NEW
Crystal Clock Oscillator
Low Phase Noise Type
NZ2520S Series
Model name
NZ2520SD Frequency stability of 50 ꢀ ꢁ0 .
n
–6
Application
n
l
For wireless LAN
Pb
Free
Absolute maꢀimum rating
Features
n
Power supply voltage (VDD) –0.6 to +6.0 V
Storage temperature range –55 to +ꢁ25 °C
l
Low phase noise, low voltage, low consumption current, and high stability,
maꢂe this product ideal for wireless LAN.
l
l
l
Compact and light. Dimensions and weightꢄ 2.5 ꢀ 2.0 mm, 0.9 mm, and 0.02 g.
Automatic mounting by taping and IR reflow (lead-free) are possible.
Lead-free.
Specifications
n
Model
(MHꢃ)
NZ2520SD
C–MOS
Item
Output level
Frequency range
Operating temperature range
Frequency Stability
*ꢁ
20 ≤ F < 30
4.5
30 ≤ F ≤ 40
5.5
*2
(°C)
–40 to +85
50
–6
(×ꢁ0
)
Current
During operation +3.3 V, 25 °C (mA)
During standby +3.3 V, 25 °C (μA)
consumption
maꢀ
ꢁ0
VOL maꢀ/VOH min
(V)
(ns)
(%)
0.ꢁ VDD/0.9 VDD
Tr maꢀ/Tf maꢀ
Duty Cycle min. to maꢀ.
6/6
45 to 55
Load (C ) maꢀ
Oscillation start time maꢀ
Standby function
L
(pF)
(ms)
ꢁ5
4
Available (tristate)
Fout ꢁ ꢂHꢃ ꢄ –ꢁ45 (Typ)
Fout ꢁ00 ꢂHꢃ ꢄ –ꢁ58 (Typ)
Phase noise
+3.3 V, 25 °C
*ꢁꢄ If you require a product with a frequency not given above, please contact us.
*2ꢄ If you require a product with an operating temperature range not given above, please contact us.
List of Codes for Placing an Order
n
List of Codes for Placing an Order
Power supply voltage [VDD
NSA3449E
+3.3 0.33
]
(V)
cc30_081201_NZ2520SD_50_e
