Absolute encoders - parallel
Hollow shaft ø14 mm
Singleturn encoder 13 bit, 1024 cams
RXA1H
Terminal significance
Terminal assignment
UB
Encoder voltage supply.
Connector
Pin 1
Core colour Assignment
GND
Ground connection of encoder and output
drivers relating to UB.
white
Output 1
Output 2
Output 3
Output 4
Output 5
Output 6
Output 7
Output 8
Output 9
Output 10
Pin 2
brown
green
yellow
grey
Outputs
1-16
16 programmable cams outputs.
Each output enables optionally alternative
configuration as special output.
Pin 3
Pin 4
Pin 5
Zero setting
Input for setting a zero point anywhere
within the programmed encoder resolution.
The zero setting operation is released by a
High impulse and has to be in line with the
selected counting direction (UP/DOWN).
Connect to GND after reset operation for
maximum interference immunity. Impulse
duration >100 ms.
Pin 6
pink
Pin 7
black
Pin 8
violet
Pin 9
grey/pink
red/blue
Pin 10
Pin 11
Pin 12
Pin 13
Pin 14
Pin 15
Pin 16
Pin 17
Pin 18
Pin 19
Pin 20
Pin 21
Pin 22
Pin 23
Pin 24
Pin 25
Pin 26
Pin 27
Pin 28
Pin 29
Pin 30
Pin 31
Pin 32
Pin 33
Pin 34
Pin 35
Pin 36
Pin 37
white/green Output 11
braun/green Output 12
white/yellow Output 13
yellow/brown Output 14
For safety reasons any reset operation will
immediately stop a running cams program.
Start
Program start input.
Applying a High potential (UB) for at least
100 ms will start the selected cams
program. If the start input is firmly con-
nected to UB, the cams program selected
at the programming inputs will immediately
start after encoder power on.
white/grey
grey/brown
yellow/blue
green/grey
yellow/pink
–
Output 15
Output 16
–
–
Programs
Inputs for program selection 1-16.
Preset of the cams program in binary code.
Program 1 is selected by code 0-0-0-0
program 16 by 1-1-1-1.
Input „Program 1“: Valence „1“
Input „Program 2“: Valence „2“
–
–
–
–
–
–
–
–
Input „Program 4“: Valence „4“
Input „Program 8“: Valence „8“
–
–
white/pink
pink/brown
white/red
brown/red
white/black
Start
After encoder power on and upon every
alteration at the programming inputs the
cams program selection by the four
programming inputs will be valid. A later
selection by serial programming interface
will overwrite the selection made at the four
programming inputs. Every alteration of the
program inputs will immediately stop a
running cams program.
Zero setting
Program 1
Program 2
Program 4
brown/black Program 8
pink/green
grey/green
yellow/grey
white/blue
brown/blue
red
GND-PRG
VPOS1
VPOS2
TxD
VPOS1
VPOS2
Separate voltage supply of output driver
(outputs 1-8: pin 32, outputs 9-16: pin 33).
GND-PRG
Separate ground of programming interface
RS232.
RxD
RxD
Encoder receiver input for RS232 program-
ming interface.
UB
blue
GND
TxD
Encoder transmitter output for RS232
programming interface.
