or 1 NO
DC- or AC-coil
Reinforced insulation
Transparent cover optional
RoHS compliant (Directive 2002/95/EC)
as per product date code 0413
Applications
Domestic appliances, heating control, emergency lighting,
automatic doors
S0271-A
Approvals
V
REG.-Nr. A651,
Z
E214025
Technical data of approved types on request
Contact data
Contact configuration
1 CO or 1 NO
single contact
Contact set
Type of interruption
micro disconnection
Rated current
12 A
16 A
Rated voltage / max.switching voltage AC
Maximum breaking capacity AC
Limiting making capacity, max 4 s, duty factor 10%
Contact material
240/400 VAC
3000 VA
4000 VA
25 A
AgNi 90/10
Mechanical endurance DC coil
AC coil
Rated frequency of operation with / without load
> 5 x 106 cycles
> 1 x 106 cycles
6 / 600 min-1
Contact ratings
Type
RX1
RX1
RX3
RX3
Load
Cycles
1x105
1x105
5x104
5x104
12 A, 250 VAC, DC coil, NO contact, 85°C, EN61810-1
12 A, 250 VAC, AC coil, NO contact, 70°C, EN61810-1
16 A, 250 VAC, NO contact, 70°C, DF 50%, EN61810-1
16 A, 250 VAC, NO contact, 85°C, DF 10%, UL508
Coil data
Rated coil voltage range DC coil
AC coil
5...110 VDC
24...230 VAC
520 mW
typ 0,75 VA
2
Coil power DC coil
AC coil
Operative range
Coil insulation system according UL1446
class F
Coil versions, DC-coil
Coil
Rated
voltage
VDC
5
Operate
voltage
VDC
3.5
Release
voltage
VDC
0.5
Coil
resistance
Ohm
50+10%
68+10%
274+10%
1095+10%
4380+10%
6845+10%
23010+10%
Rated coil
code
power
mW
500
529
526
526
526
526
526
005
006
012
024
048
060
110
6
4.2
0.6
12
8.4
1.2
24
16.8
33.6
42.0
77.0
2.4
48
4.8
60
6.0
110
11.0
All figures are given for coil without preenergization, at ambient temperature +23°C
1
