T Series Crystal Spec
¾ 3.2mm X 2.5mm SMD
¾ Wide Frequency Range
¾ RoHS Compliant
¾ Tight Tolerance and Stability
ESR CHART:
ELECTRICAL SPECIFICATIONS:
ESR
(Ohms)
100 Max
80 Max
60 Max
Frequency Range
Frequency Tolerance /
Stability
Operating Temperature
Range
13.000MHz to 55.000MHz
(See Part Number Guide for Options)
Frequency Range
Mode / Cut
13.000MHz to 20.000MHz
20.000MHz to 30.000MHz
30.000MHz to 55.000MHz
Fund / AT
Fund / AT
Fund / AT
(See Part Number Guide for Options)
Storage Temperature
Aging
Shunt Capacitance
Load Capacitance
Equivalent Series
Resistance (ESR)
Drive Level
-40°C to +85°C
±5ppm / first year max
5pF Max
MARKING:
Line 1: MXX.XXX
XX.XXX = Frequency in MHz
(See Part Number Guide for Options)
See ESR Chart
Line 2: SYMCCL
S = Internal Code
YM = Date Code (Year/Month)
CC = Crystal Parameters Code
L = Denotes RoHS Compliant
10µW Typ / 100µW Max
500 Megaohms Min at 100VDC ±15VDC
Insulation Resistance
MECHANICAL DETAILS:
3.45 [.136]
MAX
0.75 [.030]
MAX
2.12 [.083]
1.20 [.047]
2.00 [.079]
1.70 [.067]
PIN CONNECTION
1
2
3
4
CRYSTAL
NC
CRYSTAL
NC
1
4
2
3
2.75 [.108]
MAX
1.60 [.063]
1.50 [.059]
0.91 [.036]
1.12 [.044]
RECOMMENDED
LAND PATTERN
DIMENSIONS IN BRACKETS ARE IN INCHES
PART NUMBER GUIDE:
Frequency
T
1
3.2mm x 2.5mm
4 pads
Temperature
Tolerance/Stability
B = ±30 ppm / ±50 ppm
F = ±30 ppm / ±30 ppm
G = ±10 ppm / ±30 ppm
N = ±10 ppm / ±10 ppm
P = ±20 ppm / ±20 ppm
Operating Temperature
A = 0°C to +70°c
B = -20°C to +70°c
C = -40°C to +85°c
D = -10°C to +60°c
E = -10°C to +70°c
Packaging
Load Capacitance
XX = XXpF (9pF to 50pF)
Mode of Operation
Blank = Bulk
T = Tape and Reel
1 = Fundamental
Please Consult with MMD Sales Deparment for any other Parameters or Options
