CZP
multilayer power ferrite bead
EU
features
• Designed to reduce noise at high frequencies
• Standard EIA packages: 1J, 2A, 2B
• Nickel barrier with solder overcoat for excellent
solderability
• Magnetically shielded
• Marking: Black body color with no marking
• Products with lead-free terminations meet
EU RoHS requirements
dimensions and construction
Type
(Inch Size Code)
Dimensions inches (mm5
W
L
W
t
d
1J
.063 .006
.031 .006
.031 .006
.014 .006
L
Solder
(0603)
(1.6±±.1ꢀ5
(±.8±±.1ꢀ5
(±.8±±.1ꢀ5
(±.36±±.1ꢀ5
Plating
2A
(0805)
.079 .008
(2.±±±.25
.047 .008
(1.2±±±.25
.035 .008
(±.9±±.25
.02 .012
(±.ꢀ1±±.3±5
Ni
Plating
2B
(1206)
.126 .008
(3.2±±.25
.063 .008
(1.6±±.25
.043 .008
(1.1±±.25
.02 .012
(±.ꢀ1±±.3±5
Silver
Metallization
t
d
Terminations
(Metallization
Bands)
d
Electrodes
ordering information
New Part #
CZP
2A
F
T
TD
500
P
Permeability
Code
Termination
Material
Type
Size
Packaging
Impedance
Tolerance
2 significant
figures + 1
multiplier
1J
2A
2B
F
P
T: Sn
TD: 7" paper tape
(1J, 2A - 4,000 pieces/reel)
TE: 7" embossed plastic
(2B - 3,000 pieces/reel)
P: 25%
For further information
on packaging, please refer
to Appendix A.
