IXTQ 18N60P
IXTV 18N60P IXTV 18N60PS
Symbol
gfs
Test Conditions
Characteristic Values
TO-3P (IXTQ) Outline
(TJ = 25°C, unless otherwise specified)
Min. Typ. Max.
VDS = 20 V; ID = 0.5 ID25, pulse test
VGS = 0 V, VDS = 25 V, f = 1 MHz
9
16
S
Ciss
Coss
Crss
2500
278
23
pF
pF
pF
td(on)
tr
td(off)
tf
21
22
62
22
ns
ns
ns
ns
VGS = 10 V, VDS = 0.5 VDSS, ID = ID25
RG = 5 Ω (External)
Qg(on)
Qgs
49
15
17
nC
nC
nC
VGS = 10 V, VDS = 0.5 VDSS, ID = 0.5 ID25
Qgd
RthJC
RthCS
0.35 °C/W
°C/W
(TO-3P, PLUS220)
0.21
Source-Drain Diode
Characteristic Values
(TJ = 25°C, unless otherwise specified)
Min. Typ. Max.
Symbol
IS
Test Conditions
VGS = 0 V
Repetitive
18
54
A
ISM
A
V
PLUS220 (IXTV) Outline
VSD
IF = IS, VGS = 0 V,
1.5
Pulse test, t ≤ 300 μs, duty cycle d ≤ 2 %
IF = 18A, -di/dt = 100 A/μs
VR = 100V
trr
500
ns
PLUS220SMD (IXTV_S) Outline
IXYS reserves the right to change limits, test conditions, and dimensions.
