New Product
8STH06FP
Vishay High Power Products
Hyperfast Rectifier,
8 A FRED PtTM
FEATURES
• Hyperfast recovery time
• Low forward voltage drop
RoHS
COMPLIANT
• Low leakage current
• 175 °C operating junction temperature
• Designed and qualified for industrial level
1
2
3
DESCRIPTION
8STH06FP 600
V series are the state of the art
tandem hyperfast recovery rectifiers: excellent switching
performance and extremely low forward voltage drop trade
off is overcome, boosting overall application performance.
Specially designed for CCM PFC application, these devices
show incomparable performance in every current intensive
hard switching application.
3L TO-220 FULL-PAK
Optimized reverse recovery stored charge enables
downsizing of boosting switch and cooling system, increased
operating frequency make possible use of smaller reactive
elements. Cost effective PFC application is then possible
with high efficiency over wide input voltage range and
loading factor.
PRODUCT SUMMARY
trr
IF(AV)
VR
19 ns
8 A
600 V
Plastic insulated package features easy mounting together
with not insulated parts.
ABSOLUTE MAXIMUM RATINGS FOR BOTH DIODES
PARAMETER
SYMBOL
VRRM
IF
TEST CONDITIONS
MAX.
600
UNITS
Repetitive peak reverse voltage
DC forward current
V
50 % duty cycle, rect. waveforms, TC = 93 °C
TC = 25 °C
8
A
Non-repetitive peak surge current
Operating junction and storage temperatures
IFSM
100
TJ, TStg
- 55 to 175
°C
ELECTRICAL SPECIFICATIONS FOR BOTH DIODES (TJ = 25 °C unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN.
TYP.
MAX.
UNITS
Breakdown voltage,
blocking voltage
VBR
VR
,
IR = 100 µA
IF = 8 A
600
-
-
-
-
-
-
-
-
-
2.1
1.7
1.6
< 1
7
2.4
2
V
Forward voltage
VF
IF = 8 A, TJ = 125 °C
IF = 8 A, TJ = 150 °C
VR = VR rated
1.8
10
80
100
-
Reverse leakage current
Junction capacitance
IR
TJ = 125 °C, VR = VR rated
TJ = 150 °C, VR = VR rated
VR = 600 V
µA
pF
27
12
CT
Document Number: 94554
Revision: 08-Apr-08
