TYN612
DESCRIPTION
Glass passivated thyristors in a plastic envelope, intended
for use in applications requiring high bidirectional blocking
voltage capability and high thermal cycling performance.
Typical applications include motor control, industrial and
domestic lighting, heating and static switching.
ABSOLUTE MAXIMUM RATINGS ( Ta = 25 OC)
Parameter
Symbol
Typ
Unit
Repetitive peak off-state
voltages
VDRM
VRRM
600
V
Average on-state current
RMS on-state current
IT(AV)
8.0
12
A
A
IT(RMS)
Non-repetitive peak
on-state current
ITSM
140
A
A1 A2 G
Max. Operating Junction
Temperature
Tj
110
oC
oC
TO-220
Storage Temperature
Tstg
-45~150
( Ta = 25 OC)
ELECTRICAL CHARACTERISTICS
Parameter
Symbol
Test Conditions
Min
Typ
Max Unit
VDRM
VRRM
Repetitive peak off-state voltages
600
V
Average on-state current
RMS on-state current
IT(AV)
IT(RMS) all conduction angles
half sine wave; Tmb< 103 oC
8.0
A
A
12
1.3
7.5
10
4
On-state voltage
Holding current
VTM
ITM=24A,tp=380 s
1.60
30
V
IH
IL
VD =12 V; IGT = 0.1 A
VD =12 V; IGT = 0.1 A
mA
mA
Latching current
45
Gate trigger current
Gate trigger voltage
IGT
VD =12 V; IT = 0.1 A
VD =12 V; IT = 0.1 A
mA
V
15
VGT
0.6
1.5
