SMD 5x7 45MHz Crystal Filter
MODEL NO.: TY0133A
REV. NO.: 1
Features:
RoHS Compliant
Lead free
Lead-free soldering
ꢀ
ꢀ
ꢀ
Surface Mount Seam Weld Package
3-pole IF Filter
Excellent Reliability Performance
Description and Applications:
Surface mount 5.0mmx7.0mm crystal filter for use in wireless telecommunication devices.
Electrical Specifications:
TY0133A
Specification
45.0 MHz, Fundamental
3.0 dB max
Center Frequency Fo
Insertion Loss
Ripple (@+/-6.0 KHz)
3 dB Passband
1.0 dB max
+/-7.5 KHz
Stopband (@+/-25 KHz)
Ultimate Attenuation @ Fo-910 KHz
Spurious
15 dB min
70 dB min
10 dB min
Terminating Impedance
Operating Temperature
Marking
650Ω// 3.5pF
-20°C ~ +70°C
Laser marking
