M S
V PRODUCT FEATURE
8S3223
2.550
SP8T SWITCH
with REMOVABLE
SMA CONNECTORS
• Broad Band (2-18 GHz)
• Fast Switching
J6
J7
J5
J4
8S3223
J3
J2
M
S
V
1.300
• Small Package
1.50
• -55°C to +125°C Operation
J1
J8
SN xxx date
J0
TRUTH TABLE
E3 E2 E1
SELECTED PATH
REMOVABLE SMA CONNECTOR
(.012 DIA PIN , 9 PL)
.018 DIA PIN
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
J0 - J1
J0 - J2
J0 - J3
J0 - J4
J0 - J5
J0 - J6
J0 - J7
J0 - J8
2.75
1.375
.000
.35 ±.01
SPECIFICATIONS
MODEL
NUMBER
FREQUENCY VSWR INSERTION ISO.
RANGE
(GHz)
MAX. LOSS (dB) (dB)
OPTIONS AVAILABLE
MAX.
3.5
MIN.
Alternate Configurations
Isolations to 80 dB
8S3223
2 - 18
2.0
60
Alternate Power Supplies
Faster Speeds
Extended Frequency Range
Custom Screening
Switching Speed (50% TTL to 10/90% RF) 100 ns Max
Harmonic Generation (@ +20 dBm)
TTL Control (3 Line)
50 dBc Max
Decoded
RF Power (No Performance Degradation)
Power Supply Requirements
+23 dBm
+5V, -5V
Operating Temperature Range
-55° to +125°C
The 8S3223 SP8T with internal drivers is a sealed, integrated switching network, using passivated PIN diodes, thereby
minimizing electrical parasitics. This enables the SP8T switch to work over extremely wide bandwidths. This switch is
ruggedly built and conservatively rated to insure highly reliable operation. The 8S3223 SP8T incorporates a TTL PIN
diode driver integrated with the MVS solid state RF section and bias filtering circuits. MVS switches are ideally suited for
microwave sub-assemblies, where many system functions must be integrated together. The 8S3223 SP8T is perfect for
high-speed channel selection or pulse modulation.
160B Shelton Road
Monroe, CT 06810
TEL (203) 445-1970
FAX (203) 445-1564
