GENERAL CHARACTERISTICS
PARAMETER
SYMBOL
TYPICAL RATING
420
UNITS
mV
OPEN CIRCUIT VOLTAGE @ 100 fc, 2850 K SOURCE
PEAK SPECTRAL RESPONSE @ 25°C
V
OC
l pk
l range
t / t
920
725 - 1100
20
nm
nm
ns
SPECTRAL APPLICATION RANGE
RISE/FALL TIMES @ 800 nm, V =10 V, R = 50 W
R
F
R
L
TEMPERATURE COEFFICIENT
TC I
TC I
+0.20
+11.0
- 2.0
% / °C
% / °C
mV/ °C
SHORT CIRCUIT CURRENT @ 2850 K SOURCE
SC
DARK CURRENT @ V = 10 V
D
R
TC
T
OPEN CIRCUIT VOLTAGE
VOC
- 40 to +100
°C
TEMPERATURE RANGE, OPERATING & STORAGE
AMB
TYPICAL CHARACTERISTIC CURVES
RELATIVE SPECTRAL RESPONSE
ANGULAR RESPONSE
RELATIVE JUNCTION CAPACITANCE vs BIAS VOLTAGE
(REFERRED TO ZERO BIAS)
Specifications subject to change without prior notice.
Information supplied by PerkinElmer Optoelectronics is
believed to be reliable, however, no responsibility is
assumed for possible inaccuracies or omissions. The
user should determine the suitability of this product in
his own application. No patent rights are granted to any
devices or circuits described herein.
