Certificate: TH97/10561QM
Certificate: TW00/17276EM
SURFACE MOUNT SILICON
ZENER DIODES
SZ653D - SZ65D0
V
P
Z
: 3.3 - 200 Volts
: 5 Watts
SMB (DO-214AA)
D
1.1 ± 0.3
FEATURES :
* Complete Voltage Range 3.3 to 200 Volts
* High peak reverse power dissipation
* High reliability
0.22 ± 0.07
2.0 ± 0.1
* Low leakage current
2.3 ± 0.2
3.6 ± 0.15
* Nonsensitive to ESD
* Pb / RoHS Free
MECHANICAL DATA
* Case : SMB (DO-214AA) Molded plastic
* Epoxy : UL94V-O rate flame retardant
* Lead : Lead formed for Surface mount
* Polarity : Color band denotes cathode end
* Mounting position : Any
Dimensions in millimeters
PAD LAYOUT
A
INC.
mm.
A
B
C
0.260 6.60
0.085 2.16
0.110 2.79
* Weight : 0.093 gram
C
MAXIMUM RATINGS
Rating at 25 °C ambient temperature unless otherwise specified
B
Rating
Symbol
Value
Unit
W
DC Power Dissipation at TL = 75 °C (Note1)
PD
5.0
1.2
Maximum Forward Voltage at IF = 1.0 A
VF
V
TJ
Operating Junction Temperature Range
Storage Temperature Range
- 55 to + 150
- 55 to + 150
°C
TSTG
°C
Note :
(1) TL = Lead temperature at 6.0 mm2 ( 35 micron thickness ) copper land areas.
Fig. 1 POWER TEMPERATURE DERATING CURVE
5.0
4.0
3.0
2.0
1.0
0
6.0 mm2 ( 35 micron thickness )
copper land areas.
0
25
50
75
100
125
150
175
TL, LEAD TEMPERATURE (°C)
Page 1 of 2
Rev. 07 : March 16, 2007
